SAIC Hongyan Genlyon C500 450hp 8X4(12 wheels) truck-mounted crane

Export reference
From $84,444
MSRP ¥60.8M CNY
Emission: China V
Fuel: Diesel
Wheelbase:: 2025+4375+1400mm
Cab dimensions:: 11.98×2.55×3.89m
Type:: Truck with crane
GVWR:: 31ton
Lifting capacity: 16ton
Drive 8X4 (12 wheels)
Horsepower 450
Rated mass: 11.43ton

Overview

The SAIC Hongyan Genlyon C500 450hp 8X4(12 wheels) truck-mounted crane is a truck-mounted crane featuring 16ton tank capacity, 31t GVW and 8X4 (12 wheels) drive. On the powertrain side, it comes with 450 hp, China V emissions and Diesel fuel.

China V 450 Diesel 8X4

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Cab dimensions: 11.98×2.55×3.89m
Type: Truck with crane
Drive type: 8X4
Wheelbase: 2025+4375+1400mm
Rated mass: 11.43ton
GVWR: 31ton
Front/rear suspension: 1.435/3.745m
Energy Type: Diesel
Body Parameters
Crane model: SQS400
Lifting capacity: 16ton
crane self-weight: 6.455ton
Vehicle certification code: CQ5316JSQHTVG466
Body Brand: SAIC Hongyan
Engine parameters
Engine Brand: SAIC Fiat Powertrain Hongyan
Engine Model: SAIC Fiat Powertrain HongyanF3GCE611A*L
fuel type: Diesel
Displacement: 11.12L
Emission standard: China V
Max output power: 327kW
Max hp: 450Horsepower
Max torque: 2100N·m
Max torque speed: 1100-1500rpm
Rated speed: 1900rpm
Chassis Specs
Chassis Brand: SAIC Hongyan
Chassis Series: GENLYON
Chassis Model: CQ1316HTVG39-486
rear axle description: 16T Hande axle
Axle ratio: 5.262
Leaf spring count: 3/3/4,3/3/6,9/9/12,5/5/6,3/3/12
Transmission Parameters
Number of gears: 12Gear
Transmission Model: Fast Gear12JSD220TA
Cab parameters
Cab: Flat roof
Tire
Tire Size: 11.00R20
Number of tires: 12pcs

Photos

Exterior1

1 photos

FAQ

What is the export price of SAIC Hongyan Genlyon C500 450hp 8X4(12 wheels) truck-mounted crane, and what does it include?

SAIC Hongyan Genlyon C500 450hp 8X4(12 wheels) truck-mounted crane export reference is about From $84,444; MSRP is ¥60.8M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does SAIC Hongyan Genlyon C500 450hp 8X4(12 wheels) truck-mounted crane use, and can it enter my country?

This model is listed as China V. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of SAIC Hongyan Genlyon C500 450hp 8X4(12 wheels) truck-mounted crane?

Key specs of SAIC Hongyan Genlyon C500 450hp 8X4(12 wheels) truck-mounted crane: Drive: 8x4; Horsepower: 450 hp; Emission: China V; Fuel: Diesel. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is SAIC Hongyan Genlyon C500 450hp 8X4(12 wheels) truck-mounted crane suited for?

SAIC Hongyan Genlyon C500 450hp 8X4(12 wheels) truck-mounted crane is a truck-mounted crane model; configuration should match the job. State the application, emission and LHD/RHD needs in your quote.

How does SAIC Hongyan Genlyon C500 450hp 8X4(12 wheels) truck-mounted crane differ from other variants in the same series?

SAIC Hongyan Genlyon C500 450hp 8X4(12 wheels) truck-mounted crane belongs to SAIC Hongyan Genlyon Heavy Truck (truck-mounted crane). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for SAIC Hongyan Genlyon C500 450hp 8X4(12 wheels) truck-mounted crane?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export SAIC Hongyan Genlyon C500 450hp 8X4(12 wheels) truck-mounted crane?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
