Foton Ruiwo Q9 350 hp 6X4(10 wheels) 6m Dump Truck
EXW
From $39,625
Export quote
Foton Q9 heavy-duty truck Dump Trucks
Main model photos
150 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Foton Ruiwo Q9 350 hp 6X4(10 wheels) 6m Dump Truck | 6x4 / 350hp / China V | From $39,625 | |
| Foton Ruowo Q9 336hp 6X4(10 wheels) 6m Dump Truck | 6x4 / 350hp / China V | From $39,111 | |
| Foton Ruowo Q9 350hp 6X4(10 wheels) 5.8m Dump Truck | 6x4 / 350hp / China V | From $39,542 | |
| Foton Ruowo Q9 336hp 6X4(10 wheels) 5.8m Dump Truck | 6x4 / 336hp / China V | From $39,028 | |
| Foton Ruiwo Q9RB 220 hp 6X2(8 wheels) 7.4m Dump Truck | 6x2 / 220hp / China V | From $33,333 |
Foton Ruowo Q9 336hp 6X4(10 wheels) 6m Dump Truck
EXW
From $39,111
Export quote
Foton Ruowo Q9 350hp 6X4(10 wheels) 5.8m Dump Truck
EXW
From $39,542
Export quote
Foton Ruowo Q9 336hp 6X4(10 wheels) 5.8m Dump Truck
EXW
From $39,028
Export quote
Foton Ruiwo Q9RB 220 hp 6X2(8 wheels) 7.4m Dump Truck
EXW
From $33,333
Export quote
Series Specs
Basic Info
Model code (announced): BJ3255DLPJB-FC / BJ3255DLPJB-FB / BJ3255DLPHH-FA / BJ3255DLPHB-FB / BJ3315DNPHC-FE / BJ3255DLPJB-FA / BJ3315DPPHC-FA / BJ3315DNPJC-FA / BJ3315DNPHC-FA / BJ3315DNPJC-FC / BJ3315DNPHC-22 / BJ3315DNPHC-34 / BJ3315DNPHC-26 / BJ3313DMPJF-8 / BJ3313DMPJF-7 / BJ3315DNPKC-1 / BJ3315DNPKF-1 / BJ3315DNPHC-27 / BJ3315DNPHC-25
Drive type: 6X4 / 6X2 / 8X4
Wheelbase: 4100+1350 / 3900+1350 / 1800+4700 / 1800+3400 / 1800+3100+1350 / 1800+2800+1350 / 3700+1350 / 1800+2800+1300 / 1800+2850+1350 / 1800+2500+1350 / 1800+3450+1300 / 1800+3250+1300 / 1800+3000+1300 / 1800+3650+1350 / 1800+4200+1350 / 1800+3950+1350 / 1800+4300+1350 / 1800+3850+1350 / 1800+3450+1350mm
Engine Model: WeichaiWP10.350E53 / WeichaiWP10.336E53 / YuchaiYC6J220-52 / YuchaiYC6J180-52 / YuchaiYC6A270-50 / WeichaiWP10.310E53 / YuchaiYC6JA240-50 / WeichaiWP7.300E51 / WeichaiWP7.270E51 / YuchaiYC6A260-46 / WeichaiWP10.290E41 / WeichaiWP10.336E40 / WeichaiWP10.310E41 / WeichaiWP7.270E40
Transmission Model: Fast Gear12JSD180 / Fast Gear8JS85E / Fast Gear10JS90A / Fast Gear10JSD120B / Fast Gear10JSD160 / Fast Gear8JS110A / Fast Gear12JSD160 / Fast Gear 10-Speed / Fast Gear9JS119A / Fast Gear12JSD160TA / Fast Gear10JSD140B
Rear Axle Ratio: 5.286 / 5.29 / 5.571 / 6.167 / 4.8 / 4.87 / 5.73 / 5.833 / 5.26
Cab length: 8.896 / 8.694 / 10.12 / 8.405 / 8.87 / 8.296 / 8.494 / 8.668 / 8.468 / 9.878 / 9.458 / 9.485 / 9.46 / 10.25 / 10.961 / 10.77 / 10.498 / 11.088 / 10.088 / 9.738 / 10.362 / 10.45 / 10.05m
Cab width: 2.495 / 2.54 / 2.36m
Cab height: 3.425 / 2.96 / 2.94 / 3.1 / 3.45 / 3.15 / 3.2 / 3.03 / 3.42 / 3.39 / 3.52 / 2.92m
Front track width: 2024 / 1908/1908 / 1820/1820 / 1896/1896 / 1882/1882 / 1860/1860,1882/1882,1896/1896,1950/1950 / 1940/1940 / 1960/1960 / 1860/1860 / 2024/2024 / 1900/1900 / 1930/1930 / 2044/2044mm
rear track: 1880/1880 / 1860 / 1740 / 1777/1777 / 1728/1728,1777/1777,1864/1864 / 1860/1860 / 1728/1728 / 1864/1864 / 1865/1865mm
Curb Weight: 12.5 / 11.905 / 11.405 / 14.77 / 11.8 / 14.765 / 14.81 / 10.95ton
Rated payload: 12.37 / 12.965 / 12.9 / 16.1 / 19.005 / 16.105 / 15.995 / 16.06ton
GVWR: 25 / 24.5 / 31ton
Origin: Shandong Zhucheng
tonnage class: Heavy truck / Medium-duty truck / Light Truck
Approach angle: 15 / 20 / 19 / 16 / 25 / 24 / 26°
