Dongfeng Commercial Vehicle Tianjin Medium Truck 180 hp 4X2(6 wheels) 4.75m Dump Truck

Export reference
From $26,111
MSRP ¥18.8M CNY
Emission: China IV
Fuel: Diesel
Transmission: Fast Gear
Curb Weight:: 6.65ton
Wheelbase:: 3800mm
Tire Size:: 10.00R20 radial tire
Rated payload: 4.99ton
Drive 4X2 (6 wheels)
Horsepower 180
Cargo box type: Rear-dump body

Overview

The Dongfeng Commercial Vehicle Tianjin Medium Truck 180 hp 4X2(6 wheels) 4.75m Dump Truck is a Medium-duty truck featuring 4.99t payload, 11.835t GVW, Rear-dump body cargo body and 4X2 (6 wheels) drive. On the powertrain side, it comes with a YuchaiYC6J180-42 engine, 180 hp, China IV emissions and Fast Gear transmission.

China IV 180 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): DFL3120B5
Drive type: 4X2
Wheelbase: 3800mm
engine: YuchaiYC6J180-42
transmission: Fast Gear8JS85F
Rear Axle Ratio: 5.571
Cab length: 7.05m
Cab width: 2.5m
Cab height: 2.96m
Front track width: 1920mm
rear track: 1860mm
Curb Weight: 6.65ton
Rated payload: 4.99ton
GVWR: 11.835ton
Origin: Shiyan, Hubei
tonnage class: Medium-duty truck
Approach angle: 25°
departure angle: 20°
Energy Type: Diesel
Engine parameters
Engine Brand: Yuchai
Engine Model: YuchaiYC6J180-42
Number of cylinders: 6cylinder
fuel type: Diesel
Displacement: 6.494L
Emission standard: China IV
Max output power: 132kW
Max hp: 180Horsepower
Max torque: 650N·m
Max torque speed: 1200-1700rpm
Rated speed: 2500rpm
Engine Type: Vertical, inline 6-cylinder, water-cooled, 4-stroke, electronic direct injection
Transmission Parameters
Transmission Model: Fast Gear8JS85F
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 8Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
Unloading Type: Rear-dump body
Cargo box type: Rear-dump body
Cargo box length: 4.75m
Cargo box width: 2.3m
Cargo box height: 0.8m
fuel tank
Fuel tank capacity: 160L
Chassis Specs
Front axle allowable load: 3945kg
rear axle description: 6.8t single reduction rear axle
rear axle allowable load: 7890kg
Axle ratio: 5.571
Leaf spring count: 8/10+8
Tire
Tire Size: 10.00R20 radial tire
Number of tires: 6pcs
Control configuration
ABS:

Photos

0 photos

FAQ

What is the export price of Dongfeng Commercial Vehicle Tianjin Medium Truck 180 hp 4X2(6 wheels) 4.75m Dump Truck, and what does it include?

Dongfeng Commercial Vehicle Tianjin Medium Truck 180 hp 4X2(6 wheels) 4.75m Dump Truck export reference is about From $26,111; MSRP is ¥18.8M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does Dongfeng Commercial Vehicle Tianjin Medium Truck 180 hp 4X2(6 wheels) 4.75m Dump Truck use, and can it enter my country?

This model is listed as China IV. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Dongfeng Commercial Vehicle Tianjin Medium Truck 180 hp 4X2(6 wheels) 4.75m Dump Truck?

Key specs of Dongfeng Commercial Vehicle Tianjin Medium Truck 180 hp 4X2(6 wheels) 4.75m Dump Truck: Drive: 4x2; Horsepower: 180 hp; Emission: China IV; Fuel: Diesel; Transmission: Fast Gear. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Dongfeng Commercial Vehicle Tianjin Medium Truck 180 hp 4X2(6 wheels) 4.75m Dump Truck suited for?

Dongfeng Commercial Vehicle Tianjin Medium Truck 180 hp 4X2(6 wheels) 4.75m Dump Truck is a Dump Trucks model often used on construction, mining and aggregate jobs. Check drive, horsepower and emission; state duty cycle and destination in your quote.

How does Dongfeng Commercial Vehicle Tianjin Medium Truck 180 hp 4X2(6 wheels) 4.75m Dump Truck differ from other variants in the same series?

Dongfeng Commercial Vehicle Tianjin Medium Truck 180 hp 4X2(6 wheels) 4.75m Dump Truck belongs to Dongfeng Tianjin Medium Truck (Dump Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Dongfeng Commercial Vehicle Tianjin Medium Truck 180 hp 4X2(6 wheels) 4.75m Dump Truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Dongfeng Commercial Vehicle Tianjin Medium Truck 180 hp 4X2(6 wheels) 4.75m Dump Truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
