JAC Gallop K3W Heavy Duty Version 350 hp 6X4(10 wheels) Flatbed Truck
EXW
Export quote
JAC Gallop K3 Heavy Truck flatbed truck
Main model photos
903 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| JAC Gallop K3W Heavy Duty Version 350 hp 6X4(10 wheels) Flatbed Truck | 6x4 / 350hp / China V | ||
| JAC Gallop K3W Heavy Duty Version 350 hp 6X4(10 wheels) Flatbed Truck | 6x4 / 350hp / China V | ||
| JAC Gallop K3W Heavy Duty Version 350 hp 6X4(10 wheels) Flatbed Truck | 6x4 / 350hp / China V | ||
| JAC Gallop K3W Heavy Duty Version 350 hp 6X4(10 wheels) Flatbed Truck | 6x4 / 350hp / China V | ||
| JAC Gallop K3W Heavy Duty Version 350 hp 6X4(10 wheels) Flatbed Truck | 6x4 / 350hp / China V |
JAC Gallop K3W Heavy Duty Version 350 hp 6X4(10 wheels) Flatbed Truck
EXW
Export quote
JAC Gallop K3W Heavy Duty Version 350 hp 6X4(10 wheels) Flatbed Truck
EXW
Export quote
JAC Gallop K3W Heavy Duty Version 350 hp 6X4(10 wheels) Flatbed Truck
EXW
Export quote
JAC Gallop K3W Heavy Duty Version 350 hp 6X4(10 wheels) Flatbed Truck
EXW
Export quote
Series Specs
Basic Info
Cab dimensions: 9.04×2.5×3.5 / 8.625×2.5×3.5 / 8.385×2.5×3.5 / 9.735×2.55×3.5 / 10.035×2.55×3.5 / 10.425×2.55×3.5 / 10.805×2.55×3.5 / 11.1×2.495×3.45 / 10.4x2.495x3.3 / 8.68×2.495×3.3 / 10.5×2.495×3.45 / 8.95×2.5×3.35 / 9.67×2.495×3.11,2.99m
Type: Flatbed dump truck / flatbed truck
Drive type: 6X4 / 8X4 / 4X2
Wheelbase: 4350+1350 / 4100+1350 / 3900+1350 / 3690+1350 / 1800+3200+1350 / 1800+3500+1350 / 1800+3800+1350 / 1800+4100+1350 / 4700 / 4500 / 5300 / 4000+1350mm
Rated mass: 12.355 / 12.42 / 15.355 / 14.755 / 10.97 / 7.305 / 9 / 14.805ton
GVWR: 25 / 31 / 30.95 / 24.5 / 15.6 / 15.95ton
Front/rear suspension: 1.495/1.845 / 1.495/1.68 / 1.495/1.64 / 1.495/1.85 / 1.495/1.89 / 1.495/1.98 / 1.495/2.06 / 1.495/2.655 / 1.495/3.205 / 1.53/2.45 / 1.53/2.12 / 1.585/2.735m
Energy Type: Diesel
Body Parameters
Other special notes: K3W Semi-High Roof / Highway transfer transport for railway-standard containers. / Effective cargo platform length 6.2m, ramp 1.1m. Ladder: length 2500, 160*80*8 square steel 8 pcs (4 per side), four extended springs. / Effective cargo platform length 5.5m, ramp 0.75m. Ladder: length 2300, 6 pieces of 140*80*6 square steel (3 per side), four extended springs. / Effective cargo platform length 5.5m, ramp 0.75m, ladder: length 2300, 6 pieces of 140*80*6 square steel (3 per side), four extended springs. / Overall length 10.5m, flatbed platform length 6.6m, ramp 1.1m, manually expandable to 3.1m / Effective cargo platform length 5m, ramp 0.7m. / Effective cargo platform length 7.2m, ramp 1m. / Optional semi-high roof cab, front grille, and new style semi-high roof cab
Vehicle certification code: HFC3251P1K6E43S3V / HFC3251P1K6E41S3V / HFC3251P1K6E39S3V / HFC3311P1K6H35S3V / HFC3311P1K6H38S3V / HFC3311P1K6H41S3V / HFC3311ZXPP2K4H38AF / HFC5251TPBP1K4E43F / HFC5161TPBP3K1A47F / HFC5311TPBP2K4H38AF / DTA5160TPB / HFC5251TPBK1R1LZT
