Dongfeng H5 4X2(6 wheels) 5m Electric Dump Truck CATL 310.66kWh
EXW
From $69,444
Export quote
Dongfeng H5 Heavy Truck electric dump truck
Main model photos
1,993 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng H5 4X2(6 wheels) 5m Electric Dump Truck CATL 310.66kWh | 4x2 | From $69,444 | |
| Dongfeng H5 8X4(12 wheels) 8.1m cab-over-chassis swap battery electric dump truck CATL 400.61kWh | 8x4 | From $93,056 | |
| Dongfeng H5 8X4(12 wheels) 8m cab-over-chassis swap battery electric dump truck CATL 400.61kWh | 8x4 | From $91,667 | |
| Dongfeng H5 8X4(12 wheels) 7.7m cab-over-chassis swap battery electric dump truck CATL 400.61kWh | 8x4 | From $93,056 | |
| Dongfeng H5 8X4(12 wheels) 7.6m Crew Cab Battery Swap Pure Electric Dump Truck CATL 400.61kWh | 8x4 | From $91,667 |
Dongfeng H5 8X4(12 wheels) 8.1m cab-over-chassis swap battery electric dump truck CATL 400.61kWh
EXW
From $93,056
Export quote
Dongfeng H5 8X4(12 wheels) 8m cab-over-chassis swap battery electric dump truck CATL 400.61kWh
EXW
From $91,667
Export quote
Dongfeng H5 8X4(12 wheels) 7.7m cab-over-chassis swap battery electric dump truck CATL 400.61kWh
EXW
From $93,056
Export quote
Dongfeng H5 8X4(12 wheels) 7.6m Crew Cab Battery Swap Pure Electric Dump Truck CATL 400.61kWh
EXW
From $91,667
Export quote
Inventory
Dongfeng Liuqi Chenglong H5 Heavy Truck Long Range Version 8X4(12 wheels) 7.8m Battery Swap Pure Electric Dump Truck 350kWh
EXW
From $138,889
Export quote
Dongfeng Liuqi Chenglong H5 Heavy Truck Long Range Edition 8X4(12 wheels) Battery Swap Pure Electric Dump Truck 350kWh
EXW
Export quote
DongfengLiuqi Chenglong H5 Heavy Truck All-Round Version 8X4(12 wheels) 5.8m Battery Swap Electric Dump Truck 282kWh
EXW
Export quote
DongfengLiuqi Chenglong H5 Heavy Truck Composite Version 8X4(12 wheels) Battery Swap Electric Dump Truck 282kWh
EXW
Export quote
Series Specs
Basic Info
Model code (announced): LZ3180H5AZBEV01 / LZ3310H7FZBEV01 / LZ3310H5FZBEV111 / LZ3310H5FZBEV141 / LZ3310H5FZBEV01 / LZ3250H5DZBEV111 / LZ3310H5FZBEV161 / LZ3310H5FZBEV121
Drive type: 4X2 / 8X4 / 6X4
Wheelbase: 4200 / 2050+4750+1350 / 2050+4400+1350 / 2050+3750+1350 / 2050+4150+1350 / 2050+3350+1350 / 2050+2950+1350 / 1800+4650+1350 / 4050+1350 / 4500 / 1800+4000+1350 / 3850+1350mm
Cab length: 7.595 / 11.925 / 11.575 / 11.475 / 10.715 / 10.515 / 11.825 / 11.225 / 11.075 / 10.875 / 10.675 / 10.475 / 10.075 / 9.915 / 9.675 / 9.515 / 10.115 / 9.715 / 8.875 / 8.675 / 7.975m
Cab width: 2.545 / 2.5 / 2.55m
Cab height: 3.3 / 3.8 / 3.65 / 3.45 / 3.6 / 3.68m
Curb Weight: 11.7 / 23.4 / 22.4 / 21.4 / 22.7 / 21.7 / 19.3 / 17.6 / 18.7 / 24 / 20 / 21.44ton
Rated payload: 6.105 / 7.47 / 8.47 / 9.47 / 8.17 / 9.17 / 11.57 / 13.27 / 6.17 / 6.87 / 10.17 / 11.37ton
GVWR: 18 / 31 / 25ton
Max. speed: 89km/h
Origin: Liuzhou, Guangxi
tonnage class: Medium-duty truck / Heavy truck
Remarks: Battery side-mounted / Rear-mounted battery / Side-mounted battery
Energy Type: Electric
electric motor
Motor 1 Brand: Fast Gear
Motor 1 Model: TZ375XSSF-SZF601 / TZ375XSF60-FS01
Motor Type: Permanent magnet synchronous motor
total rated power: 262 / 330kW
Peak power: 405 / 460kW
Battery/Charging
Battery Brand: CATL / Shanghai Qiyuan / Qiyuan
Battery type: Lithium Iron Phosphate Battery
Battery capacity: 310.66 / 400.61 / 400.62 / 352.08 / 281.91 / 600.92 / 400.9 / 350.07 / 400.619kWh
Transmission Parameters
Number of gears: 6Gear
shift type: AMT manual/auto
Transmission Model: Fast Gear 6E240
Transmission Brand: Fast Gear
Forward gears: 6Gear
Number of Reverse Gears:
Cargo box parameters
Cargo box type: Dump type
Cargo box length: 5 / 8.1 / 8 / 7.7 / 7.6 / 6.8 / 6.5 / 7.8 / 7.4 / 7.2 / 7 / 6.2 / 6 / 5.8 / 5.6 / 5.4 / 5.3 / 8.7 / 8.6m
Cargo box width: 2.35 / 2.3m
Cargo box height: 1.5 / 0.8m
Cab parameters
Cab: H52 (mid floor) / H52
seating capacity: 2Personnel
Seat rows: Sleeper cab
Chassis Specs
Front axle allowable load: 6500 / 6500/6500 / 7000kg
rear axle description: 25T hub reduction axle / 2x25T wheel reduction axle / 2x20T wheel reduction axle / 2*440 axle (16mm thick axle housing)
rear axle allowable load: 11500 / 18000 (tandem axle group)kg
Tire
Tire Size: 11.00R20 18PR / 12.00R20 18PR / 12.00R20 16PR
Number of tires: 6 / 12 / 10pcs
FAQ
What kind of truck is Dongfeng Dongfeng H5 Heavy Truck electric dump truck?
Dongfeng Dongfeng H5 Heavy Truck is an export-oriented electric dump truck lineup with about 58 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Dongfeng H5 Heavy Truck electric dump truck?
Dongfeng H5 Heavy Truck electric dump truck export reference is about $69,444 – $138,889. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Dongfeng H5 Heavy Truck electric dump truck cover?
Dongfeng H5 Heavy Truck electric dump truck mainly covers: Drive: 4x2 / 8x4. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Dongfeng H5 Heavy Truck electric dump truck?
For Dongfeng H5 Heavy Truck electric dump truck: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is electric dump truck typically used for?
electric dump truck is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Dongfeng H5 Heavy Truck electric dump truck include?
Dongfeng H5 Heavy Truck electric dump truck currently lists about 58 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Dongfeng H5 Heavy Truck electric dump truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
