FAW Jiefang F9N Steering Axle
EXW
Export quote
FAW Jiefang Steering Axle
Main model photos
16 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| FAW Jiefang F9N Steering Axle | — | ||
| FAW Jiefang F4N 5.5-ton steering axle | — | ||
| FAW Jiefang F4N 4.5-ton steering axle | — | ||
| FAW Jiefang F7N steering axle | — | ||
| FAW Jiefang F3N 3.5-ton steering axle | — |
FAW Jiefang F4N 5.5-ton steering axle
EXW
Export quote
FAW Jiefang F4N 4.5-ton steering axle
EXW
Export quote
FAW Jiefang F7N steering axle
EXW
Export quote
FAW Jiefang F3N 3.5-ton steering axle
EXW
Export quote
Series Specs
Basic Info
Axle Model: FAW Jiefang F9N Steering Axle / FAW Jiefang F4N Steering Axle / FAW Jiefang F7N Steering Axle / FAW Jiefang F3N Steering Axle / FAW Jiefang F2N Steering Axle / FAW Jiefang F5N Steering Axle / F7D steering axle / Heavy-duty 8-ton / FAW Jiefang heavy-duty / FAW Jiefang 5-ton / FAW Jiefang light-duty 3-ton
Axle Type: Steering axle
Application Scope: Construction Vehicles / Tractor truck, cargo truck, bus / cargo truck, bus / Light cargo truck / J6, J7 standard steering axle / Ultra-strong load capacity, extra-large steering angle, stable and reliable braking system – the best choice for engineering users. This product has now entered the European market. / Extremely strong load capacity and flexible matching options meet the diverse needs of passenger and cargo users. This axle is paired with Neway air suspension system, suitable for 11m-12m luxury coaches. / The most popular steering axle in the domestic market, widely used on multi-axle cargo trucks and also suitable for 9-10m buses. / Widely used in multi-axle cargo trucks, also suitable for 9-10m buses. / Load capacity 1-2 tons; 1-ton steering axle can use independent suspension, disc brake, etc., suitable for pickup series. 2-ton models can be used for light cargo trucks, etc. It adopts I-beam structure, compact; drum hydraulic brake (or disc air brake), internationally popular ABS anti-lock system, stable and reliable performance, flexible steering
Applicable Tire: 11.00-20 radial tire / 10.00-20 radial tire / 6.50-16 bias-ply tire
Front/rear track width: 2055 / 2050 / 1924-1952 / 2020/2050 / 1800 / 1706 / 1580 / 1950 / 2024 / 2020 / 1914 / 1600mm
Rated axle load: 9000 / 5500 / 4500 / 7000 / 3500 / 3000 / 2300 / 5000 / 7500 / 8000 / 6500 / 1700ton
Brake: drum brake / disc brake / drum hydraulic brake
Transmission Ratio: 45° / 6.561
Brake size: Φ410×180 / Φ400X150/Φ410X150 wedge type / Φ400X135 / Φ400×100 / Φ320X100 / Φ410×160 / Φ400X160 / Φ400X150 / Φ310X65
Max output torque: 46000 / 28000N·m
Rim Used: 8.50-20 / 10.00-20 / 7.5-20inch
Wheel Bolts: Φ335 / Φ335/Φ275/Φ285.75 / Φ275/Φ285.75 / Φ222.25 / Φ285.75/Φ335 / 280.8mm
Remarks: High-load front axle leaf spring surface flattening process, lightweight asymmetric cross-section front axle, high-performance non-quenched and tempered steel, validated through rigorous bench and road tests; split single-degree-of-freedom stamped-welded brake, stable and reliable braking, optional wedge brake; maintenance-free tie rod, optional maintenance-free hub. / High-load front axle leaf spring surface flattening process, lightweight asymmetric cross-section front axle, high-performance non-quenched and tempered steel, validated through rigorous bench and road tests; split single-degree-of-freedom stamped-welded brake, stable and reliable braking, optional wedge brake; maintenance-free tie rod; integrated lightweight structure of straight arm and steering knuckle. / I-beam large-section front axle, high-performance non-quenched and tempered steel, high load capacity verified by rigorous bench and road tests; integral single-degree-of-freedom stamped-welded brake, stable and reliable braking; maintenance-free tie rod, optional maintenance-free hub; three-arm bolted structure, easy assembly and disassembly. / High load capacity, lightweight asymmetric I-section; fatigue test improved by 3x; integral single-degree-of-freedom brake, stable and reliable braking; high market recognition, easy maintenance. / High load capacity verified by rigorous bench and road tests; variable-section friction plates, high material utilization, good braking performance; maintenance-free tie rod; three-arm bolted connection, easy to assemble and disassemble, easy to service. / I-beam large-section front axle, high-performance non-quenched and tempered steel, high load capacity verified by rigorous bench and road tests; integral single-degree-of-freedom stamped-welded brake, stable and reliable braking; maintenance-free tie rod. / Housing type: cast; Spring seat spacing: 880mm; Section size: 130×140×16; Braking torque: total axle braking torque 30000 Nm, parking brake torque 20000 Nm / Heavy-duty 5.6-ton / Heavy-duty 4.5-ton steering axle / Dimensions can be customized per user requirements. / Light 3-ton steering axle
FAQ
What kind of truck is FAW Jiefang FAW Jiefang Steering Axle axle?
FAW Jiefang FAW Jiefang Steering Axle is an export-oriented axle lineup with about 14 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is axle typically used for?
For axle, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does FAW Jiefang Steering Axle include?
FAW Jiefang Steering Axle currently lists about 14 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for FAW Jiefang Steering Axle?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
