SHACMAN Delong F3000 Standard Edition 336 hp 8X4(12 wheels) 5.41 m³ concrete mixer truck

Export reference
From $45,333
MSRP ¥32.64M CNY
Fuel: Diesel
Curb Weight:: 19ton
Wheelbase:: 1800+3575+1400mm
Tire Size:: 12.00R20
Cab dimensions:: 11.42×2.49×3.98m
Truck Type:: concrete mixer truck
Rated payload: 11.87ton
Drive 8X4 (12 wheels)
Horsepower 336
Emission China V

Overview

The SHACMAN Delong F3000 Standard Edition 336 hp 8X4(12 wheels) 5.41 m³ concrete mixer truck is a concrete mixer truck featuring 11.87t payload, 19ton GVW, 8X4 (12 wheels) drive and Mid-length flat roof cab (D) cab. On the powertrain side, it comes with 336 hp, China V emissions and Diesel fuel.

China V 336 Diesel 8X4

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Cab dimensions: 11.42×2.49×3.98m
Truck Type: concrete mixer truck
Drive type: 8X4
Vehicle origin: Xi'an, Shaanxi
Wheelbase: 1800+3575+1400mm
Front/rear track width: Front: 2036/2036mm; Rear: 1860/1860
Curb Weight: 19ton
Rated payload: 11.87ton
Max. speed: 80km/h
Front/rear suspension: 1.525/3.12m
Body Parameters
Mixing drum capacity: 5.41m³
Vehicle certification code: SX5310GJBFB386
Body Brand: SHACMAN
Others: Mid-length flat roof cab (D), cab hydraulic suspension, air driver seat, manual tilt, metal bumper, electronically controlled automatic constant temperature AC, power windows, engine PTO, standard air filter, domestic steering gear, domestic clutch, spare tire carrier, Tianxingjian Zhiya BD onboard terminal, 165Ah maintenance-free battery, domestic 4-channel ABS, reserved QF60 PTO switch and solenoid valve (normally closed) without QF60 PTO, engine PTO, aluminum alloy fuel tank, cruise control (i.e. local PTO engine constant speed control)
Engine parameters
Engine Model: WeichaiWP10.336E53
Number of cylinders: 6cylinder
fuel type: Diesel
Displacement: 9.726L
Emission standard: China V
Max output power: 247kW
Max hp: 336Horsepower
Rated speed: 1900rpm
Engine Type: Inline 6-cylinder, electronically controlled high-pressure common rail + SCR
Chassis Specs
Chassis Series: Delong F3000
Chassis Model: SX1310FB
Front axle description: 7.5T
Frame Dimensions: 850×300(8+5)mm
rear axle description: MAN 16T dual-reduction
Axle ratio: 5.262
Leaf spring count: 13/13/12, left 14 right 13/left 14 right 13/12
Transmission Parameters
Number of gears: 9Gear
Transmission Model: Fast Gear9JSD150
Cab parameters
Cab: Mid-length flat roof cab (D)
Tire
Tire Size: 12.00R20
Number of tires: 12pcs

Photos

Exterior1

1 photos

FAQ

What is the export price of SHACMAN Delong F3000 Standard Edition 336 hp 8X4(12 wheels) 5.41 m³ concrete mixer truck, and what does it include?

SHACMAN Delong F3000 Standard Edition 336 hp 8X4(12 wheels) 5.41 m³ concrete mixer truck export reference is about From $45,333; MSRP is ¥32.64M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does SHACMAN Delong F3000 Standard Edition 336 hp 8X4(12 wheels) 5.41 m³ concrete mixer truck use, and can it enter my country?

This model is listed as China V. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of SHACMAN Delong F3000 Standard Edition 336 hp 8X4(12 wheels) 5.41 m³ concrete mixer truck?

Key specs of SHACMAN Delong F3000 Standard Edition 336 hp 8X4(12 wheels) 5.41 m³ concrete mixer truck: Drive: 8x4; Horsepower: 336 hp; Emission: China V; Fuel: Diesel. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is SHACMAN Delong F3000 Standard Edition 336 hp 8X4(12 wheels) 5.41 m³ concrete mixer truck suited for?

SHACMAN Delong F3000 Standard Edition 336 hp 8X4(12 wheels) 5.41 m³ concrete mixer truck is a concrete mixer truck model often used on construction, mining and aggregate jobs. Check drive, horsepower and emission; state duty cycle and destination in your quote.

How does SHACMAN Delong F3000 Standard Edition 336 hp 8X4(12 wheels) 5.41 m³ concrete mixer truck differ from other variants in the same series?

SHACMAN Delong F3000 Standard Edition 336 hp 8X4(12 wheels) 5.41 m³ concrete mixer truck belongs to SHACMAN Delong F3000 Heavy Truck (concrete mixer truck). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for SHACMAN Delong F3000 Standard Edition 336 hp 8X4(12 wheels) 5.41 m³ concrete mixer truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export SHACMAN Delong F3000 Standard Edition 336 hp 8X4(12 wheels) 5.41 m³ concrete mixer truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
