FAW Liute Economy Long-nose Medium Truck 180hp 4X2(6 wheels) 4.5m Dump Truck
EXW
Export quote
FAW Liute Shenli L4 Heavy Truck Dump Trucks
Main model photos
70 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| FAW Liute Economy Long-nose Medium Truck 180hp 4X2(6 wheels) 4.5m Dump Truck | 4x2 / 180hp / China V | ||
| FAW Liute Economy Long-nose Medium Truck 180hp 4X2(6 wheels) 4.2m Dump Truck | 4x2 / 180hp / China V | ||
| FAW Liute Economy Long-Nose Medium Truck 200hp 4X2(6 wheels) 4.9m Dump Truck (Super Strong Red Bridge King) | 4x2 / 200hp / China IV | From $25,847 | |
| FAW Liute Economy Long-Nose Medium Truck 200hp 4X2(6 wheels) 4.9m Dump Truck (Super Strong Red Bridge King) | 4x2 / 200hp / China IV | From $25,847 | |
| FAW Liute Economy Long-Nose Medium Truck 180hp 4X2(6 wheels) 4.5m Dump Truck (Super Strong Red Bridge King) | 4x2 / 180hp / China IV | From $25,528 |
FAW Liute Economy Long-nose Medium Truck 180hp 4X2(6 wheels) 4.2m Dump Truck
EXW
Export quote
FAW Liute Economy Long-Nose Medium Truck 200hp 4X2(6 wheels) 4.9m Dump Truck (Super Strong Red Bridge King)
EXW
From $25,847
Export quote
FAW Liute Economy Long-Nose Medium Truck 200hp 4X2(6 wheels) 4.9m Dump Truck (Super Strong Red Bridge King)
EXW
From $25,847
Export quote
FAW Liute Economy Long-Nose Medium Truck 180hp 4X2(6 wheels) 4.5m Dump Truck (Super Strong Red Bridge King)
EXW
From $25,528
Export quote
Series Specs
Basic Info
Model code (announced): LZT3161K2E5A95 / LZT3163K2E4A90 / LZT3122K2E4A90 / LZT3165K2E4A91 / LZT3161K2E4A95 / LZT3110K2E3A95
Drive type: 4X2
Wheelbase: 4630 / 4350 / 5000 / 4050mm
Engine Model: XichaiCA6DLD-18E5 / XichaiCA6DF4-20E4 / XichaiCA6DF4-18E4 / XichaiCA6DF4-16E4 / XichaiCA6DF3-16E3F
Transmission Model: Fast Gear8JS85F / Hangchi HC7S-115B / Hangchi 7-Speed / Fast Gear8JS75F
Rear Axle Ratio: 5.833 / 5.571
Cab length: 7.5 / 7.16 / 7.965 / 7.485 / 7.19m
Cab width: 2.5 / 2.49m
Cab height: 2.78 / 2.84 / 2.63m
Front track width: 1930 / 2020 / 1830 / 1800mm
rear track: 1860mm
Curb Weight: 7.695 / 7.98 / 6.795 / 7.66 / 6.38ton
Rated payload: 7.9 / 7.965 / 7.8 / 4.99 / 4.9ton
GVWR: 15.79 / 15.975 / 11.98 / 15.755 / 11.475ton
Origin: Liuzhou, Guangxi
tonnage class: Medium-duty truck / Heavy truck
Approach angle: 18 / 28°
departure angle: 18 / 20 / 22 / 19 / 16 / 28°
Remarks: Radiator guard, front underrun protection, mid-roof lift, single-opening body; optional Mercedes-Benz wheel-reduction cast steel single rear axle, heavy-duty suspension, triple-layer 8+8+5 frame, 270L iron fuel tank, three-opening body, five-opening body. / Radiator guard, front underrun protection, mid-roof lift, single-opening body; optional 270L iron fuel tank, three-opening body, five-opening body. / Cab color: Light Phthalocyanine Blue; mechanical suspension driver seat; heavy-duty front and rear leaf springs; aluminum radiator; radiator guard; power steering; exhaust brake; air handbrake; air dryer; battery master switch; air-to-air intercooler; frame full-length equal-width straight beam; φ108 tube 4-hole face gear heavy-duty driveshaft; 240L iron fuel tank. / Cab color: Light Phthalocyanine Blue; mechanical damping driver seat; reinforced front/rear leaf springs; aluminum radiator; radiator guard; power steering; exhaust brake; air handbrake; air dryer; master power switch; air-to-air intercooler; full-length constant-width straight frame rail; large-diameter four-hole end-face tooth reinforced driveshaft; 240L iron fuel tank / Cab color: Light Phthalocyanine Blue; mechanical damping driver seat; reinforced front/rear leaf springs; aluminum radiator; radiator guard; power steering; exhaust brake; air handbrake; air dryer; master power switch; air-to-air intercooler; full-length constant-width straight frame rail; large-diameter four-hole end-face tooth reinforced driveshaft; 240L iron fuel tank; standard 180 oil cylinder / Construction site, mountain road, rural road, secondary road; Cab color: light phthalocyanine blue, new interior, mechanical damping driver seat, large rearview mirror, reinforced front and rear leaf springs, copper radiator, radiator guard, power steering, exhaust brake, air handbrake, air dryer, battery master switch, air-to-air intercooler, full-length equal-width straight frame, φ89 tube diameter six-hole flange driveshaft, 190L iron fuel tank
Version: Economical
Energy Type: Diesel
Engine parameters
Engine Brand: Xichai
Number of cylinders: 6cylinder
Displacement: 6.6 / 6.74 / 7.12L
Emission standard: China V / China IV / China III / Euro III
Max output power: 134 / 150 / 135 / 121 / 118kW
Max hp: 180 / 200 / 160Horsepower
Max torque: 680 / 760 / 580 / 570N·m
Max torque speed: 1300-1700 / 1300-1500rpm
Rated speed: 2300rpm
Engine Type: 6-cylinder inline, direct injection, turbocharged intercooled, electronic common rail
Transmission Parameters
Transmission Brand: Fast Gear / Hangchi
shift method: Manual
Forward gears: 8 / 7Gear
Number of Reverse Gears: 2 / 1pcs
Cargo box parameters
Unloading Type: Dump type / Rear-dump body
Cargo box length: 4.5 / 4.2 / 4.9m
Cargo box width: 2.3m
Cargo box height: 0.8m
Cab parameters
Cab: 141 long-nose flat-top single-row cab
FAQ
What kind of truck is FAW Liute FAW Liute Shenli L4 Heavy Truck Dump Trucks?
FAW Liute FAW Liute Shenli L4 Heavy Truck is an export-oriented Dump Trucks lineup with about 14 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for FAW Liute Shenli L4 Heavy Truck Dump Trucks?
FAW Liute Shenli L4 Heavy Truck Dump Trucks export reference is about $17,778 – $25,847. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does FAW Liute Shenli L4 Heavy Truck Dump Trucks cover?
FAW Liute Shenli L4 Heavy Truck Dump Trucks mainly covers: Drive: 4x2; Horsepower: 180 hp / 200 hp; Emission: China IV / China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in FAW Liute Shenli L4 Heavy Truck Dump Trucks?
For FAW Liute Shenli L4 Heavy Truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does FAW Liute Shenli L4 Heavy Truck Dump Trucks include?
FAW Liute Shenli L4 Heavy Truck Dump Trucks currently lists about 14 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for FAW Liute Shenli L4 Heavy Truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
