Chaochai NV30-C6B 163 hp 3.1L China VI Diesel Engine
EXW
Export quote
Chaochai NGD3.0 Series engine
Main model photos
6 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Chaochai NV30-C6B 163 hp 3.1L China VI Diesel Engine | 163hp / China VI | ||
| Chaochai NV30-C6D 163 hp 3L China VI Diesel Engine | 163hp / China VI | ||
| Chaochai NV30-C6C 163 hp 3L China VI Diesel Engine | 163hp / China VI | ||
| Chaochai NV30-C6E 163 hp 3L China VI Diesel Engine | 163hp / China VI | ||
| Chaochai NV30-C6G 156 hp 3L China VI Diesel Engine | 156hp / China VI |
Chaochai NV30-C6D 163 hp 3L China VI Diesel Engine
EXW
Export quote
Chaochai NV30-C6C 163 hp 3L China VI Diesel Engine
EXW
Export quote
Chaochai NV30-C6E 163 hp 3L China VI Diesel Engine
EXW
Export quote
Chaochai NV30-C6G 156 hp 3L China VI Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: NGD3.0 Series
Engine manufacturer: Chaochai / Dongfeng Chaochai Power Co., Ltd. / Dongfeng Chaoyang Chaochai Power Co., Ltd.
Suitable Range: High-end midibus / High-end midibus, high-end light truck, SUV, pickup, off-road vehicle / NGD3.0 diesel engine primarily for light trucks, SUVs, pickup trucks, light buses, MPVs, with broad market prospects
Intake type: Turbocharged Air-to-Air Intercooling / Turbocharged
Min. fuel consumption at full load: ≤200 / 202 / ≤202 / 205g/kW.h
Engine net weight: 280kg
Engine Dimensions: 662.7×638×708.8 / 842x746.5x814.5 / 603×676×702mm
noise at 1m: 113dB
Compression ratio: 17：1 / 17:1
Bore × Stroke: 96×102.5mm
Valves per cylinder: 4pcs
firing order: 1-3-4-2
Engine Brand: Chaochai
Engine Model: NV30-C6B / NV30-C6D / NV30-C6C / NV30-C6E / NV30-C6G / NGD3.0-CS6 / ChaochaiNGD3.0-CS5A / NGD3.0-CS5D / NGD3.0-CS5C / NGD3.0-CS5B / CYNGD3.0-CE4 / NGD3.0
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 3.093 / 2.968L
Emission standard: China VI / China V / China IV
Max output power: 120 / 115 / 110 / 100kW
Max hp: 163 / 156 / 150 / 136Horsepower
Max torque: 400 / 450 / 360 / 430 / 320 / 380N·m
Max torque speed: 1200-2200 / 1600-2200 / 1400-2600 / 1600-2600rpm
Rated speed: 2800 / 3200 / 3800rpm
Engine Type: EGR+DOC+DPF+SCR+ASC / Electronically controlled high-pressure common rail / Vertical water-cooled, four-stroke, turbocharged intercooled, electronic control high-pressure common rail, SCR / Vertical in-line, water-cooled, 4-stroke, turbocharged & intercooled, electronic high-pressure common rail, DOC+POC / Vertical inline, four-stroke, turbocharged
FAQ
What kind of truck is Chaochai Chaochai NGD3.0 Series engine?
Chaochai Chaochai NGD3.0 Series is an export-oriented engine lineup with about 13 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Chaochai NGD3.0 Series engine cover?
Chaochai NGD3.0 Series engine mainly covers: Horsepower: 156 hp / 163 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Chaochai NGD3.0 Series engine?
For Chaochai NGD3.0 Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Chaochai NGD3.0 Series engine include?
Chaochai NGD3.0 Series engine currently lists about 13 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Chaochai NGD3.0 Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
