Quanchai QC100E340 340 hp 10L China IV Diesel Engine
EXW
Export quote
Quanchai QC Series engine
Main model photos
3 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Quanchai QC100E340 340 hp 10L China IV Diesel Engine | 340hp / China IV | ||
| Quanchai QC480ZLQ 52 hp 1.8L China II Diesel Engine | 52hp / China II/Euro II |
Quanchai QC480ZLQ 52 hp 1.8L China II Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: Quanchai QC Series
Engine manufacturer: Anhui Quanchai Power Co., Ltd.
Suitable Range: Truck engine
Intake type: Turbocharged Air-to-Air Intercooling
Min. fuel consumption at full load: 225g/kW.h
Engine net weight: 850kg
Engine Dimensions: 805x560x632mm
Compression ratio: 18：1
noise at 1m: 119dB
Bore × Stroke: 126x130 / 80x90mm
Valves per cylinder: 4pcs
Engine Brand: Quanchai
Engine Model: QC100E340 / QC480ZLQ
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 9.726 / 1.809L
Emission standard: China IV / China II/Euro II
Max output power: 250 / 38kW
Max hp: 340 / 52Horsepower
Max torque: 1500 / 131N·m
Max torque speed: 1500 / 2000rpm
Rated speed: 2200 / 3000rpm
Engine Type: High-pressure common rail, direct injection / 4-cylinder, vertical, direct injection, forced water cooling, 4-stroke, turbocharged intercooled
FAQ
What kind of truck is Quanchai Quanchai QC Series engine?
Quanchai Quanchai QC Series is an export-oriented engine lineup with about 2 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Quanchai QC Series engine cover?
Quanchai QC Series engine mainly covers: Horsepower: 52 hp / 340 hp; Emission: China II/Euro II / China IV; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Quanchai QC Series engine?
For Quanchai QC Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Quanchai QC Series engine include?
Quanchai QC Series engine currently lists about 2 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Quanchai QC Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
