XCMG JAC Gallop Chassis truck-mounted crane

Main model photos

JAC Gallop A6L2 240 hp 6X4(10 wheels) Truck-mounted Crane Exterior

4 photos

Models

On sale

Model	Drive / HP / Emission	EXW
JAC Gallop A6L2 240 hp 6X4(10 wheels) Truck-mounted Crane	6x4 / 240hp / China V	From $59,028
JAC Gallop K5L 220hp 4X2(6 wheels) Truck Mounted Crane (XCMG Brand)	4x2 / 220hp / China V	From $37,222
JAC Gallop K5L 160hp 4X2(6 wheels) Truck Mounted Crane (XCMG Brand)	4x2 / 160hp / China V	From $36,806

JAC Gallop A6L2 240 hp 6X4(10 wheels) Truck-mounted Crane

6x4 240hp China V

EXW From $59,028

Export quote

Model details

JAC Gallop K5L 220hp 4X2(6 wheels) Truck Mounted Crane (XCMG Brand)

4x2 220hp China V

EXW From $37,222

Export quote

Model details

JAC Gallop K5L 160hp 4X2(6 wheels) Truck Mounted Crane (XCMG Brand)

4x2 160hp China V

EXW From $36,806

Export quote

Model details

Series Specs

Basic Info

Cab dimensions: 12×2.55×3.95 / 9×2.55×3.75m

Type: Truck with crane

Drive type: 6X4 / 4X2

Wheelbase: 5800+1350 / 5300mm

Rated mass: 9.805 / 7.905ton

GVWR: 25 / 18ton

Front/rear suspension: 1.4/3.45 / 1.4/2.3m

Energy Type: Diesel

Body Parameters

Other special notes: 7t straight-arm crane, 3-section arm, integrated slewing

Crane model: SPS25000

Lifting capacity: 10 / 6.3ton

crane self-weight: 4.1 / 2.85ton

Vehicle certification code: HFC5181JSQP3K1A47V

Body Brand: XCMG brand

Engine parameters

Injection System: Common Rail

Engine Brand: Yuchai / Yunnei Power / Weichai

Engine Model: YuchaiYC6JA240-50 / Yunnei PowerD45TCIE1 / WeichaiWP4.1Q160E50

Displacement: 6.87 / 4.46 / 4.088L

Emission standard: China V

Max output power: 177 / 162 / 115kW

Max hp: 240 / 220 / 160Horsepower

Max torque: 950 / 820 / 520N·m

Max torque speed: 1200-1800 / 1200-2800 / 1400-1800rpm

Rated speed: 2300 / 2400 / 2600rpm

Chassis Specs

Chassis Brand: JAC Gallop

Chassis Series: GallopA6L / GallopK5L

Chassis Model: HFC1251P3K3E43V / HFC5181XXYP3K1A47V

Frame Dimensions: 302×80×(8+4) / 280×75×(8+4)mm

rear axle description: 153 / 9t reinforced

Leaf spring count: 3/12,10/12 / 3/4+3,3/9+7,9/9+7

Transmission Parameters

Number of gears: 8Gear

Transmission Model: Fast Gear8JS105 / Fast Gear8JS85TC+QD40A / Fast Gear8JS75TC+QD40A

Cab parameters

Cab: K6L Semi-High Roof / K5L semi-high roof

Tire

Tire Size: 11.00R20 / 10.00R20,11R22.5

Number of tires: 10 / 6pcs

FAQ

What kind of truck is XCMG XCMG JAC Gallop Chassis truck-mounted crane?

XCMG XCMG JAC Gallop Chassis is an export-oriented truck-mounted crane lineup with about 3 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.

What is the export price range for XCMG JAC Gallop Chassis truck-mounted crane?

XCMG JAC Gallop Chassis truck-mounted crane export reference is about $36,806 – $59,028. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).

What spec range does XCMG JAC Gallop Chassis truck-mounted crane cover?

XCMG JAC Gallop Chassis truck-mounted crane mainly covers: Drive: 4x2 / 6x4; Horsepower: 160 hp / 220 hp / 240 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.

How do I choose a variant in XCMG JAC Gallop Chassis truck-mounted crane?

For XCMG JAC Gallop Chassis truck-mounted crane: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.

What is truck-mounted crane typically used for?

truck-mounted crane specs vary widely by job. Define the application first, then compare specs here and request a quote.

How many models does XCMG JAC Gallop Chassis truck-mounted crane include?

XCMG JAC Gallop Chassis truck-mounted crane currently lists about 3 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.

How do I request a quote for XCMG JAC Gallop Chassis truck-mounted crane?

Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
