Dongfeng 17DS5B-00030(DF5S360 Series) 5-Speed Manual Transmission
EXW
Export quote
Dongfeng DF5S Series transmission
Main model photos
5 photos
Models
On sale
Dongfeng 17DY4-00030(DF5S410 Series) 5-Speed Manual Transmission
EXW
Export quote
Dongfeng 17Q56-00030(DF5S410 Series) 5-Speed Manual Transmission
EXW
Export quote
Dongfeng DF5S1050 5-speed manual transmission
EXW
Export quote
Dongfeng 17DS5-00030 (DF5S360 Series) 5-Speed Manual Transmission
EXW
Export quote
Series Specs
Transmission Parameters
Transmission Brand: Dongfeng
Transmission series: DF5S series
Matching Range: Available engine: EQ6100-1 gasoline engine, etc. Applicable model: Medium bus / Engine: EQD6102 | Compatible models: Yangzhou midibus / Engine: Cummins 4BT | Compatible models: midibus / Available engine: EQ6100-1 gasoline engine, etc. Applicable model: Medium bus Oil capacity: 5L / Engine: Dachai 6110 diesel | Compatible models: city bus / Available engine: CA4113Z / Available engine: Yuchai, Chaochai6105 diesel Applicable model: EQ1092F19D series / Available engine: EQ6100-1 gasoline engine, etc. Applicable model: EQ1092F / Available engine: EQ6100-1 gasoline engine, etc. Applicable model: EQ1092F series / Available engine: EQ6100-1 dual-fuel gasoline engine, etc. Applicable model: EQ1092F series / Available engine: Cummins6BT etc. Applicable model: EQ1108G / Available engine: Cummins6BT diesel Applicable model: EQ1108G6D1 / Engine: Cummins 6105 diesel | Compatible models: EQ1108G8D1 / Engine: NND6102 | Compatible models: EQ1068G2D2 / Engine: Cummins 4BTAA | Compatible models: EQ1061G5D2/EQ1061TSD2 series / Engine: EQD6102 diesel | Compatible models: EQ1061G2D2 series / Engine: Cummins 4BT | Compatible models: EQ1061T5D2 series / Engine: EQD6102 | Compatible models: EQ1061G2D2 series / Engine: A. Yuchai YC4112ZQ, YC4110ZLQ series diesel engines (100-110 kW / 136-150 hp) / Available engines: A. Yuchai YC4112ZQ, YC4110ZLQ-series diesel engine (100-110 kW / 136-150 hp) / Engine: Chaoyang 4102 diesel | Compatible models: EQ1061T2
Features: Features: 2nd, 3rd, 4th, and 5th gears use inertia lock-pin synchronizer; With hand brake and clutch release bearing carrier; With reverse gear switch; Indirect control. / Features: 2nd, 3rd, 4th, and 5th gears use inertia lock-pin synchronizer; With release bearing carrier and hand brake assembly; Remote control. / Features: 2nd, 3rd, 4th, and 5th gears use inertia lock-pin synchronizer; With hand brake; With rear suspension left/right brackets; Remote control. / Features: 2nd, 3rd, 4th, and 5th gears use inertia lock-pin synchronizer; With hand brake and clutch release bearing carrier; Speedometer output shaft; With reverse gear switch. / Inertia lock-pin synchronizer for 2nd/3rd and 4th/5th gears, 1st/reverse gear shifted via sliding gear sleeve, without top cover, with reverse switch. / Features: 2nd, 3rd, 4th, and 5th gears use inertia lock-pin synchronizer; 1st and reverse gears use sliding gear sleeve shifting; Without top cover; With reverse gear switch. / Features: 2nd, 3rd, 4th, and 5th gears use inertia lock-pin synchronizer; 1st and reverse gears use sliding gear sleeve / Inertia lock-pin synchronizer for 2nd/3rd and 4th/5th gears, 1st/reverse gear shifted via sliding gear sleeve, with reverse switch, direct control. / Inertia lock-pin synchronizer for 2nd/3rd and 4th/5th gears, with parking brake and clutch release bearing housing, speedometer output shaft, reverse switch, direct control. / Inertia lock-pin synchronizer for 2nd/3rd and 4th/5th gears, with parking brake and clutch release bearing housing, speedometer output shaft, reverse switch, direct control / 2nd/3rd and 4th/5th gear with inertia-type synchronizer, without hand brake, with neutral/reverse switch, direct control / Inertia lock-pin synchronizer for 2nd/3rd and 4th/5th gears, 1st/reverse gear shifted via sliding gear sleeve, with parking brake and clutch housing, reverse switch, cable control / Inertia lock-pin synchronizer for 2nd/3rd