FARIZON X7E 6X4(10 wheels) 6.5m Battery Swap Electric Half-Cab Dump Truck Xuanwu 440kWh
EXW
From $90,000
Export quote
FARIZONX7E electric dump truck
Main model photos
65 photos
Models
On sale
FARIZON X7E 6X4(10 wheels) 6.5m Battery Swap Electric Half-Cab Dump Truck CATL 282kWh
EXW
Export quote
FARIZON X7E 6X4(10 wheels) 6.2m Battery Swap Pure Electric Crew Cab Dump Truck Xuanwu 440kWh
EXW
From $89,722
Export quote
FARIZON X7E 6X4(10 wheels) 6.2m Battery Swap Pure Electric Crew Cab Dump Truck CATL 282kWh
EXW
Export quote
FARIZON X7E 6X4(10 wheels) 6m Battery Swap Pure Electric Crew Cab Dump Truck Xuanwu 440kWh
EXW
From $89,444
Export quote
Series Specs
Basic Info
Model code (announced): HN3250H55D2BEVY / HN3313H45C2BEVY / HN3316H45C2BEVY / HN3312H22C2BEVY / HN3310H22C2BEVY / HN3311H22C2BEVY
Drive type: 6X4 / 8X4
Wheelbase: 4500+1350 / 4200+1350 / 1850+3200+1350mm
Cab length: 9.55 / 9.35 / 9.05 / 8.85 / 8.75 / 9.85 / 9.65 / 9.7 / 9.78m
Cab width: 2.55m
Cab height: 3.8 / 3.58 / 3.59 / 3.85m
CLTC range: 420 / 258 / 280 / 230 / 188km
Curb Weight: 20.5 / 19.8 / 18.5 / 21 / 19 / 18.1ton
Rated payload: 4.37 / 5.07 / 12.37 / 9.87 / 11.87 / 12.77ton
GVWR: 25 / 31ton
Max. speed: 85km/h
Origin: Ma'anshan / Ma'anshan, Anhui
tonnage class: Medium-duty truck / Heavy truck
Energy Type: Electric
electric motor
Motor 1 Brand: Hualing / Anhui Hualing / Kaibo
Motor 1 Model: TZ460XSHME14 / TZ460XSHME10 / EK140750PMS1/EK140750PMS1
Motor Type: Permanent magnet synchronous motor
total rated power: 360 / 315 / 280kW
Peak power: 550 / 450 / 440kW
Motor 1 Peak Power: 550kW
Battery/Charging
Battery Brand: Xuanwu / CATL / Huzhou Zhixin / Smart Core
Battery type: Lithium Iron Phosphate Battery
Battery capacity: 440 / 282 / 403 / 660 / 391.68 / 391 / 423 / 350kWh
Transmission Parameters
Number of gears: 4Gear
shift type: Manual
Transmission Model: 4-speed / J4S280(QL) with PTO
Cargo box parameters
Cargo box type: Rear dump / Dump type
Cargo box length: 6.5 / 6.2 / 6 / 5.8 / 5.6m
Cargo box width: 2.35 / 2.3m
Cargo box height: 1.5 / 1.2m
Cab parameters
Cab: X7 flat roof / X7E
seating capacity: 2Personnel
Seat rows: Sleeper cab
Chassis Specs
Front axle allowable load: 7000 / 6500/6500kg / 6500/6500
rear axle description: 23T cast steel mid-rear axle / 16T / HL300A(5.921) Cast Steel Mid-Rear Axle
rear axle allowable load: 18000 (tandem axle group)kg
Tire
Tire Size: 12.00R20 16PR / 12.00R20 18PR / 11.00R20 18PR
Number of tires: 10 / 12pcs
Control configuration
ABS:
Power steering: Electric Power Steering
FAQ
What kind of truck is FARIZON FARIZONX7E electric dump truck?
FARIZON FARIZONX7E is an export-oriented electric dump truck lineup with about 18 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for FARIZONX7E electric dump truck?
FARIZONX7E electric dump truck export reference is about $88,889 – $90,000. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does FARIZONX7E electric dump truck cover?
FARIZONX7E electric dump truck mainly covers: Drive: 6x4. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in FARIZONX7E electric dump truck?
For FARIZONX7E electric dump truck: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is electric dump truck typically used for?
electric dump truck is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does FARIZONX7E electric dump truck include?
FARIZONX7E electric dump truck currently lists about 18 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for FARIZONX7E electric dump truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
