Meizhou HZM12010 trailer axle

Export reference

MSRP N/A

Application Scope:: For leaf spring suspension

Applicable Tire:: 11.0-20；12.0-20；11R20/22.5;12R20

Front/rear track width:: 1820mm

View more photos (1)

Axle Model: Meizhou HZM12010

Brake size: Brake chamber center distance: 417mm

Axle Type: Trailer axle

Overview

The BPW Meizhou HZM12010 trailer axle is a parts product with spec Meizhou HZM12010 and Brake chamber center distance: 417mm size.

Model Specs

Legend: ● Standard　○ Optional　- N/A

Basic Info

Axle Model: Meizhou HZM12010

Axle Type: Trailer axle

Application Scope: For leaf spring suspension

Applicable Tire: 11.0-20；12.0-20；11R20/22.5;12R20

Front/rear track width: 1820mm

Rated axle load: 12000ton

Brake: SN4218

Brake size: Brake chamber center distance: 417mm

curb weight: 355kg

Rim Used: 20/22.5inch

Wheel Bolts: 10XM22X1.5mm

Remarks: 1. Integrated axle hub cap, easy to install and remove, convenient for maintenance, also serves as oil reservoir. 2. High load capacity, long life, low rolling resistance bearings, compact and lightweight structure. 3. Axle designed with 1° camber for better tire load distribution. 4. Special lubricant maintains good film uniformity and lubrication effect under all climate conditions. 5. Bearing seal uses floating oil slinger ring design for easy installation and reliable sealing. 6. Soft non-asbestos long-life brake linings provide smooth braking, high friction, and good thermal stability. 7. Bayonet connection between brake shoe and anchor pin for easy installation, automatic compensation, and quick release. 8. Locally reinforced square axle beam with high torsional and bending section modulus for strong torsional and bending resistance.

Photos

Exterior1

1 photos

FAQ

What transport jobs is Meizhou HZM12010 trailer axle suited for?

Match Meizhou HZM12010 trailer axle to your job using drive, horsepower and emission on this page. Include use case, destination and quantity in your quote request.

How does Meizhou HZM12010 trailer axle differ from other variants in the same series?

Meizhou HZM12010 trailer axle belongs to BPW Trailer Axle (axle). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Meizhou HZM12010 trailer axle?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Meizhou HZM12010 trailer axle?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
