Xi'an Cummins ISX15E5 600U 610 hp 14.9L China V diesel engine
EXW
Export quote
Xi’an Cummins ISM Series engine
Main model photos
7 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Xi'an Cummins ISX15E5 600U 610 hp 14.9L China V diesel engine | 610hp / China V | ||
| Xi’an Cummins ISM11E5 450 450hp 10.8L China V Diesel Engine | 450hp / China V | ||
| Xi'an Cummins ISM11E5 440 440hp 10.8L China V diesel engine | 440hp / China V | ||
| Xi'an Cummins ISM11E5 420 420hp 10.8L China V diesel engine | 420hp / China V | ||
| Xi’an Cummins ISM11E5 385 385hp 10.8L China V Diesel Engine | 385hp / China V |
Xi’an Cummins ISM11E5 450 450hp 10.8L China V Diesel Engine
EXW
Export quote
Xi'an Cummins ISM11E5 440 440hp 10.8L China V diesel engine
EXW
Export quote
Xi'an Cummins ISM11E5 420 420hp 10.8L China V diesel engine
EXW
Export quote
Xi’an Cummins ISM11E5 385 385hp 10.8L China V Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: ISM Series
Engine manufacturer: Xi'an Cummins Engine Co., Ltd. / Cummins / Xi’an Cummins
Suitable Range: Tractor truck, cargo truck, dump truck, special vehicle, etc. / Widely used in on-road vehicles such as trucks, buses, RVs, light commercial vehicles, and pickup trucks, as well as off-road machinery including construction equipment, mining machinery, agricultural machinery, marine, oil & gas fields, railways, and generator sets.
Intake type: Turbocharged, Air-to-Air Intercooled / Turbocharged Intercooled (Turbo) / Turbocharged, Air-cooled Intercooled
Min. fuel consumption at full load: 125g/kW.h
Engine net weight: 940kg
Engine Dimensions: 1500*850*1200 / 1335x825x1159mm
Compression ratio: 16.0 : 1 / 16.2 : 1
Bore × Stroke: 125x147mm
Valves per cylinder: 4pcs
firing order: 1-5-3-6-2-4
Engine Brand: Xi’an Cummins
Engine Model: ISX15E5 600U / ISM11E5 450 / ISM11E5 440 / ISM11E5 420 / ISM11E5 385 / ISM11E5 345 / ISM440E 20 / ISM405E 20 / ISM380E 20 / ISM340E 20 / ISME335 30 / ISME360 30 / ISME380 30 / ISME420 30 / ISME385 30 / ISME345 30 / ISME308 30 / ISM11E4 440 / ISM11E4 420 / ISM11E4 385 / ISM11E4 345 / ISM11E4 308
Number of cylinders: 6cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 14.9 / 10.8L
Emission standard: China V / China II/Euro II / China III / Euro III / China IV
Max output power: 448 / 331 / 324 / 309 / 283 / 254 / 298 / 280 / 250 / 246 / 265 / 306 / 226 / 318kW
Max hp: 610 / 450 / 440 / 420 / 385 / 345 / 405 / 380 / 340 / 335 / 360 / 308Horsepower
Max torque: 2779 / 2150 / 2000 / 1900 / 1800 / 2100 / 1825 / 1699 / 1410 / 1590 / 2010 / 1835 / 1710 / 1450 / 2080 / 1500N·m
Max torque speed: 1100-1300 / 1200 / 1200-1600 / 1000-1200 / 1200-1300 / 1000-1400rpm
Rated speed: 1900rpm
Engine Type: Full electronic control / Turbocharged Intercooled (Turbo), Direct Injection, Electronic Control / Inline 6-cylinder, electronic control system
FAQ
What kind of truck is Xi’an Cummins Xi’an Cummins ISM Series engine?
Xi’an Cummins Xi’an Cummins ISM Series is an export-oriented engine lineup with about 22 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Xi’an Cummins ISM Series engine cover?
Xi’an Cummins ISM Series engine mainly covers: Horsepower: 385 hp / 420 hp / 440 hp / 450 hp / 610 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Xi’an Cummins ISM Series engine?
For Xi’an Cummins ISM Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Xi’an Cummins ISM Series engine include?
Xi’an Cummins ISM Series engine currently lists about 22 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Xi’an Cummins ISM Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
