Dongfeng F5 220hp 6X2(8 wheels) Concrete Mixer Truck

Export reference
MSRP N/A
Fuel: Diesel
Curb Weight:: 9.62ton
Wheelbase:: 1750+2400mm
Tire Size:: 10.00R20 18PR
Cab dimensions:: 8.35×2.5×3.99m
Truck Type:: Concrete mixer truck
Rated payload: 14.75ton
Drive 6X2 (8 wheels)
Horsepower 220
Emission China V

Overview

The Dongfeng F5 220hp 6X2(8 wheels) Concrete Mixer Truck is a concrete mixer truck featuring 14.75t payload, 9.62ton GVW, 6X2 (8 wheels) drive and 8.35×2.5×3.99m cab. On the powertrain side, it comes with 220 hp, China V emissions and Diesel fuel.

China V 220 Diesel 6X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Cab dimensions: 8.35×2.5×3.99m
Drive type: 6X2
Truck Type: Concrete mixer truck
Front/rear track width: Front track: 1910/1910mm; Rear track: 1860mm
Wheelbase: 1750+2400mm
Vehicle origin: Wuhan, Hubei
Curb Weight: 9.62ton
Rated payload: 14.75ton
Max. speed: 88km/h
Front/rear suspension: 1.45/2.55m
Body Parameters
Mixing drum capacity: 5.98m³
Vehicle certification code: EQ5250GJBLV2
Body Brand: Dongfeng
Engine parameters
Engine Model: YuchaiYC4EG220-50
Number of cylinders: 4cylinder
fuel type: Diesel
Displacement: 4.73L
Emission standard: China V
Max output power: 160kW
Max hp: 220Horsepower
Rated speed: 2500rpm
Engine Type: Vertical, inline, water-cooled, four-stroke, high-pressure common rail
Chassis Specs
Chassis Series: Huashen F5
Chassis Model: EQ5250GJBLVJ
Leaf spring count: 10/10/12+9
Tire
Tire Size: 10.00R20 18PR
Number of tires: 8pcs

Photos

Exterior1

1 photos

FAQ

What emission standard does Dongfeng F5 220hp 6X2(8 wheels) Concrete Mixer Truck use, and can it enter my country?

This model is listed as China V. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Dongfeng F5 220hp 6X2(8 wheels) Concrete Mixer Truck?

Key specs of Dongfeng F5 220hp 6X2(8 wheels) Concrete Mixer Truck: Drive: 6x2; Horsepower: 220 hp; Emission: China V; Fuel: Diesel. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Dongfeng F5 220hp 6X2(8 wheels) Concrete Mixer Truck suited for?

Dongfeng F5 220hp 6X2(8 wheels) Concrete Mixer Truck is a concrete mixer truck model often used on construction, mining and aggregate jobs. Check drive, horsepower and emission; state duty cycle and destination in your quote.

How does Dongfeng F5 220hp 6X2(8 wheels) Concrete Mixer Truck differ from other variants in the same series?

Dongfeng F5 220hp 6X2(8 wheels) Concrete Mixer Truck belongs to Dongfeng F5 heavy truck (concrete mixer truck). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Dongfeng F5 220hp 6X2(8 wheels) Concrete Mixer Truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Dongfeng F5 220hp 6X2(8 wheels) Concrete Mixer Truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
