Foton Medium 154 hp 4X2(6 wheels) 4.8m Dump Truck (Fast Gear 10-speed)
EXW
From $27,125
Export quote
Foton Medium Truck Dump Trucks
Main model photos
140 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Foton Medium 154 hp 4X2(6 wheels) 4.8m Dump Truck (Fast Gear 10-speed) | 4x2 / 154hp / China V | From $27,125 | |
| Foton Medium 154 hp 4X2(6 wheels) 4.5m dump truck (Fast Gear 10-speed) | 4x2 / 154hp / China V | From $27,125 | |
| Foton Medium Q5 154 hp 4X2(6 wheels) 4.8m Dump Truck | 4x2 / 154hp / China V | From $26,778 | |
| Foton Medium Q5 154 hp 4X2(6 wheels) 4.5m Dump Truck | 4x2 / 154hp / China V | From $26,847 | |
| Foton Medium RC 170hp 6X2(8 wheels) 5.2m dump truck | 6x2 / 170hp / China V | From $34,722 |
Foton Medium 154 hp 4X2(6 wheels) 4.5m dump truck (Fast Gear 10-speed)
EXW
From $27,125
Export quote
Foton Medium Q5 154 hp 4X2(6 wheels) 4.8m Dump Truck
EXW
From $26,778
Export quote
Foton Medium Q5 154 hp 4X2(6 wheels) 4.5m Dump Truck
EXW
From $26,847
Export quote
Foton Medium RC 170hp 6X2(8 wheels) 5.2m dump truck
EXW
From $34,722
Export quote
Series Specs
Basic Info
Model code (announced): BJ3166DKPED-1 / BJ3223DLPEB-FA / BJ3255DLPHB-FB / BJ3165DJPFG-FA / BJ3165DJPFA-FA / BJ3255DLPHE-4 / BJ3225DLPFE-2 / BJ3255DLPHE-2 / BJ3225DLPFB-2 / BJ3165DJPFK-1 / BJ3165DKPFG-1 / BJ3165DJPHK-1 / BJ3165DJPHD-1 / BJ3165DJPHD-2 / BJ3122DEPHD-G1 / BJ3165DJPHA-1 / BJ3165DJPFA-1 / BJ3195DKPFB-4 / BJ3072DDPEA-G3 / BJ3145DJPFG-1 / BJ3045D9PEA-1
Drive type: 4X2 / 6X2
Wheelbase: 4200 / 1800+3600 / 1800+3400 / 5000 / 3900 / 1800+4700 / 1800+4500 / 1800+4200 / 1800+3900 / 1800+4100 / 1800+3700 / 4700 / 4500 / 3300 / 5400 / 1800+3800 / 3400 / 4100mm
Engine Model: FotonISF3.8s5154 / YuchaiYC4EG170-50 / YuchaiYC6J180-52 / WeichaiWP6.180E40 / WeichaiWP6.220E40 / FotonISF3.8s4R168 / YuchaiYC6J160-42 / FotonISF3.8s4R141 / YuchaiYC4E140-42 / WeichaiWP6.240E40 / WeichaiWP6.245E40 / YuchaiYC6J180-42 / YuchaiYC6J160-46 / YuchaiYC4D130-45 / YangchaiYZ4DA2-40
Transmission Model: Fast Gear10JS90 / Fast Gear8JS85E / Fast Gear10JS90A / WLYWLY8S90 / Fast Gear8JS110A / Fast Gear8JS118 / WLYWLY8S90A / Fast Gear8JS85F / Fast Gear 8-speed / 10-speed / WLYWLY545ZHF
Rear Axle Ratio: 6.33 / 5.286 / 5.143 / 5.571 / 5.73 / 6.72 / 6.833 / 5.833
Cab length: 7.545 / 7.245 / 7.91 / 7.94 / 8.93 / 6.92 / 10.12 / 10.4 / 9.92 / 9.75 / 9.096 / 9.296 / 8.796 / 8.51 / 8.99 / 8.84 / 8.915 / 8.23 / 8.31 / 8.13 / 8.03 / 7.83 / 7.13 / 7.63 / 7.22 / 7.315 / 6.99 / 7.29 / 6.13 / 9.24 / 9.55 / 6.37 / 10.14 / 7.56 / 5.99 / 7.265m
Cab width: 2.495 / 2.37 / 2.47 / 2.414 / 2.508 / 2.5 / 2.485 / 2.25 / 2.472 / 2.38 / 2.15 / 2150m
Cab height: 3.01 / 2.85 / 2.88 / 2.96 / 3.04 / 2.93 / 2.87 / 3.08 / 2.9 / 2.785 / 2.905 / 2.975 / 2.98 / 2.79 / 2.86 / 2.755 / 2.65 / 3.06m
Front track width: 1940 / 1785/1785 / 1820/1820 / 1896/1896 / 1886/1886 / 1896 / 1890/1890 / 1950 / 1826 / 1995 / 1963/1924 / 1761 / 1725 / 1780 / 1655 / 1897mm
rear track: 1851 / 1728 / 1740 / 1860 / 1864 / 1860/1851 / 1721 / 1638 / 1655 / 1725 / 1669mm
Curb Weight: 8 / 10.29 / 11.405 / 7.815 / 11.905 / 11.915 / 7.68 / 7.615 / 7.9 / 6.6 / 9.345 / 4.17 / 6.5 / 2.72ton
Rated payload: 7.87 / 7.805 / 11.115 / 12.9 / 7.99 / 11.1 / 4.99 / 9.86 / 3 / 6.885 / 1.645 / 8.055ton
GVWR: 16 / 21.6 / 24.5 / 25 / 15.8 / 11.785 / 19.4 / 4.17 / 13.58 / 4.495ton
