8JS95TE
EXW
Export quote
Fast Gear 8-Speed Series transmission
Main model photos
6 photos
Models
On sale
8JS85TE
EXW
Export quote
8JS75TE
EXW
Export quote
8J45TA
EXW
Export quote
8J45T
EXW
Export quote
Series Specs
Transmission Parameters
Transmission Brand: Fast Gear
Transmission series: 8-speed series
Features: 1. Main and auxiliary box with twin countershaft structure for power split and high reliability; 2. Small center distance, compact size, light weight; 3. Floating main shaft and gears, no needle bearings between gears and shaft for high transmission efficiency; 4. Gears use full 'fine tall tooth' design for smooth meshing and low noise; 5. Full synchronizer design, both main and auxiliary boxes use lock-ring double-cone synchronizers for large synchronization capacity and easy shifting; 6. Combined main and auxiliary box design for small ratio steps and good fuel economy; 7. Multiple PTO options to meet various vehicle modification power take-off needs.
Matching Range: This series of transmissions is suitable for various highway trucks, long-distance coaches, buses, etc.
Max input torque: 850 / 1100 / 950 / 450 / 3300 / 2800 / 2600 / 2400 / 500 / 750 / 650 / 550 / 1300N·m
1st gear ratio: 10.36 / 10.364 / 9.656 / 7.307 / 10.369 / 8.122 / 11.748 / 9.621 / 7.339 / 9.263 / 8.464 / 8.021 / 6.731 / 8.154 / 7.46 / 10.447 / 13.556 / 11.7 / 6.73 / 7.34 / 7.43 / 8.12 / 10.31
synchronizer: Yes
2nd gear ratio: 6.3 / 6.302 / 6.466 / 5.469 / 6.306 / 6.079 / 8.26 / 6.463 / 5.493 / 6.235 / 6.408 / 5.662 / 4.605 / 6.013 / 5.346 / 7.486 / 9.421 / 4.61 / 5.24 / 5.77 / 7.33
3rd gear ratio: 4.32 / 4.318 / 4.321 / 3.747 / 4.473 / 5.769 / 3.764 / 4.235 / 4.642 / 4.063 / 3.397 / 4.444 / 4.115 / 3.825 / 5.356 / 6.46 / 5.77 / 4.3 / 3.4 / 3.76 / 3.77 / 5.09
4th gear ratio: 3.43 / 3.429 / 3.195 / 2.81 / 3.431 / 3.308 / 4.091 / 3.193 / 2.823 / 3.157 / 3.332 / 2.928 / 2.52 / 3.264 / 3.053 / 2.825 / 2.731 / 3.825 / 4.433 / 4.09 / 2.82 / 2.98 / 3.77
5th gear ratio: 2.41 / 2.4 / 2.235 / 1.95 / 2.456 / 2.872 / 2.188 / 2.371 / 2.101 / 1.858 / 2.38 / 2.124 / 2.731 / 3.06 / 2.87 / 1.86 / 2.15 / 2.73
6th gear ratio: 1.46 / 1.459 / 1.497 / 1.838 / 2.019 / 1.473 / 1.554 / 1.451 / 1.349 / 1.635 / 1.45 / 1.398 / 1.957 / 2.125 / 2.02 / 1.35 / 1.39 / 1.53 / 1.94
7th gear ratio: 1 / 1.352 / 1.41 / 1.4 / 1.457 / 1.35
8th gear ratio: 0.79 / 0.794 / 0.739 / 0.75 / 1 / 0.746 / 0.713 / 0.823 / 0.752 / 0.826 / 0.714 / 0.62
Reverse Gear 1 Ratio: 10.53 / 10.526 / 9.807 / 7.307 / 10.531 / 8.122 / 11.932 / 9.802 / 7.339 / 9.263 / 8.018 / 7.448 / 6.25 / 7.571 / 7.46 / 10.447 / 12.247 / 11.93 / 10.52 / 7.34 / 8.08 / 10.26
Transmission weight: 190 / 145 / 135 / 85 / 873 / 779 / 490 / 177/127 / 173 / 180 / 243kg
Transmission oil capacity: 6 / 4.5 / 31 / 34.8 / 33 / 3.3 / 36 / 13L
Reverse Gear 2 Ratio: 2.44 / 2.438 / 2.27 / 1.95 / 2.456 / 2.917 / 2.188 / 2.731 / 2.763 / 2.92
Number of gears: 8Gear
shift type: Manual
Transmission Model: 8JS95TE / 8JS85TE / 8JS75TE / 8J45TA / 8J45T / 8J50TA / 8JSX110TM / 8JSX110TC / 8JSX110TE / 8JSX110T / 8JSX95TM / 8JSX95TC / 8JSX95TE / 8JSX95T / 8JS85TF-C / 8JS85TM / 8JS85TC / C8J45TC / 8JSX110M / 8JSX110C / 8DSS330 / 8DS280 / 8DS260A / 8DS240B / 8DS240A / C8J50TB / C8J45TB / C8J50TA / C8J45TA / C8J45T / 8JS75TE-C / 8JS65F-D / 8JS95TE-C / 8JS95F-C / 8JS75F-C / 8JS95E-C / 8JS85F-C / 8JS65F-C / 8JS55F-C / 8JS75E-C / 8DS260 / 8JS85E-C / 8JS65E-C / 8JS55E-C / 8JS85TE-C / 8JS85C / 8JS75C / 8JS130TA-B / 8JS130T-B
shift method: Manual
Forward gears: 8Gear
Number of Reverse Gears: 2 / 1pcs
FAQ
What kind of truck is Fast Gear Fast Gear 8-Speed Series transmission?
Fast Gear Fast Gear 8-Speed Series is an export-oriented transmission lineup with about 103 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is transmission typically used for?
For transmission, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Fast Gear 8-Speed Series transmission include?
Fast Gear 8-Speed Series transmission currently lists about 103 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Fast Gear 8-Speed Series transmission?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