Body Brand: JAC Gallop / Teyun
Engine parameters
Engine Model: WeichaiWP10.350E53 / WeichaiWP10.310E53 / WeichaiWP12.375E50 / WeichaiWP10.300E40 / WeichaiWP10.270E40 / YuchaiYC6J180-46 / YuchaiYC4E160-42 / Xichai CA4DF3-15E3 / Yuchai YC6J220-33
Displacement: 9.726 / 11.596 / 6.49 / 4.26 / 4.752 / 7.225L
Emission standard: China V / China IV / China III / Euro III
Max output power: 257 / 228 / 276 / 221 / 199 / 132 / 118 / 116 / 162kW
Max hp: 350 / 310 / 375 / 300 / 270 / 180 / 160 / 150 / 220Horsepower
Chassis Specs
Chassis Brand: JAC Gallop
Chassis Series: GallopK3
Chassis Model: HFC3251P1K6E43S3V / HFC3251P1K6E41S3V / HFC3251P1K6E39S3V / HFC3311P1K6H35S3V / HFC3311P1K6H38S3V / HFC3311P1K6H41S3V / HFC3311P2K4H38AF / HFC1241P1K4D60F / HFC1166K1R1ZF / HFC1162K1R1T / HFC1251K1R1LZT
rear axle description: Mercedes-Benz (4.76/5.26 ratio) / STR (4.8/5.73 ratio) / Anben (4.2/4.76/5.26/5.92 ratio) / Anben (4.76/5.26 ratio) / Anben (4.2/4.76 ratio) / Anben (4.2/4.76/5.26 ratio) / Ankai 457 Rear Axle, Ratio 4.44 / Front axle: Sanhuan 6.5T, Rear axle: Anben axle 4.76 / Front axle: Sanhuan 5.5T; Rear axle: Boying 9T (4.875) / Front axle: JAC 3.5T; Rear axle: Boying 8T (4.875) / 5T/9T / Reinforced 435
Leaf spring count: 10/12 / 9/9/12 / 9/9+7 / 9/12
Transmission Parameters
Number of gears: 12 / 16 / 10 / 9 / 8 / 7Gear
Transmission Model: Fast Gear12JSD160(T)+QH50 cast iron / Fast Gear 12JSD180(T)+QH70 cast iron / Fast Gear12JSD160(T)+QH70 cast iron / Fast Gear 16JSD200T(A)+QH70 cast iron / Fast Gear 16JSD200T+QH70 cast iron / Fast Gear10JSD140 / Fast Gear9JS135(T-B) / Fast Gear8JS85E / Fast Gear8JS75C / Fast Gear / Fast Gear 7DS100
Tire
Tire Size: 11.00R20，12.00R20 16PR / 11.00R20 / 10.00R20 / 12.00R20 14PR / 9.00R20 16PR / 9.00-20 / 10.00-20,10.00R20,11.00-20,11.00R20
Number of tires: 10 / 12 / 6pcs
FAQ
What kind of truck is JAC Gallop JAC Gallop K3 Heavy Truck flatbed truck?
JAC Gallop JAC Gallop K3 Heavy Truck is an export-oriented flatbed truck lineup with about 22 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for JAC Gallop K3 Heavy Truck flatbed truck?
JAC Gallop K3 Heavy Truck flatbed truck export reference is about $23,861 – $49,722. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does JAC Gallop K3 Heavy Truck flatbed truck cover?
JAC Gallop K3 Heavy Truck flatbed truck mainly covers: Drive: 6x4; Horsepower: 350 hp; Emission: China V. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in JAC Gallop K3 Heavy Truck flatbed truck?
For JAC Gallop K3 Heavy Truck flatbed truck: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is flatbed truck typically used for?
flatbed truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does JAC Gallop K3 Heavy Truck flatbed truck include?
JAC Gallop K3 Heavy Truck flatbed truck currently lists about 22 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for JAC Gallop K3 Heavy Truck flatbed truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
