SANY SY245H Crawler Excavator

Export reference
MSRP N/A
Engine Model:: crawler excavator
Tonnage:: 24ton
Bucket capacity:: 1.3cubic meter
Machine dimensions:: 10.29×3.19×3.255mm
Track shoe width:: 600mm
Track gauge:: 2590mm
SANY SY245H Crawler Excavator exterior
View more photos (3)
Operating weight: 25.5ton
Bucket type: backhoe
Product power: Conventional Power
Model: SY245H

Overview

The SANY SY245H Crawler Excavator is a excavator featuring 25.5ton GVW, backhoe bucket capacity and Conventional Power power. On the powertrain side, it comes with a crawler excavator engine.

Model Specs

Legend: ● Standard　○ Optional　- N/A

Basic Info
Model: SY245H
Engine Model: crawler excavator
Product power: Conventional Power
Bucket type: backhoe
Tonnage: 24ton
Operating weight: 25.5ton
Bucket capacity: 1.3cubic meter
Machine dimensions: 10.29×3.19×3.255mm
Track shoe width: 600mm
Track gauge: 2590mm
Min ground clearance: 470cm
Rear Overhang Radius: 3105mm
performance specs
Bucket digging force: 175kN
Arm Digging Force: 120kN
Operating Range
Max digging radius: 10225mm
Max digging depth: 6705mm
Max digging height: 9745mm
Max unloading height: 6715mm
Engine parameters
Engine Model: D06FRC
Max output power: 147kW

Photos

Exterior3

SANY SY245H Crawler Excavator Exterior (1) | 86Trucks SANY SY245H Crawler Excavator Exterior (2) | 86Trucks SANY SY245H Crawler Excavator Exterior (3) | 86Trucks

3 photos

FAQ

What transport jobs is SANY SY245H Crawler Excavator suited for?

SANY SY245H Crawler Excavator is a excavator model; configuration should match the job. State the application, emission and LHD/RHD needs in your quote.

How does SANY SY245H Crawler Excavator differ from other variants in the same series?

SANY SY245H Crawler Excavator belongs to SANY crawler excavator (excavator). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for SANY SY245H Crawler Excavator?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export SANY SY245H Crawler Excavator?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
