Meichi 20TMRZP-X263A Mining Drive Axle
EXW
Export quote
Meritor drive axle
Main model photos
20 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Meichi 20TMRZP-X263A Mining Drive Axle | — | ||
| Meichi X141A Mining Drive Axle | — | ||
| Meichi X360A Mining Drive Axle | — | ||
| Meritor X360 mining drive axle | — | ||
| Meritor X360B mining drive axle | — |
Meichi X141A Mining Drive Axle
EXW
Export quote
Meichi X360A Mining Drive Axle
EXW
Export quote
Meritor X360 mining drive axle
EXW
Export quote
Meritor X360B mining drive axle
EXW
Export quote
Series Specs
Basic Info
Axle Model: Meritor 20TMRZP-X263A / Meritor X141A / Meritor X360A / Meritor X360 / Meritor X360B / Meritor C217JA / Meritor C227EA / Meritor C223SBCHA / Meritor C223SBC / Meritor C208ADA / Meritor C208ACA / MD13166 / MP13166 / MR13166 / MS13176 / Meritor MFS66122 / MC13176 / MT32616 / Meritor MT36610 / Meritor D212 / Meritor D222E / Meritor D222
Axle Type: Drive axle / Steering axle
Application Scope: Tandem axle supports max GCW 90t truck; single axle supports max GCW 45t truck and buses/coaches over 10m / Suitable for trucks up to 55 tons total weight and buses, tourist, and passenger vehicles over 10 meters / Highway logistics trucks and hazardous material transport trucks / Suitable for construction vehicles, heavy cargo trucks and heavy tractor trucks, mining dump trucks, and heavy cranes / Road machinery axle
Applicable Tire: 22.5
Front/rear track width: 1776/1832 / 1800 - 1860 / 2021 / 1805-1860 / 1837mm
Rated axle load: 88000 / 10000 / 16000 / 18000 / 36000 / 26000 / 13000 / 6600 / 32000 / 12000ton
Transmission Ratio: total reduction ratio:15.39; main reduction ratio:3.42; wheel hub reduction ratio:4.5 / total reduction ratio:11.7; main reduction ratio:3.36; wheel hub reduction ratio:3.48 / total reduction ratio:18.28; main reduction ratio:3.7; wheel hub reduction ratio:4.94 / Total reduction ratio:6.166; Main reduction ratio:6.166; Wheel hub reduction ratio:1 / Total reduction ratio:5.939; Main reduction ratio:3.7; Wheel hub reduction ratio:1.605; / 3.07-7.17 / 3.07~7.17 / 2.80, 2.93, 3.07, 3.21, 3.42, 3.58, 3.73, 3.91, 4.10, 4.30, 4.56, 4.89, 5.38, 5.63, 6.14, 6.83, 7.17 / 2.64, 2.85, 3.08, 3.36, 3.70, 4.11, 4.63, 5.29, 5.63, 6.14 / 3.46-7.2 / 5.73
Brake: drum brake / drum brake / disc brake / Disc / Drum Type / Disc brake / Disc ADB
Brake size: Φ500X250P / 22.5 inch ADB / Φ414X200P / Φ420X160P / Φ410X200 / ADB, 22.5 inch / 410x200 / 22.5 / 410x200/220 / Φ420X180P
curb weight: 850 / 780 / 690 / Intermediate axle approx. 830kg, rear axle approx. 740 / 700 / 400 / 750 / 32000-44000
Max output torque: 8000-10000 / 10000-12000N·m
Rim Used: 24 / 20 / 8.25×22.5;9.00×22.5 / 8.25×22.5 in, 9.00×22.5 / 9.00x22.5; 8.25x22.5inch
Wheel Bolts: 20xM22x1.5 ISO / 20×M22×1.5 / 10xM22x1.5 / 10xM22x2.5/1.5mm
Remarks: Through-type / crane bridge / Drum Type / Disc; Spring Seat Center Distance: 960/1040mm; Section Size: 150×135×14mm / stamped-welded axle housing; leaf spring seat center distance: 960/1040mm; section size: 150×135×14mm / Drum single reduction; approx. 50–80 kg lighter than domestic same-class axle; transmission efficiency 1.5%–2.2% higher than domestic same-class axle; noise approx. 12 dB lower than domestic same-class axle. Reinforced brake drum for greater braking torque; imported friction linings for longer life. Reinforced stamped-welded axle housing, friction-welded spindle ends to meet overloading needs in emerging markets; imported hub combination oil seals for better sealing and longer life; ABS sensor standard. / Single reduction drive axle; max power up to 560 hp; 50-80 kg lighter than domestic axles of same class; transmission efficiency 1.5%-2.2% higher than domestic axles of same class; noise approx. 12 dB lower than domestic axles of same class. Meritor original brakes for greater braking torque; imported friction linings for longer life. Reinforced stamped-welded axle housing, friction-welded spindle ends to meet overloading needs in emerging markets; imported hub combination oil seals for better sealing and longer life; ABS sensors standard. / Max steering angle: 45°, kingpin center distance: 1752.6 mm; weight approx. 30 kg lighter than domestic same-class axles; Meritor original brake, larger braking torque; imported friction linings, longer service life; grease or oil lubrication, oil change interval up to 1 year or 160,000 km for high-speed passenger vehicles (Meritor approved oil); larger steering angle, lower steering effort; adjustable tie rod for easy caster and camber adjustment, improving tire life; inclined kingpin design for improved vehicle stability. / Drum single reduction drive axle; approx. 50–80 kg lighter than domestic same-class axle; transmission efficiency 1.5%–2.2% higher than domestic same-class axle; noise approx. 12 dB lower than domestic same-class axle. Reinforced brake drum for greater braking torque; imported friction linings for longer life. Reinforced stamped-welded axle housing, friction-welded spindle ends to meet overloading needs in emerging markets; imported hub combination oil seals for better sealing and longer life; ABS sensor standard. / Disc single reduction; max hp up to 560 hp; 50–80 kg lighter than domestic same-class axles; 1.5%–2.2% higher transmission efficiency than domestic same-class axles; about 12 dB lower noise than domestic same-class axles. Meritor original brakes, larger braking torque; imported friction discs, longer life. Reinforced stamped-welded axle housing, friction-welded spindle, meets overload needs in emerging markets; imported hub combination oil seals, better sealing, longer life; ABS sensor standard. / Single reduction drive axle; max power up to 560 hp; 50-80 kg lighter than domestic axles of same class; transmission efficiency 1.5%-2.2% higher than domestic axles of same class; noise approx. 12 dB lower than domestic axles of same class. Reinforced brake drum for greater braking torque; imported friction linings for longer life. Reinforced stamped-welded axle housing, friction-welded spindle ends to meet overloading needs in emerging markets; imported hub combination oil seals for better sealing and longer life; ABS sensors standard. / Drum hub reduction / drum wheel-reduction drive axle / Rim mounting pilot diameter Φ280.8mm
FAQ
What kind of truck is Meritor Meritor drive axle axle?
Meritor Meritor drive axle is an export-oriented axle lineup with about 27 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is axle typically used for?
For axle, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Meritor drive axle include?
Meritor drive axle currently lists about 27 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Meritor drive axle?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
