Foton 200 hp 4X2(6 wheels) concrete pump truck
EXW
Export quote
FotonQ5 concrete pump truck
Main model photos
491 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Foton 200 hp 4X2(6 wheels) concrete pump truck | 4x2 / 200hp / China V | ||
| Foton 220 hp 4X2(6 wheels) Concrete Pump Truck | 4x2 / 200hp / China IV |
Foton 220 hp 4X2(6 wheels) Concrete Pump Truck
EXW
Export quote
Series Specs
Basic Info
Model code (announced): BJ5185THB-FA / BJ5185THB-1
Drive type: 4X2
Wheelbase: 4800mm
Overall Dimensions: L×W×H: 10.18×2.37×3.61 / 10.01×2.37×3.61m
Max. travel speed: 80km/h
Curb Weight: 18.3ton
Body Parameters
Water tank capacity: 6L
Chassis Specs
Axle Count: 2
Chassis Series: Foton Ruiwo Q5
rear axle description: 1153
Pumping system
Pumping displacement (low/high): 60-80m³/h
Boom Outriggers
Boom Vertical Height: 28m
Engine parameters
Engine Model: YuchaiYC6J200-52 / YuchaiYC6J200-46
fuel type: Diesel
Displacement: 6.494L
Emission standard: China V / China IV
Max output power: 147kW
Max hp: 200Horsepower
Rated speed: 2300 / 2500rpm
Transmission Parameters
Number of gears: 8Gear
Transmission Model: Fast Gear8JS85E
Tire
Tire Size: 10.00R20 18PR
FAQ
What kind of truck is Foton FotonQ5 concrete pump truck?
Foton FotonQ5 is an export-oriented concrete pump truck lineup with about 2 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does FotonQ5 concrete pump truck cover?
FotonQ5 concrete pump truck mainly covers: Drive: 4x2; Horsepower: 200 hp; Emission: China IV / China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in FotonQ5 concrete pump truck?
For FotonQ5 concrete pump truck: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is concrete pump truck typically used for?
concrete pump truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does FotonQ5 concrete pump truck include?
FotonQ5 concrete pump truck currently lists about 2 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for FotonQ5 concrete pump truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
