Shidai Jingang 130 hp 4X2(6 wheels) concrete mixer truck
EXW
Export quote
Foton King Light Truck concrete mixer truck
Main model photos
216 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Shidai Jingang 130 hp 4X2(6 wheels) concrete mixer truck | 4x2 / 130hp / China IV | ||
| Shidai Jingang 130 hp 4X2(6 wheels) concrete mixer truck | 4x2 / 130hp / China III / Euro III | ||
| Shidai Jingang 130 hp 4X2(6 wheels) concrete mixer truck | 4x2 / 130hp / China III / Euro III |
Shidai Jingang 130 hp 4X2(6 wheels) concrete mixer truck
EXW
Export quote
Shidai Jingang 130 hp 4X2(6 wheels) concrete mixer truck
EXW
Export quote
Series Specs
Basic Info
Cab dimensions: 6.825×2.48×3.45 / 6.825×2.48×3.6 / 6.765×2.499×3.42m
Drive type: 4X2
Truck Type: Concrete mixer truck
Vehicle origin: Beijing / Hunan
Wheelbase: 3900 / 3600mm
Front/rear track width: 1790，1725 / Front track: 1790mm; Rear track: 1725mm
Curb Weight: 5.86 / 7.99ton
Rated payload: 7.505 / 7.805ton
Max. speed: 80km/h
Front/rear suspension: 1.19/1.975m
Body Parameters
Drum geometric volume: 6m³
Slump: 50mm
Mixing drum capacity: 4m³
Drum rotation speed: 6-8r/min
Feed rate: 3m³/min
Discharge speed: 2m³/min
Discharge residue rate: <0.7%
Filling Rate: 58.7%
water supply method: Air pressure water supply
Vehicle certification code: BJ5142GJB-G1 / BJ5162GJB1
hydraulic system: Closed hydraulic circuit
Body Brand: Foton
Engine parameters
Engine Model: YuchaiYC4D130 / Yuchai YC4D130-33
Number of cylinders: 4cylinder
fuel type: Diesel
Displacement: 4.2 / 4.214 / 4L
Emission standard: China IV / China III / Euro III
Max output power: 95 / 96kW
Max hp: 130Horsepower
Rated speed: 2800rpm
Engine Type: Inline / Vertical, inline, water-cooled, four-stroke, direct injection
Chassis Specs
Chassis Series: King Kong
Chassis Model: BJ1142 / BJ1162V5PDB-E1
rear axle description: 10T 153AS Shortened Axle / 8
Leaf spring count: 9/11+9
Transmission Parameters
Number of gears: 6 / 5Gear
Transmission Model: 6-53HF with auxiliary transmission / 145HF
Tire
Tire Size: 9.00R20 / 8.25R20 / 9.00-20
Number of tires: 6pcs
FAQ
What kind of truck is Foton Foton King Light Truck concrete mixer truck?
Foton Foton King Light Truck is an export-oriented concrete mixer truck lineup with about 3 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Foton King Light Truck concrete mixer truck cover?
Foton King Light Truck concrete mixer truck mainly covers: Drive: 4x2; Horsepower: 130 hp; Emission: China III / Euro III / China IV; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Foton King Light Truck concrete mixer truck?
For Foton King Light Truck concrete mixer truck: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is concrete mixer truck typically used for?
concrete mixer truck is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Foton King Light Truck concrete mixer truck include?
Foton King Light Truck concrete mixer truck currently lists about 3 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Foton King Light Truck concrete mixer truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
