FAW Jiefang Qingdao HanV2.0 350hp 6X4(10 wheels) Concrete Pump Truck (Zoomlion Brand)
EXW
Export quote
ZOOMLION FAW Jiefang Qingdao Chassis concrete pump
Main model photos
68 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| FAW Jiefang Qingdao HanV2.0 350hp 6X4(10 wheels) Concrete Pump Truck (Zoomlion Brand) | 6x4 / 350hp / China VI | ||
| FAW Jiefang Qingdao JH6 430hp 6X4(10 wheels) Concrete Pump Truck (Zoomlion Brand) | 6x4 / 430hp / China VI | ||
| FAW Jiefang Qingdao JH6 460hp 8X4(12 wheels) Concrete Pump Truck (Zoomlion Brand) (Xichai) | 8x4 / 460hp / China VI | ||
| FAW Jiefang Qingdao JH6 460 hp 8X4(12 wheels) Concrete Pump Truck (Zoomlion Brand) | 8x4 / 460hp / China VI | ||
| FAW Jiefang Qingdao JH6 510hp 10X4(14 wheels) Concrete Pump Truck (Zoomlion Brand) | 10x4 / 510hp / China VI |
FAW Jiefang Qingdao JH6 430hp 6X4(10 wheels) Concrete Pump Truck (Zoomlion Brand)
EXW
Export quote
FAW Jiefang Qingdao JH6 460hp 8X4(12 wheels) Concrete Pump Truck (Zoomlion Brand) (Xichai)
EXW
Export quote
FAW Jiefang Qingdao JH6 460 hp 8X4(12 wheels) Concrete Pump Truck (Zoomlion Brand)
EXW
Export quote
FAW Jiefang Qingdao JH6 510hp 10X4(14 wheels) Concrete Pump Truck (Zoomlion Brand)
EXW
Export quote
Series Specs
Basic Info
Model code (announced): ZLJ5290THBJF / ZLJ5340THBJF / ZLJ5460THBJF / ZLJ5530THBJF / ZLJ5441THBJF / ZLJ5140THBJE / ZLJ5230THBJE / ZLJ5350THBJF / ZLJ5350THBJE / ZLJ5440THBJF / ZLJ5280THBJE
Pumping displacement: 180 / 100m³/h
Drive type: 6X4 / 8X4 / 10X4 / 4X2 / 6X2
Max pumping height: 59 / 39 / 49 / 56 / 43m
Wheelbase: 4300+1350 / 5100+1350 / 2300+5450+1350 / 2300+4250+1350+1350 / 4900 / 5200 / 4700+1350 / 2100+4450+1350 / 3850+1350mm
Overall Dimensions: L×W×H: 10.975×2.55×3.95 / 12.34×2.55×3.965 / 15.17×2.55×3.965 / 16.315×2.55×3.965 / 14.88×2.55×3.965 / 9.1×2.45×3.14 / 10.53×2.55×3.92 / 12.28×2.55×4 / 14.22×2.55×4 / 10.95×2.55×3.99m
Max. travel speed: 89 / 90 / 86km/h
Curb Weight: 28.87 / 33.87 / 45.87 / 52.87 / 43.87 / 13.605 / 22.87 / 34.87 / 27.87ton
Chassis Specs
Axle Count: 3 / 4 / 5 / 2
Chassis Series: HanV2.0 / JH6 / Long V / HanV
Chassis Model: CA5330THBP1K2T1BE6A81 / CA5360THBP26K15L6T1BE6A81 / CA5460THBP26K15L7T4BE6A81 / CA5550THBP26K15L6T6BE6A81 / CA1167PK2L2BE5A80 / CA5230THBP1K2BE5A80 / CA5350THBP26K2L6T1BE6A81 / CA5350THBP26K2L6T1BE5A80 / CA5440P26K2L7T4BE6A81 / CA5300THBP1K2T2BE5A81
Frame Dimensions: 300*80*(8+5)mm
rear axle description: 457 upgraded stamped-welded axle / 300 hub reduction axle
Axle ratio: 4.875 / 5.263
clutch: Φ430
Pumping system
Pumping displacement (low/high): 180 / 60/100 / 120/180 / 60/180m³/h
Pumping pressure (low/high): 35 / 42 / 8/15
Pumping strokes (low/high): 14/25 / 18/26 / 26Times/min
Delivery cylinder: bore × stroke: Φ260×2100 / Φ230×1650mm
Engine parameters
Engine Model: WeichaiWP8.350E61 / WeichaiWP10.5H430E62 / XichaiCA6DM2-46E68 / WeichaiWP12.460E62 / WeichaiWP13.510E62 / WeichaiWP13.550E62 / DachaiCA4DK1-18E5 / XichaiCA6DL1-32E5 / XichaiCA6DM2-42E6 / XichaiCA6DM2-42E52 / XichaiCA6DM2-46E6
fuel type: Diesel
Displacement: 7.8 / 10.5 / 11.05 / 11.6 / 12.54 / 4.764 / 7.7L
Emission standard: China VI / China V
Max output power: 257 / 316 / 341 / 338 / 382 / 405 / 139 / 238 / 309 / 312kW
Max hp: 350 / 430 / 460 / 510 / 550 / 180 / 320 / 420Horsepower
Rated speed: 2100 / 1900 / 2300 / 1800rpm
Transmission Parameters
Number of gears: 9 / 12 / 8 / 10Gear
Transmission Model: Fast Gear9JSD150T / Fast GearC12JSDQXL220TA / Fast GearC12JSDQXL240T / Fast GearC12JSDQXL260TA / 8-speed gearbox
Cab parameters
Cab: HanV flat roof / JH6 Flat Roof
Tire
Tire Size: 11.00R20 18PR / Front 385/65R22.5 24PR / Rear 315/80R22.5 20PR / Front 385/65R22.5 24-ply / Rear 315/80R22.5 20-ply / 1st, 2nd, 5th axle: 385/65R22.5 24PR / 3rd, 4th axle: 315/80R22.5 20PR / 425/65R22.5 20PR/315/80R22.5 20PR,385/65R22.5 24PR/315/80R22.5 20PR / 9.00R20 16PR / 425/65R22.5 20PR/12.00R20 20PR / 385/65R22.5 20PR/315/80R22.5 20PR / 385/65R22.5 20PR/12.00R20 20PR
FAQ
What kind of truck is ZOOMLION ZOOMLION FAW Jiefang Qingdao Chassis concrete pump truck?
ZOOMLION ZOOMLION FAW Jiefang Qingdao Chassis is an export-oriented concrete pump truck lineup with about 14 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for ZOOMLION FAW Jiefang Qingdao Chassis concrete pump?
ZOOMLION FAW Jiefang Qingdao Chassis concrete pump export reference is about From $119,861. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does ZOOMLION FAW Jiefang Qingdao Chassis concrete pump cover?
ZOOMLION FAW Jiefang Qingdao Chassis concrete pump mainly covers: Drive: 6x4 / 8x4 / 10x4; Horsepower: 350 hp / 430 hp / 460 hp / 510 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in ZOOMLION FAW Jiefang Qingdao Chassis concrete pump?
For ZOOMLION FAW Jiefang Qingdao Chassis concrete pump: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is concrete pump truck typically used for?
concrete pump truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does ZOOMLION FAW Jiefang Qingdao Chassis concrete pump include?
ZOOMLION FAW Jiefang Qingdao Chassis concrete pump currently lists about 14 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for ZOOMLION FAW Jiefang Qingdao Chassis concrete pump?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
