FAW Jiefang Hanwei(J5M) Heavy Truck 260hp 8X4(12 wheels) 6.7m Dump Truck
EXW
From $38,889
Export quote
FAW Jiefang Hanwei J5M Heavy Truck Dump Trucks
Main model photos
67 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| FAW Jiefang Hanwei(J5M) Heavy Truck 260hp 8X4(12 wheels) 6.7m Dump Truck | 8x4 / 260hp / China III / Euro III | From $38,889 | |
| FAW Jiefang Hanwei (J5M) heavy truck 280 hp 6X4(10 wheels) 6.2m dump truck (Dachai) | 6x4 / 280hp / China III / Euro III | From $34,028 | |
| FAW Jiefang Hanwei (J5M) heavy truck 280 hp 6X4(10 wheels) 6.2m dump truck (Xichai) | 6x4 / 280hp / China III / Euro III | From $41,389 | |
| FAW Jiefang Hanwei (J5M) heavy truck 260 hp 6X4(10 wheels) 6.2m dump truck (Dachai) | 6x4 / 260hp / China III / Euro III | From $31,944 | |
| FAW Jiefang Hanwei (J5M) heavy truck 260 hp 6X4(10 wheels) 6.4m dump truck (Xichai) | 6x4 / 260hp / China III / Euro III | From $39,583 |
FAW Jiefang Hanwei (J5M) heavy truck 280 hp 6X4(10 wheels) 6.2m dump truck (Dachai)
EXW
From $34,028
Export quote
FAW Jiefang Hanwei (J5M) heavy truck 280 hp 6X4(10 wheels) 6.2m dump truck (Xichai)
EXW
From $41,389
Export quote
FAW Jiefang Hanwei (J5M) heavy truck 260 hp 6X4(10 wheels) 6.2m dump truck (Dachai)
EXW
From $31,944
Export quote
FAW Jiefang Hanwei (J5M) heavy truck 260 hp 6X4(10 wheels) 6.4m dump truck (Xichai)
EXW
From $39,583
Export quote
Series Specs
Basic Info
Model code (announced): CA3313P7K1T4A1E / CA3253P7K1T1E / CA3313P7K1T4E / CA3253P7K2T1AE / CA3253P7K2T1
Drive type: 8X4 / 6X4
Wheelbase: 1900+3100+1350 / 4200+1350 / 1900+3650+1350 / 3400+1350 / 3800+1350mm
Engine Model: DachaiBF6M1013-26E3 / DachaiBF6M1013-28E3 / XichaiCA6DL1-28E3 / XichaiCA6DL1-26E3
Transmission Model: Fast Gear9JS119
Rear Axle Ratio: 5.286 / 5.833 / 5.73 / 5.83 / 4.111
Cab length: 9.59 / 8.9 / 9.1 / 10.09 / 7.4 / 8.2 / 8.3m
Cab width: 2.49 / 2.5m
Cab height: 3.56 / 3.2 / 3.3m
Front track width: 1928/1928 / 1928 / 2020 / 1914,1948mm
rear track: 1847/1847 / 1869/1869mm
Curb Weight: 14.765 / 12.48 / 14.9 / 12.3 / 12.05ton
Rated payload: 16.04 / 12.305 / 15.8 / 12.3 / 12.77ton
GVWR: 31 / 24.98 / 30.95 / 25 / 24.95ton
Origin: Changchun, Jilin
tonnage class: Heavy truck
Approach angle: 28°
departure angle: 25 / 17 / 31 / 20 / 36°
Remarks: Flat roof cab, Dachai Deutz 260PS engine, 9JS119 gearbox, rear axle 435, ratio 5.143, 11 nylon tires, Zhongji box 6.7*2.3*(1.25+0.25), D4B3, high-strength plate, lightweight cargo box, domestic front lift 180, anti-sway balance bracket, set beam, floor four longitudinal beams, wide tail flip seat, small five-opening door, rear door secondary lift / Corresponding vehicle length and box length: 8900mm corresponds to 6200mm, 9100mm corresponds to 6400mm. Engine net power values: BF6M1013-24E3 engine 177kW, BF6M1013-26E3 engine 192kW, BF6M1013-28E3 engine 206kW. CA6DF3-24E3, CA6DF3-24E3U engine 177kW, CA6DL1-26E3, CA6DL1-26E3U engine 192kW, CA6DL1-28E3, CA6DL1-28E3U engine 206kW / Optional high-top cab; dump method: rear dump; cargo box dimensions: 