departure angle: 15 / 16 / 18 / 17 / 20 / 25 / 21 / 19 / 42°
Remarks: Recirculating ball power steering / Recirculating ball power steering, optional spare tire / Recirculating ball power steering; optional rear axle 457CS, spare tire / Power steering, spare tire, optional A/C / Recirculating ball power steering; optional rear axle STR10CS, spare tire / Spare tire
Energy Type: Diesel
Engine parameters
Engine Brand: Weichai / Yuchai
Number of cylinders: 6cylinder
Displacement: 9.726 / 6.494 / 7.52 / 6.87 / 7.47 / 7.255 / 7.14L
Emission standard: China V / China IV
Max output power: 257 / 247 / 162 / 132 / 199 / 228 / 177 / 220 / 191 / 213kW
Max hp: 350 / 336 / 220 / 180 / 270 / 310 / 240 / 300 / 260 / 290Horsepower
Max torque: 1600 / 1550 / 860 / 700 / 1100 / 1500 / 950 / 1250 / 1160 / 1000 / 1180N·m
Max torque speed: 1200-1600 / 1200-1500 / 1200-1800 / 1200-1700 / 1300-1600rpm
Rated speed: 1900 / 2300 / 2200rpm
Engine Type: Electronic high-pressure common rail + SCR / Water-cooled, 4-stroke, with exhaust brake, direct injection, turbocharged intercooled, electronically controlled high-pressure common rail SCR / Vertical, inline 6-cylinder, water-cooled, 4-stroke / 6-cylinder, inline, 4-stroke, 4-valve, common-rail direct injection, turbocharged intercooled / Vertical, inline, water-cooled, four-stroke / Inline 6-cylinder, electronically controlled high-pressure common rail + SCR / Inline 6-cylinder, electronic high-pressure common rail, SCR / Vertical, inline, water-cooled, four-stroke, direct injection / Water-cooled, four-stroke, with exhaust brake, direct injection, turbocharged intercooled, electronic high-pressure common rail + SCR / Water-cooled, four-stroke, with exhaust brake, direct injection, turbocharged intercooled / Electronically controlled high-pressure common rail SCR
Transmission Parameters
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 12 / 8 / 10 / 9Gear
Number of Reverse Gears: 2 / 1pcs
Cargo box parameters
hydraulic cylinder brand & model: Front-mounted cylinder F185 / 160 / 185
Unloading Type: Dump type
Cargo box type: Dump type
Cargo box length: 6 / 5.8 / 7.4 / 5.6 / 5.4 / 7 / 6.6 / 6.8 / 8 / 7.8 / 8.2 / 7.6 / 7.2m
Cargo box width: 2.3 / 2.2m
Body Parameters
Lifting type: Front lift cylinder / 160 front-mounted lift / 185 front lift
FAQ
What kind of truck is Foton Foton Q9 heavy-duty truck Dump Trucks?
Foton Foton Q9 heavy-duty truck is an export-oriented Dump Trucks lineup with about 157 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Foton Q9 heavy-duty truck Dump Trucks?
Foton Q9 heavy-duty truck Dump Trucks export reference is about $24,028 – $52,819. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Foton Q9 heavy-duty truck Dump Trucks cover?
Foton Q9 heavy-duty truck Dump Trucks mainly covers: Drive: 6x2 / 6x4; Horsepower: 220 hp / 336 hp / 350 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Foton Q9 heavy-duty truck Dump Trucks?
For Foton Q9 heavy-duty truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Foton Q9 heavy-duty truck Dump Trucks include?
Foton Q9 heavy-duty truck Dump Trucks currently lists about 157 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Foton Q9 heavy-duty truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
