SHACMAN Delong X3000 375 hp 8X4(12 wheels) 5.79 m³ concrete mixer truck (Tanghong Heavy Industry brand)(XT5312GJBSX37G5)
EXW
From $52,639
Export quote
Tanghong Heavy Industry SHACMAN chassis concrete
Main model photos
16 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| SHACMAN Delong X3000 375 hp 8X4(12 wheels) 5.79 m³ concrete mixer truck (Tanghong Heavy Industry brand)(XT5312GJBSX37G5) | 8x4 / 375hp / China V | From $52,639 | |
| SHACMAN Delong F3000 375 hp 8X4(12 wheels) 5.79 m³ concrete mixer truck (Tanghong Heavy Industry brand)(XT5312GJBSX37G5) | 8x4 / 375hp / China V | From $47,236 | |
| SHACMAN Delong X3000 345 hp 6X4(10 wheels) 4 m³ concrete mixer truck (Tanghong Heavy Industry) (XT5252GJBSXE43) | 6x4 / 345hp / China V | From $50,889 | |
| SHACMAN Delong X3000 375 hp 6X4(10 wheels) 4 m³ concrete mixer truck (Tanghong Heavy Industry) (XT5252GJBSXE43) | 6x4 / 375hp / China V | From $51,028 | |
| SHACMAN Delong F3000 375 hp 6X4(10 wheels) 4 m³ concrete mixer truck (Tanghong Heavy Industry) (XT5252GJBSXE43) | 6x4 / 375hp / China V | From $44,347 |
SHACMAN Delong F3000 375 hp 8X4(12 wheels) 5.79 m³ concrete mixer truck (Tanghong Heavy Industry brand)(XT5312GJBSX37G5)
EXW
From $47,236
Export quote
SHACMAN Delong X3000 345 hp 6X4(10 wheels) 4 m³ concrete mixer truck (Tanghong Heavy Industry) (XT5252GJBSXE43)
EXW
From $50,889
Export quote
SHACMAN Delong X3000 375 hp 6X4(10 wheels) 4 m³ concrete mixer truck (Tanghong Heavy Industry) (XT5252GJBSXE43)
EXW
From $51,028
Export quote
SHACMAN Delong F3000 375 hp 6X4(10 wheels) 4 m³ concrete mixer truck (Tanghong Heavy Industry) (XT5252GJBSXE43)
EXW
From $44,347
Export quote
Series Specs
Basic Info
Cab dimensions: 11.85×2.496×3.99 / 10.5×2.5×3.99 / 10.1×2.55×3.99 / 10.07x2.55x3.99m
Truck Type: Concrete mixer truck
Drive type: 8X4 / 6X4
Vehicle origin: Tangshan, Hebei
Front/rear track width: Front: 2036/2036mm; Rear: 1860/1860 / Front track: 2036mm; Rear track: 1860/1860 / Front: 2011/2011mm; Rear: 1860/1860
Wheelbase: 1800+3775+1400 / 4375+1400 / 3975+1400 / 1800+3000+1400mm
Curb Weight: 18.16 / 16 / 14ton
Rated payload: 12.71 / 8.805 / 16.87ton
Max. speed: 99 / 80km/h
Front/rear suspension: 1.525/3.35 / 1.525/3.2 / 1.525/2.375 / 1.525/2.345m
Body Parameters
Mixing drum capacity: 5.79 / 4 / 7.7 / 7.73m³
Vehicle certification code: XT5312GJBSX37G5 / XT5252GJBSXE43 / XT5314GJBSX30E / XT5315GJBSXE12
Body Brand: Tanghong Heavy Industry
Engine parameters
Engine Model: WeichaiWP12.375E50 / Xi’an CumminsISM11E5 345 / WeichaiWP10.336E53 / WeichaiWP8.340E51 / WeichaiWP7.340E53 / WeichaiWP10H400E50 / WeichaiWP10.350E53
Number of cylinders: 6cylinder
fuel type: Diesel
Displacement: 11.596 / 10.8 / 9.726 / 7.8 / 7.47 / 9.5L
Emission standard: China V
Max output power: 276 / 254 / 247 / 250 / 294 / 257kW
Max hp: 375 / 345 / 336 / 340 / 400 / 350Horsepower
Rated speed: 1900 / 2100rpm
Engine Type: Inline, water-cooled, six-cylinder, electronically controlled high-pressure common rail + SCR / Full electronic control / Water-cooled, 4-stroke, with exhaust brake, direct injection, turbocharged intercooled, electronically controlled high-pressure common rail + SCR / High-pressure common rail+EGR / Electronic high-pressure common rail + SCR
Chassis Specs
Chassis Series: Delong X3000 / Delong F3000 / Delong New M3000
Chassis Model: SX1310FB / SX1250FB / SX5310GJBMB6 / SX5318GJBMR306
Frame Dimensions: 866×308(8+7+8) / 850×300(8+7) / 850×270(8+5) / 850×300(8+5)mm
rear axle description: MAN 16T dual-reduction / MAN 11.5T single reduction / HDS 16T dual reduction
Axle ratio: 4.769 / 5.262 / 4.266 / 5.286 / 4.8 / 5.73
Leaf spring count: 13/13/12 / 10/12 / 10/10/10
Transmission Parameters
Number of gears: 12 / 10 / 9Gear
Transmission Model: Fast Gear12JSD180T / Fast Gear10JSD140 / Fast Gear9JS135 / Fast Gear10JSD120T / Fast Gear10JSD140T
Tire
Tire Size: 12.00R20 / 12.00R20 16PR / 11.00R20
Number of tires: 12 / 10pcs
FAQ
What kind of truck is Tanghong Heavy Industry Tanghong Heavy Industry SHACMAN chassis concrete mixer truck?
Tanghong Heavy Industry Tanghong Heavy Industry SHACMAN chassis is an export-oriented concrete mixer truck lineup with about 16 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Tanghong Heavy Industry SHACMAN chassis concrete?
Tanghong Heavy Industry SHACMAN chassis concrete export reference is about $41,639 – $52,639. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Tanghong Heavy Industry SHACMAN chassis concrete cover?
Tanghong Heavy Industry SHACMAN chassis concrete mainly covers: Drive: 6x4 / 8x4; Horsepower: 345 hp / 375 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Tanghong Heavy Industry SHACMAN chassis concrete?
For Tanghong Heavy Industry SHACMAN chassis concrete: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is concrete mixer truck typically used for?
concrete mixer truck is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Tanghong Heavy Industry SHACMAN chassis concrete include?
Tanghong Heavy Industry SHACMAN chassis concrete currently lists about 16 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Tanghong Heavy Industry SHACMAN chassis concrete?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
