Sinotruk Hohan J7G Heavy Truck 430 hp 6X4(10 wheels) 7.8m LNG dump truck
EXW
Export quote
Sinotruk J7G Heavy Truck Dump Trucks
Main model photos
103 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Sinotruk Hohan J7G Heavy Truck 430 hp 6X4(10 wheels) 7.8m LNG dump truck | 6x4 / 430hp / China V | ||
| Sinotruk Hohan J7G Heavy Truck 430 hp 6X4(10 wheels) 6.8m LNG Dump Truck | 6x4 / 430hp / China V | ||
| Sinotruk Hohan J7G Heavy Truck 430 hp 6X4(10 wheels) 6.5m LNG Dump Truck | 6x4 / 430hp / China V | ||
| Sinotruk Hohan J7G Heavy Truck 430 hp 8X4(12 wheels) 7m LNG Dump Truck | 8x4 / 430hp / China V | ||
| Sinotruk Haohan J7G Heavy Truck 430 hp 8X4(12 wheels) 6.8m LNG Dump Truck | 8x4 / 430hp / China V |
Sinotruk Hohan J7G Heavy Truck 430 hp 6X4(10 wheels) 6.8m LNG Dump Truck
EXW
Export quote
Sinotruk Hohan J7G Heavy Truck 430 hp 6X4(10 wheels) 6.5m LNG Dump Truck
EXW
Export quote
Sinotruk Hohan J7G Heavy Truck 430 hp 8X4(12 wheels) 7m LNG Dump Truck
EXW
Export quote
Sinotruk Haohan J7G Heavy Truck 430 hp 8X4(12 wheels) 6.8m LNG Dump Truck
EXW
Export quote
Series Specs
Basic Info
Model code (announced): ZZ3315V3866E1L / ZZ3255V4346E1L / ZZ3315V3266E1L / ZZ3315V3566E1L / ZZ3315V4066E1L / ZZ3255V4046E1L / ZZ3255V3846E1L
Drive type: 6X4 / 8X4
Wheelbase: 1800+3800+1350 / 4600+1350 / 1800+3200+1350 / 1800+3500+1350 / 1800+4000+1350 / 4325+1350 / 4000+1350 / 3800+1350mm
Engine Model: SinotrukMT13.43-50
Transmission Model: SinotrukHW19710
Rear Axle Ratio: 5.45 / 4.77
Cab length: 10.61 / 9.55 / 9.25 / 9.76 / 9.56 / 10.06 / 9.96 / 10.71 / 9.087 / 8.987 / 8.78 / 8.69 / 8.6 / 8.45m
Cab width: 2.55m
Cab height: 3.55 / 3.5 / 2.8m
Front track width: 1930/1930 / 2022mm
rear track: 1800/1800 / 1830/1830mm
Curb Weight: 15.21 / 12.5 / 14.96 / 15.04ton
Rated payload: 15.75 / 12.37 / 15.91 / 15.83 / 15.66ton
GVWR: 31 / 25ton
Origin: Jinan, Shandong
tonnage class: Heavy truck
Approach angle: 17°
departure angle: 20 / 21 / 22 / 24°
Remarks: Optional ratio 4.875, front axle H153 available / Optional ratio (front axle HF9 optional 5.45); front underrun protection, automatic slack adjuster, reflective vest, Triangle warning triangle, wheel chock, static grounding strap, oil pan guard / Front axle optional H153, optional ratio 5.45/4.875 / Final drive ratio optional 4.875, 5.45 / Front axle optional HF7; front underrun protection, automatic slack adjuster, reflective vest, Triangle warning triangle, wheel chock, A/C, static grounding strap, oil pan guard
Version: LNG Edition
Energy Type: LNG (liquefied natural gas)
Engine parameters
Engine Brand: Sinotruk
Number of cylinders: 6cylinder
Displacement: 12.419L
Emission standard: China V
Max output power: 316kW
Max hp: 430Horsepower
Max torque: 1900N·m
Max torque speed: 1100-1400rpm
Rated speed: 1900rpm
Engine Type: Inline 6-cylinder, water-cooled, 4-stroke, turbocharged intercooled, CFV
Transmission Parameters
Transmission Brand: Sinotruk
shift method: Manual
Forward gears: 10Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
Unloading Type: Dump type
Cargo box type: Dump type
Cargo box length: 7.8 / 6.8 / 6.5 / 7 / 7.3 / 7.2 / 7.9 / 6.3 / 6.2 / 6 / 5.8 / 5.6 / 5.4m
Cargo box width: 2.3m
Cargo box height: 1.2 / 0.8m
FAQ
What kind of truck is Sinotruk Sinotruk J7G Heavy Truck Dump Trucks?
Sinotruk Sinotruk J7G Heavy Truck is an export-oriented Dump Trucks lineup with about 18 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Sinotruk J7G Heavy Truck Dump Trucks?
Sinotruk J7G Heavy Truck Dump Trucks export reference is about From $59,722. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Sinotruk J7G Heavy Truck Dump Trucks cover?
Sinotruk J7G Heavy Truck Dump Trucks mainly covers: Drive: 6x4 / 8x4; Horsepower: 430 hp; Emission: China V; Fuel: LNG (liquefied natural gas). Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Sinotruk J7G Heavy Truck Dump Trucks?
For Sinotruk J7G Heavy Truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Sinotruk J7G Heavy Truck Dump Trucks include?
Sinotruk J7G Heavy Truck Dump Trucks currently lists about 18 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Sinotruk J7G Heavy Truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
