Dachai CA4DK1-22E62 220hp 4.8L China VI diesel engine
EXW
Export quote
Dachai CA4DK1 Series engine
Main model photos
18 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dachai CA4DK1-22E62 220hp 4.8L China VI diesel engine | 220hp / China VI | ||
| Dachai CA4DK1-22E61 220 hp 4.8L China VI Diesel Engine | 220hp / China VI | ||
| Dachai CA4DK1-20E51 200hp 4.8L China V Diesel Engine | 200hp / China V | ||
| Dachai CA4DK1-16E51 160hp 4.8L China V Diesel Engine | 160hp / China V | ||
| Dachai CA4DK1-14E5 140hp 4.8L China V Diesel Engine | 140hp / China V |
Dachai CA4DK1-22E61 220 hp 4.8L China VI Diesel Engine
EXW
Export quote
Dachai CA4DK1-20E51 200hp 4.8L China V Diesel Engine
EXW
Export quote
Dachai CA4DK1-16E51 160hp 4.8L China V Diesel Engine
EXW
Export quote
Dachai CA4DK1-14E5 140hp 4.8L China V Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: DachaiCA4DK1 / CA4DK1 Series
Engine manufacturer: FAW Group Corporation / Deutz FAW (Dalian) Diesel Engine Co., Ltd.
Suitable Range: 16-20 ton cargo truck, dump truck / For Trucks
Intake type: Turbocharged Air-to-Air Intercooling / Exhaust gas turbocharging, air-to-air intercooling
Min. fuel consumption at full load: ≤193 / 193g/kW.h
Engine net weight: 520kg
Engine Dimensions: 973×794×1055mm
Compression ratio: 18
noise at 1m: ≤91 / ≤92dB
Bore × Stroke: 108×130mm
Valves per cylinder: 4pcs
Engine Brand: Dachai
Engine Model: CA4DK1-22E62 / CA4DK1-22E61 / CA4DK1-20E51 / CA4DK1-16E51 / CA4DK1-14E5 / CA4DK1-22E51 / CA4DK1-20E5 / CA4DK1-22E6 / CA4DK1-21E6 / CA4DK1-20E6 / CA4DK1-18E6 / CA4DK1-22E5 / CA4DK1-16E5 / CA4DK1-18E51 / CA4DK1-18E4 / CA4DK1-18E5
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 4.764 / 4.76 / 4.8L
Emission standard: China VI / China V / China IV
Max output power: 165 / 147 / 118 / 103 / 162 / 155 / 136 / 121 / 139 / 132kW
Max hp: 220 / 200 / 160 / 140 / 210 / 180Horsepower
Max torque: 780 / 650 / 580 / 820 / 850 / 800 / 750 / 830 / 720N·m
Max torque speed: 1200-1700 / 1200-1800 / 1200-1600 / 1100-1700rpm
Rated speed: 2300rpm
Engine Type: SCR / 4-cylinder, inline, turbocharged with intercooler, high-pressure common rail, SCR / High-pressure common rail + EGR + DOC + DPF + SCR + ASC
FAQ
What kind of truck is Dachai Dachai CA4DK1 Series engine?
Dachai Dachai CA4DK1 Series is an export-oriented engine lineup with about 16 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Dachai CA4DK1 Series engine cover?
Dachai CA4DK1 Series engine mainly covers: Horsepower: 140 hp / 160 hp / 200 hp / 220 hp; Emission: China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Dachai CA4DK1 Series engine?
For Dachai CA4DK1 Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Dachai CA4DK1 Series engine include?
Dachai CA4DK1 Series engine currently lists about 16 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Dachai CA4DK1 Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
