Sinotruk HOWO TX 350 hp 8X4(12 wheels) 7.76 m³ Concrete Mixer Truck (Lingyu Brand)
EXW
From $54,444
Export quote
CIMC Lingyu Sinotruk HOWO Chassis concrete mixer
Main model photos
10 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Sinotruk HOWO TX 350 hp 8X4(12 wheels) 7.76 m³ Concrete Mixer Truck (Lingyu Brand) | 8x4 / 350hp / China VI | From $54,444 | |
| Sinotruk HOWO T5G 340hp 8X4(12 wheels) 7.3m³ concrete mixer truck (Lingyu brand) | 8x4 / 340hp / China V | From $76,389 | |
| Sinotruk HOWO T5G 340 hp 8X4(12 wheels) 7.58 m³ Concrete Mixer Truck | 8x4 / 340hp / China V | From $76,389 | |
| Sinotruk HOWO T5G 340hp 8X4(12 wheels) 7.95m³ concrete mixer truck (CIMC brand) | 8x4 / 340hp / China V | From $76,389 | |
| Sinotruk HOWO T5G 340hp 8X4(12 wheels) 7.2m³ concrete mixer truck (Lingyu brand) | 8x4 / 340hp / China V |
Sinotruk HOWO T5G 340hp 8X4(12 wheels) 7.3m³ concrete mixer truck (Lingyu brand)
EXW
From $76,389
Export quote
Sinotruk HOWO T5G 340 hp 8X4(12 wheels) 7.58 m³ Concrete Mixer Truck
EXW
From $76,389
Export quote
Sinotruk HOWO T5G 340hp 8X4(12 wheels) 7.95m³ concrete mixer truck (CIMC brand)
EXW
From $76,389
Export quote
Sinotruk HOWO T5G 340hp 8X4(12 wheels) 7.2m³ concrete mixer truck (Lingyu brand)
EXW
Export quote
Series Specs
Basic Info
Cab dimensions: 10.1×2.52×3.995 / 10.15×2.5×3.95 / 10.15×2.52×3.995 / 10.32×2.52×3.995 / 10.7×2.55×3.99 / 10.65×2.55×3.99 / 11.97×2.55×3.995 / 11.97×2.55×3.99 / 9.995×2.5×3.99m
Drive type: 8X4 / 6X4
Truck Type: Concrete mixer truck
Wheelbase: 1800+3050+1350 / 1800+3025+1400 / 4325+1350 / 1800+3825+1350 / 4025+1350mm
Vehicle origin: Luoyang, Henan
Front/rear track width: Front: 2035/2035mm; Rear: 1850/1850 / Front: 2015/2015mm; Rear: 1850/1850 / Front: 2022/2022mm; Rear: 1830/1830 / Front track: 2022/2022mm; Rear track: 1830/1830 / Front track: 2022mm; Rear track: 1830/1830
Curb Weight: 13.93 / 14.5 / 14.3 / 13.5 / 15 / 13.88 / 15.58 / 19 / 16.75ton
Rated payload: 16.94 / 16.37 / 16.57 / 17.37 / 15.87 / 10.99 / 15.29 / 11.87 / 8.12ton
Max. speed: 82 / 80km/h
Front/rear suspension: 1.43/2.47 / 1.43/1.3 / 1.43/2.52 / 1.43/2.69 / 1.5/2.975 / 1.5/3.495 / 1.5/3.45 / 1.5/3.12 / 1.5/3.475m
Engine parameters
Injection System: Common Rail (China V)
Engine Model: WeichaiWP8.350E61 / SinotrukMC07.34-50 / SinotrukD10.38-50 / SinotrukD10.34-50
Number of cylinders: 6cylinder
fuel type: Diesel
Displacement: 7.8 / 6.87 / 9.726L
Emission standard: China VI / China V
Max output power: 257 / 248 / 276 / 249kW
Max hp: 350 / 340 / 380Horsepower
Rated speed: 2100 / 2300 / 2000 / 1900rpm
Engine Type: Inline 6-cylinder, water-cooled, 4-stroke, high-pressure common rail, turbocharged intercooled, EGR / Inline 6-cylinder, water-cooled, 4-stroke, turbocharged intercooled, high-pressure common rail
Body Parameters
Mixing drum capacity: 7.76 / 7.3 / 7.58 / 7.95 / 7.2 / 5.02 / 7 / 5.2 / 3.7m³
Vehicle certification code: CLY5317GJB30E65 / CLY5317GJB30E1 / CLY5317GJB30E54 / CLY5317GJB30E52 / CLY5317GJB30E1B / CLY5257GJB43E1B / CLY5317GJB36E1B / CLY5317GJB36E1 / CLY5257GJB43E1
Body Brand: Lingyu
Chassis Specs
Chassis Series: HOWO TX / HOWO T5G / SinotrukHOWO-7
Chassis Model: ZZ1317N306GF1 / ZZ1317N306GE1 / ZZ1257N4347E1 / ZZ1317N3667E1
Axle ratio: 5.73
Leaf spring count: 11/11/10 / 10/12 / 11/11/12
Transmission Parameters
Number of gears: 12 / 10Gear
Transmission Model: 12-speed transmission / Sinotruk 10-speed / SinotrukHW10
Tire
Tire Size: 11.00R20 18PR / 11.00R20 / 12R22.5,11.00R20 / 11.00R20 18PR,12.00R20 16PR/12.00R20 18PR,12.00R20 16PR / 11.00R20 18PR，12.00R20 18PR / 11.00R20 18PR，12.00R20 16PR
FAQ
What kind of truck is CIMC Lingyu CIMC Lingyu Sinotruk HOWO Chassis concrete mixer truck?
CIMC Lingyu CIMC Lingyu Sinotruk HOWO Chassis is an export-oriented concrete mixer truck lineup with about 10 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for CIMC Lingyu Sinotruk HOWO Chassis concrete mixer?
CIMC Lingyu Sinotruk HOWO Chassis concrete mixer export reference is about $54,444 – $76,389. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does CIMC Lingyu Sinotruk HOWO Chassis concrete mixer cover?
CIMC Lingyu Sinotruk HOWO Chassis concrete mixer mainly covers: Drive: 8x4; Horsepower: 340 hp / 350 hp; Emission: China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in CIMC Lingyu Sinotruk HOWO Chassis concrete mixer?
For CIMC Lingyu Sinotruk HOWO Chassis concrete mixer: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is concrete mixer truck typically used for?
concrete mixer truck is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does CIMC Lingyu Sinotruk HOWO Chassis concrete mixer include?
CIMC Lingyu Sinotruk HOWO Chassis concrete mixer currently lists about 10 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for CIMC Lingyu Sinotruk HOWO Chassis concrete mixer?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
