SHACMAN Longxiao Elite Edition 530hp 8X4(12 wheels) 7.6m CNG Dump Truck
EXW
Export quote
SHACMAN Longxiao Dump Trucks
Main model photos
61 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| SHACMAN Longxiao Elite Edition 530hp 8X4(12 wheels) 7.6m CNG Dump Truck | 8x4 / 530hp / China VI | ||
| SHACMAN Cummins Longxiao Highway Standard Elite Edition 600 hp 8X4(12 wheels) 8 m Dump Truck | 8x4 / 600hp / China VI | From $67,069 | |
| SHACMAN Cummins Longxiao Highway Standard Elite Edition 490 hp 8X4(12 wheels) 8 m Dump Truck | 8x4 / 490hp / China VI | From $59,778 | |
| SHACMAN Cummins Longxiao Highway Standard Elite Edition 490 hp 8X4(12 wheels) 7.6 m Dump Truck | 8x4 / 490hp / China VI | From $59,639 | |
| SHACMAN Cummins Longxiao Highway Standard Elite Edition 490 hp 8X4(12 wheels) 7.2 m Dump Truck | 8x4 / 490hp / China VI | From $59,361 |
SHACMAN Cummins Longxiao Highway Standard Elite Edition 600 hp 8X4(12 wheels) 8 m Dump Truck
EXW
From $67,069
Export quote
SHACMAN Cummins Longxiao Highway Standard Elite Edition 490 hp 8X4(12 wheels) 8 m Dump Truck
EXW
From $59,778
Export quote
SHACMAN Cummins Longxiao Highway Standard Elite Edition 490 hp 8X4(12 wheels) 7.6 m Dump Truck
EXW
From $59,639
Export quote
SHACMAN Cummins Longxiao Highway Standard Elite Edition 490 hp 8X4(12 wheels) 7.2 m Dump Truck
EXW
From $59,361
Export quote
Series Specs
Basic Info
Model code (announced): SX3319XE6 / SX3319XD426 / SX33195D406 / SX33195D366 / SX33195D346 / SX5319ZLJ5D326 / SX33195D326
Drive type: 8X4
Wheelbase: 1950+4025+1400 / 1950+3825+1400 / 1950+3425+1400 / 1950+3225+1400 / 1950+3025+1400mm
Engine Model: Cummins15NNS6B530A / Xi’an CumminsM15NS6B600 / Xi’an CumminsX12NS6B490
Transmission Model: Fast GearS13MDQ
Rear Axle Ratio: 5.92
Cab length: 11.42 / 10.95 / 10.55 / 10.15 / 9.75 / 9.45m
Cab width: 2.55m
Cab height: 3.6 / 3.5m
Front track width: 2036/2036mm
rear track: 1860/1860mm
Curb Weight: 15.5ton
Rated payload: 15.37ton
GVWR: 31ton
Origin: Baoji, Shaanxi
tonnage class: Heavy truck
Approach angle: 17°
departure angle: 17°
Remarks: Standard: construction bumper, hydraulic cab mount, Tianxingjian Zhiya Edition, desert air filter, telescopic shaft with flexible shift, PTO, maintenance-free battery, radiator grille guard, construction appearance; Optional: Longxiao extended high-roof cab without deflector, Tianxingjian Zhixing Edition (with reverse camera), 400L dual-chamber aluminum fuel tank (water-heated), LED headlights, electric tilting cab, dump body floor heating, oil bath air filter, off-road tread tires, mining tread tires, extended tool kit (passenger ashtray, water bottle holder, jack, crowbar, vehicle tool kit).
Version: Elite Edition / Highway standard elite edition
Energy Type: Compressed Natural Gas (CNG) / Diesel
Engine parameters
Engine Brand: Cummins / Xi’an Cummins
Number of cylinders: 6cylinder
Displacement: 14.5 / 11.8L
Emission standard: China VI
Max output power: 390 / 441 / 360kW
Max hp: 530 / 600 / 490Horsepower
Max torque: 2500 / 2800 / 2300N·m
Max torque speed: 1000-1400 / 900-1400rpm
Rated speed: 1900 / 1800rpm
Transmission Parameters
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 13Gear
Number of Reverse Gears: 2 / 1pcs
Housing Material: aluminum housing
Cargo box parameters
Cargo box thickness: D8B6
Unloading Type: Dump type
Cargo box type: Dump type
Cargo box length: 7.6 / 8 / 7.2 / 6.8 / 6.5m
fuel tank
Air tank capacity: 260*8L
FAQ
What kind of truck is SHACMAN SHACMAN Longxiao Dump Trucks?
SHACMAN SHACMAN Longxiao is an export-oriented Dump Trucks lineup with about 8 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for SHACMAN Longxiao Dump Trucks?
SHACMAN Longxiao Dump Trucks export reference is about $59,083 – $67,069. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does SHACMAN Longxiao Dump Trucks cover?
SHACMAN Longxiao Dump Trucks mainly covers: Drive: 8x4; Horsepower: 490 hp / 530 hp / 600 hp; Emission: China VI; Fuel: Compressed Natural Gas (CNG) / Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in SHACMAN Longxiao Dump Trucks?
For SHACMAN Longxiao Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does SHACMAN Longxiao Dump Trucks include?
SHACMAN Longxiao Dump Trucks currently lists about 8 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for SHACMAN Longxiao Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
