Sinotruk Sitrak G5 350hp 8X4(12 wheels) 7.75m³ Concrete Mixer Truck (Yate Heavy Industry Brand)
EXW
Export quote
Yate Heavy Industry Sitrak Chassis concrete mixer
Main model photos
14 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Sinotruk Sitrak G5 350hp 8X4(12 wheels) 7.75m³ Concrete Mixer Truck (Yate Heavy Industry Brand) | 8x4 / 350hp / China V | ||
| Sinotruk SITRAK C5H 340 hp 8X4(12 wheels) 7.75 m³ concrete mixer truck (Yate Heavy Industry brand) | 8x4 / 340hp / China V | ||
| Sinotruk SITRAK C5H 340 hp 8X4(12 wheels) 8 m³ concrete mixer truck (Yate Heavy Industry brand) | 8x4 / 340hp / China V |
Series Specs
Basic Info
Cab dimensions: 10.15×2.55×3.995 / 10.28×2.55×3.98 / 10.11×2.55×3.85m
Drive type: 8X4
Truck Type: Concrete mixer truck
Vehicle origin: Tangshan Gaoxin / Tangshan, Hebei
Front/rear track width: Front: 2035/2035mm; Rear: 1850/1850
Wheelbase: 1800+3050+1350 / 1800+3025+1400mm
Curb Weight: 31 / 13.95 / 13.4ton
Rated payload: 16.92 / 17.47ton
Max. speed: 82km/h
Front/rear suspension: 1.43/.252 / 1.43/2.65 / 1.43/2.48m
Body Parameters
Mixing drum capacity: 7.75 / 8m³
Vehicle certification code: TZ5317GJBZGCEB / TZ5316GJBZGCE1 / TZ5316GJBZZAE
Body Brand: Yate Heavy Industry Brand
Engine parameters
Engine Model: SinotrukMC07H.35-50 / SinotrukMC07.34-50
Number of cylinders: 6cylinder
fuel type: Diesel
Displacement: 7.36 / 6.87L
Emission standard: China V
Max output power: 257 / 250kW
Max hp: 350 / 340Horsepower
Rated speed: 2300rpm
Engine Type: Inline 6-cylinder, water-cooled, 4-stroke, turbocharged intercooled, high-pressure common rail / Water-cooled, 4-stroke, turbocharged intercooled
Chassis Specs
Chassis Series: Sitrak / SITRAK C5H
Chassis Model: ZZ1317N306GE1 / ZZ1316N306GE1
Leaf spring count: 11/11/10
Transmission Parameters
Number of gears: 8 / 9Gear
Transmission Model: 8-speed gearbox / 9-Speed
Cab parameters
Cab: SitrakG5
Tire
Tire Size: 12R22.5 / 11.00R20
Number of tires: 12pcs
FAQ
What kind of truck is Yate Heavy Industry Yate Heavy Industry Sitrak Chassis concrete mixer truck?
Yate Heavy Industry Yate Heavy Industry Sitrak Chassis is an export-oriented concrete mixer truck lineup with about 3 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Yate Heavy Industry Sitrak Chassis concrete mixer cover?
Yate Heavy Industry Sitrak Chassis concrete mixer mainly covers: Drive: 8x4; Horsepower: 340 hp / 350 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Yate Heavy Industry Sitrak Chassis concrete mixer?
For Yate Heavy Industry Sitrak Chassis concrete mixer: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is concrete mixer truck typically used for?
concrete mixer truck is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Yate Heavy Industry Sitrak Chassis concrete mixer include?
Yate Heavy Industry Sitrak Chassis concrete mixer currently lists about 3 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Yate Heavy Industry Sitrak Chassis concrete mixer?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
