SHACMAN New M3000 300 hp 8X4(12 wheels) Truck-Mounted Crane (Banjun Changxing Brand)

Export reference
From $41,722
MSRP ¥30.04M CNY
Emission: China V
Fuel: Diesel
Wheelbase:: 2100+4575+1400mm
Cab dimensions:: 12×2.55×3.98m
Type:: Truck with crane
GVWR:: 31ton
Lifting capacity: 14ton
Drive 8X4 (12 wheels)
Horsepower 300
Rated mass: 10.07ton

Overview

The Suizhou Changxing (Banjun Changxing) SHACMAN New M3000 300 hp 8X4(12 wheels) Truck-Mounted Crane (Banjun Changxing Brand) is a truck-mounted crane featuring 14ton tank capacity, 31t GVW and 8X4 (12 wheels) drive. On the powertrain side, it comes with 300 hp, China V emissions and Diesel fuel.

China V 300 Diesel 8X4

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Cab dimensions: 12×2.55×3.98m
Type: Truck with crane
Drive type: 8X4
Wheelbase: 2100+4575+1400mm
Rated mass: 10.07ton
GVWR: 31ton
Front/rear suspension: 1.525/2.4m
Energy Type: Diesel
Body Parameters
Crane model: SPS35000
Lifting capacity: 14ton
crane self-weight: 5.55ton
Vehicle certification code: AAA5319JSQSX6
Body Brand: Banjun Changxing
Engine parameters
Engine Brand: Weichai
Engine Model: WeichaiWP7.300E51
fuel type: Diesel
Displacement: 7.47L
Emission standard: China V
Max output power: 220kW
Max hp: 300Horsepower
Max torque: 1250N·m
Max torque speed: 1200-1700rpm
Rated speed: 2300rpm
Chassis Specs
Chassis Brand: SHACMAN
Chassis Series: New M3000
Chassis Model: SX1310MB6
Frame Dimensions: 866×308(8+5+8)mm
rear axle description: MAN 11.5T dual-reduction
Axle ratio: 4.111
Leaf spring count: Left 14 Right 13/Left 14 Right 13/12
Transmission Parameters
Number of gears: 9Gear
Transmission Model: Fast Gear9JS135
Tire
Tire Size: 12.00R20
Number of tires: 12pcs

Photos

Exterior1

1 photos

FAQ

What is the export price of SHACMAN New M3000 300 hp 8X4(12 wheels) Truck-Mounted Crane (Banjun Changxing Brand), and what does it include?

SHACMAN New M3000 300 hp 8X4(12 wheels) Truck-Mounted Crane (Banjun Changxing Brand) export reference is about From $41,722; MSRP is ¥30.04M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does SHACMAN New M3000 300 hp 8X4(12 wheels) Truck-Mounted Crane (Banjun Changxing Brand) use, and can it enter my country?

This model is listed as China V. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of SHACMAN New M3000 300 hp 8X4(12 wheels) Truck-Mounted Crane (Banjun Changxing Brand)?

Key specs of SHACMAN New M3000 300 hp 8X4(12 wheels) Truck-Mounted Crane (Banjun Changxing Brand): Drive: 8x4; Horsepower: 300 hp; Emission: China V; Fuel: Diesel. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is SHACMAN New M3000 300 hp 8X4(12 wheels) Truck-Mounted Crane (Banjun Changxing Brand) suited for?

SHACMAN New M3000 300 hp 8X4(12 wheels) Truck-Mounted Crane (Banjun Changxing Brand) is a truck-mounted crane model; configuration should match the job. State the application, emission and LHD/RHD needs in your quote.

How does SHACMAN New M3000 300 hp 8X4(12 wheels) Truck-Mounted Crane (Banjun Changxing Brand) differ from other variants in the same series?

SHACMAN New M3000 300 hp 8X4(12 wheels) Truck-Mounted Crane (Banjun Changxing Brand) belongs to Suizhou Changxing (Banjun Changxing) SHACMAN Chassis (truck-mounted crane). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for SHACMAN New M3000 300 hp 8X4(12 wheels) Truck-Mounted Crane (Banjun Changxing Brand)?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export SHACMAN New M3000 300 hp 8X4(12 wheels) Truck-Mounted Crane (Banjun Changxing Brand)?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
