Foton 220 hp 4X2(6 wheels) Concrete Pump Truck

Export reference
MSRP N/A
Emission: China IV
Fuel: Diesel
Drive: 4X2 (6 wheels)
Wheelbase:: 4800mm
Model code (announced):: BJ5185THB-1
Overall Dimensions: L×W×H:: 10.01×2.37×3.61m
Curb Weight: 18.3ton
Water tank capacity: 6L
Horsepower 200
Max output power: 147kW

Overview

The Foton 220 hp 4X2(6 wheels) Concrete Pump Truck is a concrete pump truck featuring 18.3ton GVW, 6L tank capacity, 200 hp and 147kW power. On the powertrain side, it comes with 4X2 (6 wheels) drive, China IV emissions and Diesel fuel.

China IV 200 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): BJ5185THB-1
Drive type: 4X2
Wheelbase: 4800mm
Overall Dimensions: L×W×H: 10.01×2.37×3.61m
Max. travel speed: 80km/h
Curb Weight: 18.3ton
Body Parameters
Water tank capacity: 6L
Chassis Specs
Axle Count: 2
Chassis Series: Foton Ruiwo Q5
Pumping system
Pumping displacement (low/high): 60-80m³/h
Boom Outriggers
Boom Vertical Height: 28m
Engine parameters
Engine Model: YuchaiYC6J200-46
fuel type: Diesel
Displacement: 6.494L
Emission standard: China IV
Max output power: 147kW
Max hp: 200Horsepower
Rated speed: 2500rpm

Photos

Exterior3

3 photos

FAQ

What emission standard does Foton 220 hp 4X2(6 wheels) Concrete Pump Truck use, and can it enter my country?

This model is listed as China IV. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Foton 220 hp 4X2(6 wheels) Concrete Pump Truck?

Key specs of Foton 220 hp 4X2(6 wheels) Concrete Pump Truck: Drive: 4x2; Horsepower: 200 hp; Emission: China IV; Fuel: Diesel. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Foton 220 hp 4X2(6 wheels) Concrete Pump Truck suited for?

Foton 220 hp 4X2(6 wheels) Concrete Pump Truck is a concrete pump truck model; configuration should match the job. State the application, emission and LHD/RHD needs in your quote.

How does Foton 220 hp 4X2(6 wheels) Concrete Pump Truck differ from other variants in the same series?

Foton 220 hp 4X2(6 wheels) Concrete Pump Truck belongs to FotonQ5 (concrete pump truck). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Foton 220 hp 4X2(6 wheels) Concrete Pump Truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Foton 220 hp 4X2(6 wheels) Concrete Pump Truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
