SHACMAN Commercial Vehicle Xuande X6 Lightweight Version 160 hp 4X2(6 wheels) 4.1m Dump Truck

Export reference
MSRP N/A
Emission: China IV
Fuel: Diesel
Transmission: Fast Gear
Curb Weight:: 6.8ton
Wheelbase:: 3950mm
Tire Size:: 9.00R20
Rated payload: 4.995ton
Drive 4X2 (6 wheels)
Horsepower 160
Cargo box type: Dump type

Overview

The SHACMAN Commercial Vehicle Xuande X6 Lightweight Version 160 hp 4X2(6 wheels) 4.1m Dump Truck is a Medium-duty truck featuring 4.995t payload, 11.99t GVW, Dump type cargo body and 4X2 (6 wheels) drive. On the powertrain side, it comes with a YuchaiYC4EG160-40 engine, 160 hp, China IV emissions and Fast Gear transmission.

China IV 160 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): SX3121GP4
Drive type: 4X2
Wheelbase: 3950mm
engine: YuchaiYC4EG160-40
transmission: Fast Gear8JS85F
Rear Axle Ratio: 6.83
Cab length: 6.67m
Cab width: 2.4m
Cab height: 2.93m
Front track width: 1765mm
rear track: 1725,1750mm
Curb Weight: 6.8ton
Rated payload: 4.995ton
GVWR: 11.99ton
Origin: Baoji, Shaanxi
tonnage class: Medium-duty truck
Approach angle: 19°
departure angle: 20°
Remarks: Optional equipment: 1. Optional 457BDQ/6.33 rear axle; 2. Optional 10.00R20 tires; 3. Optional φ140 front support; 4. Optional 250(8+4) frame; Application: sand and gravel transport; Lifting method: single cylinder; Road conditions: gravel roads, national highways, and rural roads; Speed: 50-60 km/h / 80 km/h
Version: Lightweight version
Energy Type: Diesel
Engine parameters
Engine Brand: Yuchai
Engine Model: YuchaiYC4EG160-40
Number of cylinders: 4cylinder
fuel type: Diesel
Displacement: 4.73L
Emission standard: China IV
Max output power: 118kW
Max hp: 160Horsepower
Max torque: 500N·m
Max torque speed: 1300-1600rpm
Rated speed: 2500rpm
Engine Type: BOSCH high-pressure common rail SCR
Transmission Parameters
Transmission Model: Fast Gear8JS85F
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 8Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
Unloading Type: Dump type
Cargo box type: Dump type
Cargo box length: 4.1m
Cargo box width: 2.2m
Cargo box height: 0.8m
fuel tank
Fuel tank capacity: 160L
Chassis Specs
Frame Dimensions: Double-layer 250/6+4mm
rear axle description: 153SDL
rear axle allowable load: 6990kg
Axle ratio: 6.83
Leaf spring count: 9/11+8
clutch: Φ350
Tire
Tire Size: 9.00R20
Number of tires: 6pcs

Photos

0 photos

FAQ

What emission standard does SHACMAN Commercial Vehicle Xuande X6 Lightweight Version 160 hp 4X2(6 wheels) 4.1m Dump Truck use, and can it enter my country?

This model is listed as China IV. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of SHACMAN Commercial Vehicle Xuande X6 Lightweight Version 160 hp 4X2(6 wheels) 4.1m Dump Truck?

Key specs of SHACMAN Commercial Vehicle Xuande X6 Lightweight Version 160 hp 4X2(6 wheels) 4.1m Dump Truck: Drive: 4x2; Horsepower: 160 hp; Emission: China IV; Fuel: Diesel; Transmission: Fast Gear. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is SHACMAN Commercial Vehicle Xuande X6 Lightweight Version 160 hp 4X2(6 wheels) 4.1m Dump Truck suited for?

SHACMAN Commercial Vehicle Xuande X6 Lightweight Version 160 hp 4X2(6 wheels) 4.1m Dump Truck is a Dump Trucks model often used on construction, mining and aggregate jobs. Check drive, horsepower and emission; state duty cycle and destination in your quote.

How does SHACMAN Commercial Vehicle Xuande X6 Lightweight Version 160 hp 4X2(6 wheels) 4.1m Dump Truck differ from other variants in the same series?

SHACMAN Commercial Vehicle Xuande X6 Lightweight Version 160 hp 4X2(6 wheels) 4.1m Dump Truck belongs to SHACMAN Xuande X6 Heavy-Duty Truck (Dump Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for SHACMAN Commercial Vehicle Xuande X6 Lightweight Version 160 hp 4X2(6 wheels) 4.1m Dump Truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export SHACMAN Commercial Vehicle Xuande X6 Lightweight Version 160 hp 4X2(6 wheels) 4.1m Dump Truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
