Dongfeng 17Q68-00030 (DF5S470 Series) 5-Speed Manual Transmission

Export reference
MSRP N/A
Features:: Inertia lock-pin synchronizer for 2nd/3rd and 4th/5th gears, with clutch release bearing housing assembly and parking brake
Max input torque:: 470N·m
1st gear ratio:: 4.763
Dongfeng 17Q68-00030 (DF5S470 Series) 5-Speed Manual Transmission exterior
View more photos (1)
Transmission Model: Dongfeng 17Q68-00030 (DF5S470 Series)
Transmission Brand: Dongfeng
Matching Range: Engine: NND6102 | Compatible models: EQ1068G2D2

Overview

The Dongfeng 17Q68-00030 (DF5S470 Series) 5-Speed Manual Transmission is a parts product with spec Dongfeng 17Q68-00030 (DF5S470 Series).

Model Specs

Legend: ● Standard　○ Optional　- N/A

Transmission Parameters
Transmission Brand: Dongfeng
Transmission series: DF5S series
Matching Range: Engine: NND6102 | Compatible models: EQ1068G2D2
Features: Inertia lock-pin synchronizer for 2nd/3rd and 4th/5th gears, with clutch release bearing housing assembly and parking brake
Max input torque: 470N·m
1st gear ratio: 4.763
synchronizer: Yes
Main box center distance: 121.125mm
2nd gear ratio: 2.808
3rd gear ratio: 1.594
4th gear ratio:
5th gear ratio: 0.756
Reverse Gear 1 Ratio: 4.99
Transmission weight: 122kg
Transmission oil capacity: 5.5L
Odometer drive ratio: 3.25
Control type: Remote Control
Number of gears: 5Gear
shift type: Manual
Transmission Model: Dongfeng 17Q68-00030 (DF5S470 Series)
shift method: Manual
Forward gears: 5Gear
Number of Reverse Gears:

Photos

Exterior1

Dongfeng 17Q68-00030 (DF5S470 Series) 5-Speed Manual Transmission Exterior (1) | 86Trucks

1 photos

FAQ

What transport jobs is Dongfeng 17Q68-00030 (DF5S470 Series) 5-Speed Manual Transmission suited for?

Match Dongfeng 17Q68-00030 (DF5S470 Series) 5-Speed Manual Transmission to your job using drive, horsepower and emission on this page. Include use case, destination and quantity in your quote request.

How does Dongfeng 17Q68-00030 (DF5S470 Series) 5-Speed Manual Transmission differ from other variants in the same series?

Dongfeng 17Q68-00030 (DF5S470 Series) 5-Speed Manual Transmission belongs to Dongfeng DF5S Series (transmission). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Dongfeng 17Q68-00030 (DF5S470 Series) 5-Speed Manual Transmission?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Dongfeng 17Q68-00030 (DF5S470 Series) 5-Speed Manual Transmission?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
