Dongfeng Tianjin KR 8X4(12 wheels) Pure Electric Box Cargo Truck CATL 352kWh
EXW
Export quote
Dongfeng Commercial Vehicle Dongfeng Tianjin KR
Main model photos
1,020 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng Tianjin KR 8X4(12 wheels) Pure Electric Box Cargo Truck CATL 352kWh | 8x4 | ||
| Dongfeng Tianjin KR 4X2(6 wheels) 6.8m Pure Electric Van Cargo Truck CATL 310kWh | 4x2 | ||
| Dongfeng Tianjin KR 4X2(6 wheels) Electric Hook Lift Cargo Truck CATL 262kWh | 4x2 | From $45,833 | |
| Dongfeng Tianjin KR 4X2(6 wheels) 9.75m Electric Van Cargo Truck CATL 262kWh | 4x2 | From $48,611 | |
| Dongfeng Tianjin KR 4X2(6 wheels) 9.75m Electric Van Cargo Truck CATL 262kWh | 4x2 | From $48,611 |
Dongfeng Tianjin KR 4X2(6 wheels) 6.8m Pure Electric Van Cargo Truck CATL 310kWh
EXW
Export quote
Dongfeng Tianjin KR 4X2(6 wheels) Electric Hook Lift Cargo Truck CATL 262kWh
EXW
From $45,833
Export quote
Dongfeng Tianjin KR 4X2(6 wheels) 9.75m Electric Van Cargo Truck CATL 262kWh
EXW
From $48,611
Export quote
Dongfeng Tianjin KR 4X2(6 wheels) 9.75m Electric Van Cargo Truck CATL 262kWh
EXW
From $48,611
Export quote
Series Specs
Basic Info
Model code (announced): DFH5180XXYEEV13 / DFC5180ZKXAXEV13 / DFH5180XXYEXEV13 / DFH5180XYKEXEV13 / DFH5180XYKEXEV6 / DFH5180XXYEEV6 / DFH5180CCYEEV13 / DFH1180EEV13
Type: enclosed cargo truck / Cargo Trucks / stake truck
Drive type: 8X4 / 4X2
Wheelbase: 1850+3650+1350 / 5000 / 7150mm
Box length class: 6.8 / 9.8 / 9.7m
Cab length: 10.335 / 9.05 / 12 / 9m
Cab width: 2.515 / 2.55 / 2200m
Cab height: 3.78 / 4 / 3.695 / 3.99 / 3.9 / 3.86 / 3.68 / 3.11 / 3.88m
CLTC range: 280 / 350 / 298 / 460km
Curb Weight: 9.5 / 8 / 9.88 / 10.6 / 10.08 / 8.5 / 8.6 / 8.2ton
Rated payload: 8.37 / 9.87 / 7.99 / 7.27 / 7.79 / 9.37 / 9.27 / 9.67 / 9.205ton
GVWR: 31 / 18ton
Max. speed: 89km/h
Origin: Shiyan, Hubei
tonnage class: Heavy truck / Medium-duty truck
Energy Type: Electric
electric motor
Motor 1 Brand: Suzhou Green Control / Dongfeng
Motor 1 Model: TZ460XS-LKM3101 / TZ270XS-LKM0592 / TZ230XS050DN01 / TZ230XS055DN02
Motor Type: Permanent magnet synchronous motor
total rated power: 270 / 150 / 90 / 130kW
Peak power: 450 / 252 / 160 / 230kW
total peak torque: 550 / 500N·m
total rated torque: 260 / 200 / 250N·m
Battery/Charging
Battery Brand: CATL / Rept Battero / EVE / Ruipu
Charging method: single-gun DC
Battery type: Lithium Iron Phosphate Battery
Battery capacity: 352 / 310 / 262 / 162 / 141 / 265 / 332kWh
fast charge time: 0.67h
Cargo box parameters
Cargo box volume: 62 / 58.5m³
Cargo box type: Van body / Wing Van / Stake type / stake body
Cargo box length: 6.8 / 9.75 / 9.7 / 6.75m
Cargo box width: 2.45m
Cargo box height: 2.6 / 2.45 / 0.6m
Cab parameters
Cab: D560e Flat Roof with Half Sleeper / D560e
Cab tilting: Hydraulic electric / Hydraulic machinery
seating capacity: 2Personnel
Seat rows: Sleeper cab
Chassis Specs
Front axle allowable load: 6500/6500 / 6500kg
rear axle description: LvKong STEA39000 / LvKong STEA39000Z / DongfengEP28D
rear axle allowable load: 18000 (tandem axle group) / 11500kg
FAQ
What kind of truck is Dongfeng Commercial Vehicle Dongfeng Tianjin KR electric cargo truck?
Dongfeng Commercial Vehicle Dongfeng Tianjin KR is an export-oriented electric cargo truck lineup with about 16 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Dongfeng Commercial Vehicle Dongfeng Tianjin KR?
Dongfeng Commercial Vehicle Dongfeng Tianjin KR export reference is about $35,000 – $52,778. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Dongfeng Commercial Vehicle Dongfeng Tianjin KR cover?
Dongfeng Commercial Vehicle Dongfeng Tianjin KR mainly covers: Drive: 4x2 / 8x4. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Dongfeng Commercial Vehicle Dongfeng Tianjin KR?
For Dongfeng Commercial Vehicle Dongfeng Tianjin KR: confirm local charging and registration first, then filter by range/power and payload, and quote with your operating route.
What is electric cargo truck typically used for?
electric cargo truck focuses on lower-emission work where charging is available. Confirm local charging and registration before purchase.
How many models does Dongfeng Commercial Vehicle Dongfeng Tianjin KR include?
Dongfeng Commercial Vehicle Dongfeng Tianjin KR currently lists about 16 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Dongfeng Commercial Vehicle Dongfeng Tianjin KR?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
