FAW Hongta FAW Jiefang Classic 7 Series 200 hp 4X2(6 wheels) 4.02m Dump Truck (China VI)
EXW
From $24,236
Export quote
FAW Hongta FAW Jiefang Classic 7 Series Light Truck
Main model photos
30 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| FAW Hongta FAW Jiefang Classic 7 Series 200 hp 4X2(6 wheels) 4.02m Dump Truck (China VI) | 4x2 / 200hp / China VI | From $24,236 | |
| FAW Hongta FAW Jiefang Classic 7 Series 200 hp 4X2(6 wheels) 4.37m dump truck (China VI) | 4x2 / 200hp / China VI | From $24,014 |
FAW Hongta FAW Jiefang Classic 7 Series 200 hp 4X2(6 wheels) 4.37m dump truck (China VI)
EXW
From $24,014
Export quote
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| FAW Hongta FAW Jiefang Classic 7 Series 150 hp 4X2(6 wheels) 4.06m dump truck | 4x2 / 150hp / China V | From $20,403 | |
| FAW Hongta FAW Jiefang Classic 7 Series 150 hp 4X2(6 wheels) 3.69m muck dump truck | 4x2 / 150hp / China V | From $20,625 | |
| FAW Hongta FAW Jiefang Classic 7 Series 150 hp 4X2(6 wheels) 4.06m muck dump truck | 4x2 / 150hp / China V | From $20,403 | |
| FAW Hongta FAW Jiefang Classic 7 Series 150 hp 4X2(6 wheels) 3.69m dump truck | 4x2 / 150hp / China V | From $20,069 | |
| FAW Hongta FAW Jiefang Classic 7 Series 150 hp 4X2(6 wheels) 4.06m dump truck | 4x2 / 150hp / China V | From $19,847 |
FAW Hongta FAW Jiefang Classic 7 Series 150 hp 4X2(6 wheels) 4.06m dump truck
EXW
From $20,403
Export quote
FAW Hongta FAW Jiefang Classic 7 Series 150 hp 4X2(6 wheels) 3.69m muck dump truck
EXW
From $20,625
Export quote
FAW Hongta FAW Jiefang Classic 7 Series 150 hp 4X2(6 wheels) 4.06m muck dump truck
EXW
From $20,403
Export quote
FAW Hongta FAW Jiefang Classic 7 Series 150 hp 4X2(6 wheels) 3.69m dump truck
EXW
From $20,069
Export quote
FAW Hongta FAW Jiefang Classic 7 Series 150 hp 4X2(6 wheels) 4.06m dump truck
EXW
From $19,847
Export quote
Series Specs
Basic Info
Model code (announced): CA3120K35L3E6 / CA3120K35L3E5 / CA3040K35L3E5 / CA3040K6L3R5E4-1 / CA3040K6L3E4-1 / CA3160K35L3R5E4 / CA3160K35L3E4
Drive type: 4X2
Wheelbase: 3400mm
Engine Model: YuchaiYCS04200-68 / YuchaiYC4D150-50 / YuchaiYC4D130-41
Transmission Model: Fast Gear10JS90 / Fast Gear8JS85E
Rear Axle Ratio: 5.286 / 6.833
Cab length: 6.35 / 5.995 / 6.32 / 6.38m
Cab width: 2.4 / 2.33 / 2.42 / 1995m
Cab height: 2.67 / 2.63 / 2.62m
Front track width: 1755 / 1770 / 1796mm
rear track: 1750 / 1730 / 1720mm
Curb Weight: 6.75 / 2.405 / 2.3 / 7.5ton
Rated payload: 4.995 / 1.895 / 1.995 / 7.995ton
GVWR: 11.94 / 4.495 / 15.69ton
Origin: Qujing, Yunnan
tonnage class: Light Truck
Approach angle: 25 / 23 / 24°
departure angle: 19 / 20 / 18 / 16°
Remarks: Sleeper cab / Single Row
Energy Type: Diesel
Engine parameters
Engine Brand: Yuchai
Number of cylinders: 4cylinder
Displacement: 4.16 / 4.214L
Emission standard: China VI / China V / China IV
Max output power: 147 / 110 / 96kW
Max hp: 200 / 150 / 130Horsepower
Max torque: 720 / 500 / 420N·m
Max torque speed: 1200-1600 / 1400-1800rpm
Rated speed: 2300 / 2800rpm
Engine Type: High-pressure common rail + EGR + DOC + DPF + SCR + ASC / Vertical, inline, water-cooled, four-stroke / Electronic unit pump SCR
Transmission Parameters
Transmission Brand: WLY / Fast Gear
shift method: Manual
Forward gears: 10 / 8Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
Unloading Type: Dump type
Cargo box type: Dump type
Cargo box length: 4.02 / 4.37 / 4.06 / 3.69 / 3.625 / 4.075 / 4 / 4.3m
Cargo box width: 2.2m
Cargo box height: 0.8m
fuel tank
Fuel tank material: Plastic
FAQ
What kind of truck is FAW Hongta FAW Hongta FAW Jiefang Classic 7 Series Light Truck Dump Trucks?
FAW Hongta FAW Hongta FAW Jiefang Classic 7 Series Light Truck is an export-oriented Dump Trucks lineup with about 15 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for FAW Hongta FAW Jiefang Classic 7 Series Light Truck?
FAW Hongta FAW Jiefang Classic 7 Series Light Truck export reference is about $17,722 – $25,347. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does FAW Hongta FAW Jiefang Classic 7 Series Light Truck cover?
FAW Hongta FAW Jiefang Classic 7 Series Light Truck mainly covers: Drive: 4x2; Horsepower: 150 hp / 200 hp; Emission: China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in FAW Hongta FAW Jiefang Classic 7 Series Light Truck?
For FAW Hongta FAW Jiefang Classic 7 Series Light Truck: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does FAW Hongta FAW Jiefang Classic 7 Series Light Truck include?
FAW Hongta FAW Jiefang Classic 7 Series Light Truck currently lists about 15 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for FAW Hongta FAW Jiefang Classic 7 Series Light Truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