7000×2300×1150; 7200×2300×1100; 7500×2300×1100. Front/rear overhang (mm): 1375/1615, 1375/1815, 1375/2115. Engine net power: BF6M1013-24E3 177kW, BF6M1013-26E3 192kW, BF6M1013-28E3 206kW; VIN correspondence: LFNMVULW for BF6M1013-24E3, LFNMVUMW for BF6M1013-26E3 and BF6M1013-28E3. Optional high-top cab. Overall dimensions L×W×H (mm): 9890,10090,10390 ×2490 ×3200,3560. Cargo box dimensions L×W×H (mm): 7000,7200,7500 ×2300 ×1150,1100,1100. Approach/departure angle (°): 28/31,28/29,28/25. / Engine net power values: BF6M1013-24E3 177kW, BF6M1013-26E3 192kW, BF6M1013-28E3 206kW; VIN correspondence: LFNKRULJ corresponds to BF6M1013-24E3 engine, LFNKRUMJ corresponds to BF6M1013-26E3, BF6M1013-28E3 engines. Engine displacement 7146, 7146, 7146; / Engine power parameter is net power value, exterior acceleration noise meets (GB 1495-2002) Phase II standard requirements. Rated mass (kg): 12770, 12705
Energy Type: Diesel
Engine parameters
Engine Brand: Dachai / Xichai
Number of cylinders: 6cylinder
Displacement: 7.146 / 7.7L
Emission standard: China III / Euro III
Max output power: 192 / 206 / 191kW
Max hp: 260 / 280Horsepower
Max torque: 950 / 1050 / 1100N·m
Max torque speed: 1100-1400 / 1300-1700rpm
Rated speed: 2300rpm
Engine Type: 6-cylinder inline, direct injection, turbocharged intercooled, electronic unit pump / 6-cylinder inline, direct injection, turbocharged intercooled, electronic common rail / Inline, direct injection, electronically controlled common rail, turbocharged, intercooled, air-to-air intercooled
Transmission Parameters
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 9Gear
Number of Reverse Gears:
Cargo box parameters
Unloading Type: Rear-dump body / Dump type
Cargo box length: 6.7 / 6.2 / 6.4 / 7.5 / 4.8 / 5.6m
Cargo box width: 2.3 / 2.4m
Cargo box height: 1.25 / 1 / 1.1 / 1.3 / 1.2m
fuel tank
Fuel tank capacity: 300 / 200L
Chassis Specs
rear axle description: 457 / Diameter 457
FAQ
What kind of truck is FAW Jiefang FAW Jiefang Hanwei J5M Heavy Truck Dump Trucks?
FAW Jiefang FAW Jiefang Hanwei J5M Heavy Truck is an export-oriented Dump Trucks lineup with about 11 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for FAW Jiefang Hanwei J5M Heavy Truck Dump Trucks?
FAW Jiefang Hanwei J5M Heavy Truck Dump Trucks export reference is about $31,806 – $41,389. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does FAW Jiefang Hanwei J5M Heavy Truck Dump Trucks cover?
FAW Jiefang Hanwei J5M Heavy Truck Dump Trucks mainly covers: Drive: 6x4 / 8x4; Horsepower: 260 hp / 280 hp; Emission: China III / Euro III; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in FAW Jiefang Hanwei J5M Heavy Truck Dump Trucks?
For FAW Jiefang Hanwei J5M Heavy Truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does FAW Jiefang Hanwei J5M Heavy Truck Dump Trucks include?
FAW Jiefang Hanwei J5M Heavy Truck Dump Trucks currently lists about 11 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for FAW Jiefang Hanwei J5M Heavy Truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