and 4th/5th gears, 1st/reverse gear shifted via sliding sleeve, with parking brake, clutch housing and clutch release bearing housing, remote control, with neutral/reverse switch. / Inertia lock-pin synchronizer for 2nd/3rd and 4th/5th gears, 1st/reverse gear shifted via sliding sleeve, with parking brake and clutch release bearing housing, remote control. / Inertia lock-pin synchronizer for 2nd/3rd and 4th/5th gears, with clutch release bearing housing assembly and parking brake / Inertia lock-pin synchronizer for 2nd/3rd and 4th/5th gears, with parking brake, clutch system and rear mount bracket, remote control / 2nd/3rd and 4th/5th gear inertia lock-pin synchronizer and clutch release bearing housing, remote control / 2nd/3rd and 4th/5th gear with inertia lock-pin synchronizer, with engine rear support bracket, with hand brake / Inertia lock-pin synchronizer for 2nd/3rd and 4th/5th gears, with clutch release bearing housing assembly, parking brake, remote control / Auxiliary box ratio 1.66, overall length: 700mm / With auxiliary ratio 1.37 / 1. Main box inherits the excellent quality of Dongfeng 5-speed series transmission; 2. Auxiliary box uses single-stage gear reduction, pneumatic shifting; 3. Auxiliary box can be installed with pendant or bracket mount, convenient and feasible; 4. Integrated design of shift top cover and auxiliary box housing, simple structure; 5. Short axial length of transmission assembly, easy for vehicle layout; / 2nd/3rd gear with inertia lock-pin synchronizer, 4th/5th gear with inertia slider-type synchronizer, 1st/reverse gear with sliding gear sleeve
Max input torque: 360 / 410 / 470 / 430 / 430-550 / 294N·m
1st gear ratio: 7.31 / 4.76 / 6.3 / 4.763 / 5.713 / 6.802 / 4.711
synchronizer: No synchronizer / Yes
Main box center distance: 121.125 / 121 / 100mm
2nd gear ratio: 4.31 / 2.81 / 3.71 / 2.808 / 3.368 / 3.767 / 2.609
3rd gear ratio: 2.45 / 1.59 / 2.11 / 1.594 / 2.192 / 2.186 / 1.514
4th gear ratio: 1.54 / 1 / 1.32 / 1.466 / 1.424
5th gear ratio: 1 / 0.81 / 0.76 / 0.756 / 0.788
Reverse Gear 1 Ratio: 7.66 / 4.99 / 6.9 / 4.19 / 5.98 / 5.985 / 6.6 / 6.154 / 4.263
Transmission weight: 112 / 125 / 122 / 135 / 190 / 100kg
Transmission oil capacity: 5 / 5.5 / 3.5L
Odometer drive ratio: 10/3 / 3.67 / 12/4 / 13/4 / 12/5 / 3.25
Control type: direct control / Remote Control
Number of gears: 5Gear
shift type: Manual
Transmission Model: Dongfeng 17DS5B-00030 (DF5S360 series) / Dongfeng 17DY4-00030 (DF5S410 series) / Dongfeng 17Q56-00030 (DF5S410 Series) / Dongfeng DF5S1050 / Dongfeng 17DS5-00030 (DF5S360 series) / Dongfeng 17GK1-00030 (DF5S470 series) / Dongfeng 17GK-00030 (DF5S470 series) / Dongfeng 17JL5-000309 (DF5S470 series) / Dongfeng 17D45-00030 (DF5S470 series) / Dongfeng 17D-00030 (DF5S360 series) / Dongfeng 17D4-00030-B (DF5S360 series) / Dongfeng 17GOA1-48 (DF5S360 series) / Dongfeng 17.6B-00030 (DF5S470 series) / Dongfeng 17.6B1-00030 (DF5S470 series) / Dongfeng 17B13-00030 (DF5S470 series) / Dongfeng 17Q68-00030 (DF5S470 Series) / Dongfeng 17Q01-00030 (DF5S410 Series) / Dongfeng 17Q37-00030 (DF5S410 Series) / Dongfeng 17Q13-00030 (DF5S410 Series) / Dongfeng 17Q50-00030 (DF5S410 Series) / Dongfeng 17BJ25-00030 (DF5S550 series) overdrive / Dongfeng 17BJ25-00030B / Dongfeng 17BJ25-00030 (DF5S550 series) direct gear / Dongfeng 17Q08-00030 (DF5S300 Series) / Dongfeng 17BQ08-00030
shift method: Manual
Forward gears: 5Gear
Number of Reverse Gears:
FAQ
What kind of truck is Dongfeng Dongfeng DF5S Series transmission?
Dongfeng Dongfeng DF5S Series is an export-oriented transmission lineup with about 25 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is transmission typically used for?
For transmission, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Dongfeng DF5S Series transmission include?
Dongfeng DF5S Series transmission currently lists about 25 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Dongfeng DF5S Series transmission?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
