Doosan DH55-V Crawler Excavator

Export reference
MSRP N/A
Engine Model:: crawler excavator
Tonnage:: 5ton
Bucket capacity:: 0.175cubic meter
Machine dimensions:: 5.94×1.88×2.565mm
Track shoe width:: 400mm
Track gauge:: 1480mm
Operating weight: 5.25ton
Bucket type: backhoe
Product power: Conventional Power
Model: DH55-V

Overview

The Doosan DH55-V Crawler Excavator is a excavator featuring 5.25ton GVW, backhoe bucket capacity and Conventional Power power. On the powertrain side, it comes with a crawler excavator engine.

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model: DH55-V
Engine Model: crawler excavator
Product power: Conventional Power
Bucket type: backhoe
Tonnage: 5ton
Operating weight: 5.25ton
Bucket capacity: 0.175cubic meter
Machine dimensions: 5.94×1.88×2.565mm
Track shoe width: 400mm
Track gauge: 1480mm
Counterweight ground clearance: 700mm
Min ground clearance: 350cm
Rear Overhang Radius: 1550mm
hydraulic system
Max flow of main pump: 2×55L/min
Working hydraulic circuit: 20.6
travel hydraulic circuit: 17.65Mpa
Swing Hydraulic Circuit: 17.65Mpa
performance specs
Travel speed: 2×55km/h
Bucket digging force: 31.4kN
Arm Digging Force: 24.5kN
Operating Range
Max digging radius: 6100mm
Max digging depth: 3890mm
Max digging height: 5330mm
Max unloading height: 3630mm
Max vertical digging depth: 3025mm
Engine parameters
Max output power: 40.5kW

Photos

Exterior3

3 photos

FAQ

What transport jobs is Doosan DH55-V Crawler Excavator suited for?

Doosan DH55-V Crawler Excavator is a excavator model; configuration should match the job. State the application, emission and LHD/RHD needs in your quote.

How does Doosan DH55-V Crawler Excavator differ from other variants in the same series?

Doosan DH55-V Crawler Excavator belongs to Doosan Doosan Crawler Excavator (excavator). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Doosan DH55-V Crawler Excavator?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Doosan DH55-V Crawler Excavator?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
