Fast Gear 16-Speed Series transmission
Main model photos
23 photos
Models
On sale
Fast Gear C16JSDQXL280TA 16-speed Manual Transmission
EXW
Export quote
Fast Gear 16JSDX220TA 16-speed manual transmission
EXW
Export quote
Fast Gear 16JSDX220T 16-speed manual transmission
EXW
Export quote
Fast Gear 16JSDX200T 16-Speed Manual Transmission
EXW
Export quote
Series Specs
Transmission Parameters
Transmission Brand: Fast Gear
Transmission series: 16-speed series
Features: Full synchronizer overdrive / 1. Three-section, 2x4x2 configuration; 2. Full aluminum alloy die-cast housing, lightweight, high torque-to-weight ratio; 3. Front auxiliary box, main box, and rear auxiliary box all use twin countershaft design; 4. Full helical, fine-pitch, and barrel-shaped gear design, fully ground gears for low transmission noise; 5. Wide speed ratio range, adaptable to various working conditions, strong climbing ability; 6. Small speed ratio steps for good fuel economy; 7. Compatible with pneumatic shift assist; 8. Forced lubrication system to improve transmission lubrication; 9. Reserved external cooler interface for improved cooling under special conditions; reserved through-shaft PTO interface for expansion design; 10. Main and auxiliary box interlock structure for improved auxiliary box synchronizer reliability. / Overdrive / 1. Full aluminum alloy housing design reduces weight by over 110 kg, improving fuel economy. 2. Main box with front and rear auxiliary box combination, large center distance design significantly improves auxiliary box strength and life, high transmission efficiency. 3. Twin countershafts, power split, unique structure. 4. Full synchronizer, smooth and flexible shifting; main box: double-cone lock-ring synchronizer with large synchronization capacity; front auxiliary box: single-cone lock-ring synchronizer; rear auxiliary box: enhanced lock-pin synchronizer; friction cones use high-performance non-metallic friction material for reliability. 5. Fine-pitch gear design for smooth meshing and low noise. 6. Well-arranged gear steps with small ratio steps for good fuel economy; multiple PTO options; 7. Full synchronizer overdrive gear. / 1. Full aluminum alloy housing design reduces weight by over 110 kg, improving fuel economy. 2. Main box with front and rear auxiliary box combination, large center distance design significantly improves auxiliary box strength and life, high transmission efficiency. 3. Twin countershafts, power split, unique structure. 4. Full synchronizer, smooth and flexible shifting; main box: double-cone lock-ring synchronizer with large synchronization capacity; front auxiliary box: single-cone lock-ring synchronizer; rear auxiliary box: enhanced lock-pin synchronizer; friction cones use high-performance non-metallic friction material for reliability. 5. Fine-pitch gear design for smooth meshing and low noise. 6. Well-arranged gear steps with small ratio steps for good fuel economy; multiple PTO options.
