Sinotruk VPD95E 9.5T Disc Steering Axle
EXW
Export quote
Sinotruk Steering Axle
Main model photos
27 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Sinotruk VPD95E 9.5T Disc Steering Axle | — | ||
| Sinotruk VPD95D 9.5T Disc Steering Axle | — | ||
| Sinotruk VPD75ES 7.5T Disc Steering Axle | — | ||
| Sinotruk VPD75D 7.5T Disc Steering Axle | — | ||
| Sinotruk VGD95 9.5T Drum Steering Axle | — |
Sinotruk VPD95D 9.5T Disc Steering Axle
EXW
Export quote
Sinotruk VPD75ES 7.5T Disc Steering Axle
EXW
Export quote
Sinotruk VPD75D 7.5T Disc Steering Axle
EXW
Export quote
Sinotruk VGD95 9.5T Drum Steering Axle
EXW
Export quote
Series Specs
Basic Info
Axle Model: VPD95E / VPD95D / VPD75ES / VPD75D / VGD95 / VGD75S / VGD75 / VGD70S / VGD70 / H653K / H653 / Sinotruk VGD050QB / HF12 / HF10 / HF9 / VPD085QB / VPD075QB / VGD060QB / VPD060QB / H153 / VPD050QB / VPD048QB / VPD036QB / SinotrukHR9 / VPD045QB / HF7 / HR7 / Sinotruk VPD028QB / Sinotruk VPD022QB / Sinotruk VGD053QB / Sinotruk JW07 / Sinotruk STR / Sinotruk HW08
Axle Type: Steering axle
Application Scope: For heavy-duty cargo trucks, tractor trucks, dump trucks, concrete mixer trucks, etc. / Suitable for medium-duty cargo trucks, lightweight heavy tractor trucks, and other highway vehicles / For wide-body dump trucks used in mining areas. / For highway vehicles such as heavy-duty cargo trucks and tractor trucks, and off-road vehicles such as heavy-duty dump trucks and concrete mixer trucks. / Suitable for light-duty cargo trucks and other highway vehicles. / heavy-duty truck series / Fits all heavy-duty trucks of our HOWO, Steyr King, and Steyr series
Front/rear track width: 1995 / 1963 / 2043mm
Rated axle load: 9500 / 7500 / 7000 / 6500 / 5000 / 12000 / 10000 / 9000 / 8500 / 6000 / 5500 / 4800 / 3600 / 4500 / 2800 / 2200 / 5300ton
Brake: Disc / Drum Type / drum brake / Air pressure - disc brake / Air pressure - disc drive / Disc brake / S-cam drum brake
curb weight: 425 / 210/220 / 190 / 390 / 450 / 470kg
Brake size: 22.5 inch / Φ420X160
Rim Used: 20 / 17.5inch
Wheel Bolts: Φ335 / 10-M22X1.5mm
Remarks: Leaf spring seat center distance: 880mm; Kingpin inclination 6°, Camber angle 1° / Leaf spring seat center distance: 880mm; Kingpin inclination 7°, Camber angle 1° / Leaf spring seat center distance: 850/880mm; Kingpin inclination 6°, Camber angle 1° / leaf spring seat center distance: 1230mm; kingpin inclination 5°, camber angle 1° / leaf spring seat center distance: 1090mm; kingpin inclination 5°, camber angle 1° / Leaf spring seat center distance: 850-900mm; Kingpin inclination 3°, Camber angle 1° / leaf spring seat center distance: 1160mm; kingpin inclination 7.5°, camber angle 0.5° / Leaf spring seat center distance: 850-900mm; Kingpin inclination 7.5°, Camber angle 0.5° / leaf spring seat center distance: 840-900mm; kingpin inclination 6°, camber angle 1° / leaf spring seat center distance: 840/850-900mm; kingpin inclination 6°, camber angle 1° / Leaf spring seat center distance: 850/900mm; Kingpin inclination 7°, Camber angle 1° / Leaf spring seat center distance: 850/900mm; Kingpin inclination 6°, Camber angle 1° / Leaf spring seat center distance: 840/880mm; Kingpin inclination 6°, Camber angle 1° / Leaf spring seat center distance: 840mm; Kingpin inclination 6°, Camber angle 1° / Integrated front steering axle, mainly composed of front I-beam, steering knuckle, kingpin, steering knuckle arm and tie rod arm, etc., serving to bear load and enable vehicle steering
FAQ
What kind of truck is Sinotruk Sinotruk Steering Axle axle?
Sinotruk Sinotruk Steering Axle is an export-oriented axle lineup with about 33 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is axle typically used for?
For axle, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Sinotruk Steering Axle include?
Sinotruk Steering Axle currently lists about 33 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Sinotruk Steering Axle?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
