Sinotruk HOWO heavy truck 340 hp 6X4(10 wheels) 5.1 m³ concrete mixer truck chassis

Export reference
MSRP N/A
Curb Weight:: 8.83ton
Wheelbase:: 3825+1350mm
Tire Size:: 1200R20
Cab dimensions:: 8.075×2.496×2.958m
Truck Type:: concrete mixer truck
Vehicle origin:: Jinan, Shandong
Drive 6X4 (10 wheels)
Horsepower 340
Emission China IV
Fuel Diesel

Overview

The Sinotruk HOWO heavy truck 340 hp 6X4(10 wheels) 5.1 m³ concrete mixer truck chassis is a concrete mixer truck featuring 8.83ton GVW, 6X4 (10 wheels) drive and HW76 cab cab. On the powertrain side, it comes with 340 hp, China IV emissions and Diesel fuel.

China IV 340 Diesel 6X4

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Cab dimensions: 8.075×2.496×2.958m
Truck Type: concrete mixer truck
Drive type: 6X4
Vehicle origin: Jinan, Shandong
Wheelbase: 3825+1350mm
Front/rear track width: Front track: 2022mm; Rear track: 1830/1830mm
Curb Weight: 8.83ton
Max. speed: 78km/h
Engine parameters
Injection System: Common Rail (China IV)
Engine Model: SinotrukD10.34-40
Number of cylinders: 6cylinder
fuel type: Diesel
Displacement: 9.726L
Emission standard: China IV
Max output power: 249kW
Max hp: 340Horsepower
Rated speed: 1900rpm
Engine Type: Inline 6-cylinder, water-cooled, 4-stroke, turbocharged intercooled, high-pressure common rail
Body Parameters
Mixing drum capacity: 5.1m³
Chassis Specs
Chassis Series: HOWOHOWO-7
Chassis Model: ZZ1257N3847D1
rear axle description: ST16
Axle ratio: 4.8
Leaf spring count: 9/12
Transmission Parameters
Number of gears: 10Gear
Transmission Model: SinotrukHW15710
Cab parameters
Cab: HW76 cab
Tire
Tire Size: 1200R20
Number of tires: 10pcs

Photos

Exterior1

1 photos

FAQ

What emission standard does Sinotruk HOWO heavy truck 340 hp 6X4(10 wheels) 5.1 m³ concrete mixer truck chassis use, and can it enter my country?

This model is listed as China IV. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Sinotruk HOWO heavy truck 340 hp 6X4(10 wheels) 5.1 m³ concrete mixer truck chassis?

Key specs of Sinotruk HOWO heavy truck 340 hp 6X4(10 wheels) 5.1 m³ concrete mixer truck chassis: Drive: 6x4; Horsepower: 340 hp; Emission: China IV; Fuel: Diesel. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Sinotruk HOWO heavy truck 340 hp 6X4(10 wheels) 5.1 m³ concrete mixer truck chassis suited for?

Sinotruk HOWO heavy truck 340 hp 6X4(10 wheels) 5.1 m³ concrete mixer truck chassis is a concrete mixer truck model often used on construction, mining and aggregate jobs. Check drive, horsepower and emission; state duty cycle and destination in your quote.

How does Sinotruk HOWO heavy truck 340 hp 6X4(10 wheels) 5.1 m³ concrete mixer truck chassis differ from other variants in the same series?

Sinotruk HOWO heavy truck 340 hp 6X4(10 wheels) 5.1 m³ concrete mixer truck chassis belongs to Sinotruk HOWO-7 heavy-duty truck (concrete mixer truck). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Sinotruk HOWO heavy truck 340 hp 6X4(10 wheels) 5.1 m³ concrete mixer truck chassis?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Sinotruk HOWO heavy truck 340 hp 6X4(10 wheels) 5.1 m³ concrete mixer truck chassis?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
