Yuejin Kaituo X500 129hp 4X2(6 wheels) 3.8m truck-mounted crane

Export reference
From $19,444
MSRP ¥14M CNY
Emission: China V
Fuel: Diesel
Wheelbase:: 3300mm
Cab dimensions:: 5.995X2.18X2.5m
Type:: Truck with crane
GVWR:: 4.388ton
Lifting capacity: 0.4ton
Drive 4X2 (6 wheels)
Horsepower 129
Rated mass: 0.693ton

Overview

The Yuejin Kaituo X500 129hp 4X2(6 wheels) 3.8m truck-mounted crane is a truck-mounted crane featuring 0.4ton tank capacity, 4.388t GVW and 4X2 (6 wheels) drive. On the powertrain side, it comes with 129 hp, China V emissions and Diesel fuel.

China V 129 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Cab dimensions: 5.995X2.18X2.5m
Type: Truck with crane
Drive type: 4X2
Wheelbase: 3300mm
Rated mass: 0.693ton
GVWR: 4.388ton
Front/rear suspension: 1.09/1.605m
Energy Type: Diesel
Body Parameters
Crane model: HY500
Lifting capacity: 0.4ton
crane self-weight: 1.003ton
Vehicle certification code: SH5042JSQVEDBNW
Body Brand: Yuejin
Engine parameters
Engine Brand: Yunnei Power
Engine Model: Yunnei PowerYN38CRE1
fuel type: Diesel
Displacement: 3.76L
Emission standard: China V
Max output power: 95kW
Max hp: 129Horsepower
Max torque: 365N·m
Max torque speed: 1600-2400rpm
Rated speed: 3000rpm
Chassis Specs
Chassis Brand: Yuejin
Chassis Series: Kaituo X500
Chassis Model: SH1042VEDBNW
Leaf spring count: 8/10+6
Transmission Parameters
Number of gears: 8Gear
Transmission Model: Changtai 8T50C
Tire
Tire Size: 8.25R16 6PR
Number of tires: 6pcs

Photos

Exterior1

1 photos

FAQ

What is the export price of Yuejin Kaituo X500 129hp 4X2(6 wheels) 3.8m truck-mounted crane, and what does it include?

Yuejin Kaituo X500 129hp 4X2(6 wheels) 3.8m truck-mounted crane export reference is about From $19,444; MSRP is ¥14M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does Yuejin Kaituo X500 129hp 4X2(6 wheels) 3.8m truck-mounted crane use, and can it enter my country?

This model is listed as China V. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Yuejin Kaituo X500 129hp 4X2(6 wheels) 3.8m truck-mounted crane?

Key specs of Yuejin Kaituo X500 129hp 4X2(6 wheels) 3.8m truck-mounted crane: Drive: 4x2; Horsepower: 129 hp; Emission: China V; Fuel: Diesel. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Yuejin Kaituo X500 129hp 4X2(6 wheels) 3.8m truck-mounted crane suited for?

Yuejin Kaituo X500 129hp 4X2(6 wheels) 3.8m truck-mounted crane is a truck-mounted crane model; configuration should match the job. State the application, emission and LHD/RHD needs in your quote.

How does Yuejin Kaituo X500 129hp 4X2(6 wheels) 3.8m truck-mounted crane differ from other variants in the same series?

Yuejin Kaituo X500 129hp 4X2(6 wheels) 3.8m truck-mounted crane belongs to Yuejin Kaituo X500 Light-duty Truck (truck-mounted crane). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Yuejin Kaituo X500 129hp 4X2(6 wheels) 3.8m truck-mounted crane?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Yuejin Kaituo X500 129hp 4X2(6 wheels) 3.8m truck-mounted crane?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