Origin: Shandong Zhucheng
tonnage class: Medium-duty truck / Light Truck
Approach angle: 20 / 28 / 19 / 25 / 26 / 16 / 29 / 27 / 23°
departure angle: 16 / 22 / 15 / 17 / 14 / 18 / 12 / 21 / 24°
Remarks: A/C, optional metallic paint, electronic flameout, power steering, clutch booster / Power steering, spare tire, optional A/C / Recirculating ball power steering, optional spare tire
Energy Type: Diesel
Engine parameters
Engine Brand: Foton / Yuchai / Weichai / Yangchai
Number of cylinders: 4 / 6cylinder
Displacement: 3.76 / 4.73 / 6.494 / 6.75 / 6.5 / 4.26 / 4.214 / 3.66L
Emission standard: China V / China IV
Max output power: 115 / 125 / 132 / 162 / 118 / 105 / 103 / 176 / 180 / 96 / 83kW
Max hp: 154 / 170 / 180 / 220 / 168 / 160 / 141 / 140 / 240 / 245 / 130 / 113Horsepower
Max torque: 491 / 600 / 700 / 680 / 850 / 550 / 450 / 430 / 900 / 650 / 420 / 300N·m
Max torque speed: 1200-1900 / 1300-1800 / 1200-1800 / 1400-1600 / 1300-1700 / 1200-1700 / 1200-2200 / 1300-1600 / 1100-1700 / 1400-1700 / 1400-1800 / 1000-1600rpm
Rated speed: 2600 / 2500 / 2300 / 2800 / 2900rpm
Engine Type: Electronically controlled high-pressure common rail / Vertical, inline, water-cooled, four-stroke, high-pressure common rail / 6-cylinder, inline, 4-stroke, 4-valve, common-rail direct injection, turbocharged intercooled / Electronic high-pressure common rail + SCR / Vertical, inline 4-cylinder, water-cooled, 4-stroke, electronic direct injection / BOSCH high-pressure common rail SCR / Vertical, inline 6-cylinder, water-cooled, 4-stroke, electronic direct injection / Turbocharged Air-to-Air Intercooling Bosch High-Pressure Common Rail Direct Injection SCR / 4-stroke, water-cooled, vertical inline, direct injection, wet cylinder liner / Vertical, inline, water-cooled, four-stroke, direct injection / Electronic unit pump EGR + POC + DOC / Inline, water-cooled, 4-stroke, turbocharged with intercooler
Technology route: Common Rail SCR
Transmission Parameters
Transmission Brand: Fast Gear / WLY
shift method: Manual
Forward gears: 10 / 8 / 5Gear
Number of Reverse Gears: 2 / 1pcs
Cargo box parameters
hydraulic cylinder brand & model: F160
Unloading Type: Dump type / Rear-dump body / Side-dump tipper.
Cargo box length: 4.8 / 4.5 / 5.2 / 5.6 / 6.5 / 7.2 / 7.4 / 7 / 6.3 / 6 / 5.3 / 5.4 / 5 / 4.7 / 3.7 / 6.8 / 4m
Cargo box width: 2.3 / 2.2 / 2.07 / 2.17m
Body Parameters
Lifting type: Front lift F160 / Front lift cylinder
FAQ
What kind of truck is Foton Foton Medium Truck Dump Trucks?
Foton Foton Medium Truck is an export-oriented Dump Trucks lineup with about 57 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Foton Medium Truck Dump Trucks?
Foton Medium Truck Dump Trucks export reference is about $13,889 – $36,736. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Foton Medium Truck Dump Trucks cover?
Foton Medium Truck Dump Trucks mainly covers: Drive: 4x2 / 6x2; Horsepower: 154 hp / 170 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Foton Medium Truck Dump Trucks?
For Foton Medium Truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Foton Medium Truck Dump Trucks include?
Foton Medium Truck Dump Trucks currently lists about 57 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Foton Medium Truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
