WLY8GS36
EXW
Export quote
WLY WLY8-speed series transmission
Main model photos
2 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| WLY8GS36 | — | ||
| WLY WLY8GS46 8-Speed Manual Transmission | — | ||
| WLY WLY8S110TB 8-Speed Manual Transmission | — | ||
| WLY 8S110TA 8-Speed Manual Transmission | — | ||
| WLY 8S110T 8-Speed Manual Transmission | — |
WLY WLY8GS46 8-Speed Manual Transmission
EXW
Export quote
WLY WLY8S110TB 8-Speed Manual Transmission
EXW
Export quote
WLY 8S110TA 8-Speed Manual Transmission
EXW
Export quote
WLY 8S110T 8-Speed Manual Transmission
EXW
Export quote
Series Specs
Transmission Parameters
Transmission Brand: WLY
Transmission series: WLY 8-speed series
Features: Twin countershaft, full synchronizer / Twin countershaft, auxiliary box synchronizer / Front single, rear single, main-sub box structure
Max input torque: 360 / 450 / 900 / 1100 / 850 / 750 / 1300 / 1180 / 1000 / 400 / 300N·m
1st gear ratio: 9.79 / 7.56 / 5.99 / 8.12 / 10.75 / 11.75 / 10.29 / 10.58 / 10.3 / 11.52 / 9.4 / 12.46 / 12.48
synchronizer: Yes
Main box center distance: 130 / 109.95 / 148.2 / 108 / 85mm
2nd gear ratio: 6.48 / 5.36 / 4.37 / 5.92 / 7.56 / 8.26 / 6.43 / 6.98 / 7.32 / 8.02 / 6.15 / 8.13 / 8.71
3rd gear ratio: 4.42 / 3.83 / 3.31 / 4.48 / 5.35 / 5.85 / 4.09 / 4.55 / 5.11 / 5.74 / 4.07 / 5.18 / 5.83
4th gear ratio: 3.22 / 2.74 / 2.45 / 3.31 / 3.74 / 4.09 / 3.37 / 3.76 / 4.07 / 3.13 / 3.87 / 4.12
5th gear ratio: 2.21 / 1.98 / 1.81 / 2.46 / 2.87 / 2.51 / 3.14 / 2.74 / 2.83 / 2.31 / 2.41 / 3.03
6th gear ratio: 1.47 / 1.4 / 1.32 / 1.79 / 2.02 / 1.57 / 2.07 / 1.95 / 1.97 / 1.51 / 2.11
7th gear ratio: 1 / 1.36 / 1.43 / 1.35 / 1.41
8th gear ratio: 0.73 / 0.72 / 0.85 / 0.74 / 1 / 0.81 / 0.77 / 0.75
Reverse Gear 1 Ratio: 9.79 / 1.8 / 6.05 / 8.2 / 10.92 / 11.93 / 10.45 / 10.63 / 10.23 / 11.42 / 9.33 / 11.33 / 11.57
Transmission weight: 78 / 85 / 245 / 190 / 195 / 185 / 285 / 10.63 / 320 / 310 / 140 / 100kg
Transmission oil capacity: 3.9 / 4 / 8.5 / 13 / 285 / 4.5 / 3.7L
Reverse Gear 2 Ratio: 2.21 / 6.87 / 2.92 / 2.55 / 1.83 / 2.48
Number of gears: 8Gear
shift type: Manual
Transmission Model: WLY8GS36 / WLY8GS46 / WLY8S110TB / WLY8S110TA / WLY8S110T / WLY8S110B / WLY8S110A / WLY8S110 / WLY8S90B / WLY8S90A / WLY8S90 / WLY8S90TA / WLY8S90T / WLY8S130TB / WLY8S130TA / WLY8S130T / WLY8S130B / WLY8S130A / WLY8S130 / WLY8S150T / WLY8S150TA / WLY8S150A / WLY8S150 / WLY8S150B / WLY8D40 / WLY8D30
shift method: Manual
Forward gears: 8Gear
Number of Reverse Gears: 2 / 1pcs
FAQ
What kind of truck is WLY WLY WLY8-speed series transmission?
WLY WLY WLY8-speed series is an export-oriented transmission lineup with about 26 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is transmission typically used for?
For transmission, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does WLY WLY8-speed series transmission include?
WLY WLY8-speed series transmission currently lists about 26 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for WLY WLY8-speed series transmission?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