Matching Range: Series transmission assembly suitable for cargo trucks, tractor trucks, truck cranes, and various special vehicles
Max input torque: 2800 / 2200 / 2000 / 2600 / 2400 / 1800 / 3000 / 2500 / 1680 / 1500N·m
1st gear ratio: 14.563 / 14.129 / 13.748 / 16.693 / 14.13 / 17.02 / 14.56 / 17.09 / 13.7 / 17.04 / 14.03 / 17.13
synchronizer: Yes
2nd gear ratio: 12.105 / 11.703 / 11.402 / 13.748 / 11.7 / 14.02 / 12.11 / 14.13 / 11.36 / 14.03 / 11.64 / 14.1
3rd gear ratio: 10.066 / 9.766 / 9.399 / 11.413 / 9.77 / 11.65 / 10.07 / 11.82 / 9.37 / 11.66 / 9.6 / 11.72
4th gear ratio: 8.367 / 8.089 / 7.795 / 9.399 / 8.09 / 9.6 / 8.37 / 9.77 / 7.77 / 7.97 / 9.65
5th gear ratio: 7.093 / 6.685 / 6.49 / 7.88 / 6.69 / 8.04 / 7.09 / 8.09 / 6.47 / 6.64 / 6.62 / 8.06 / 8.08
6th gear ratio: 5.896 / 5.537 / 5.382 / 6.49 / 5.54 / 6.62 / 5.9 / 6.69 / 5.36 / 5.51 / 5.49 / 6.64 / 6.66
7th gear ratio: 4.993 / 4.521 / 4.462 / 5.418 / 4.52 / 5.52 / 4.99 / 5.47 / 4.45 / 5.53 / 4.55 / 5.56
8th gear ratio: 4.15 / 3.745 / 3.7 / 4.462 / 3.74 / 4.55 / 4.52 / 3.69 / 3.78 / 4.58
Reverse Gear 1 Ratio: 13.398 / 12.999 / 13.15 / 15.968 / 13 / 16.28 / 13.4 / 15.73 / 13.11 / 16.3 / 13.42 / 16.38
Transmission weight: 308 / 393/288 (aluminum) / 291 / 365 / 405/300 (aluminum) / 439 / 437 / 350 / 342 / 270 / 355 / 392kg
9th gear ratio: 3.509 / 3.125 / 3.081 / 3.742 / 3.13 / 3.74 / 3.51 / 3.78 / 3.08
Transmission oil capacity: 15 / 16.5 / 17 / 20.8 / 19 / 21L
10-speed gear ratio: 2.917 / 2.588 / 2.556 / 3.081 / 2.59 / 3.08 / 2.92 / 3.13 / 2.56
11-speed gear ratio: 2.425 / 2.16 / 2.107 / 2.558 / 2.56 / 2.43 / 2.61 / 2.11
12-speed gear ratio: 2.016 / 1.789 / 1.747 / 2.107 / 1.79 / 2.11 / 2.02 / 2.16 / 1.75
13-speed gear ratio: 1.709 / 1.479 / 1.455 / 1.747 / 1.48 / 1.77 / 1.71 / 1.79 / 1.45 / 1.46
14-speed gear ratio: 1.421 / 1.225 / 1.206 / 1.455 / 1.22 / 1.45 / 1.42 / 1.48 / 1.21 / 1.46
15-speed gear ratio: 1.203 / 1 / 1.214 / 1.21 / 1.2
16-speed gear ratio: 1 / 0.828 / 0.829 / 0.83
Reverse Gear 2 Ratio: 11.137 / 10.767 / 10.906 / 13.15 / 10.77 / 13.41 / 11.14 / 13 / 10.87 / 13.42 / 11.13 / 13.49
Reverse Gear 3 Ratio: 3.228 / 2.875 / 2.88 / 3.23 / 3.48
Control type: Supports single-H and dual-H operation modes; single and dual levers integrated in one control.
Reverse Gear 4 Ratio: 2.683 / 2.381 / 2.38 / 2.68 / 2.88
Number of gears: 16Gear
shift type: Manual
Transmission Model: C16JSDQXL280T / C16JSDQXL280TA / 16JSDX220TA / 16JSDX220T / 16JSDX200T / C16JSDQXL260TA / C16JSDQXL240TA / 16JZSD240 / C16JSDQXL260T / C16JSDQXL240T / C16JSDQXL180TA / C16JSDQXL180T / 16JSDX240TA / 16JSDX240T / 16JSX300A / 16JS260T / 16JSDX200TA / 16JSD220TA / 16JS220TA / 16JSD220T / 16JS220T / C16JSDQXL220TA / C16JSDQXL220T / C16JSDQXL250TA / 16JS200 / C16JSDQXL200TA / C16JSDQXL200T / 16JS168T / 16JS160TA / 16JS160T / 16JS168TA / 16JSD240TA / 16JSD200TA / 16JSD180TA / 16JSD150TA / 16JSD240T / 16JSD200T / 16JSD180T / 16JSD150T / 16JSS300T / 16JS240TA / 16JS240T / 16JS200TA / 16JS200T / 16JS180TA / 16JS180T
shift method: Manual
Forward gears: 16Gear
Number of Reverse Gears: 4 / 2pcs
