Beijing Trucks Dream Chaser 490hp 8X4(12 wheels) 7.6m AMT Automatic Dump Truck
EXW
Export quote
Beijing Trucks Dream Chaser Dump Trucks
Main model photos
169 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Beijing Trucks Dream Chaser 490hp 8X4(12 wheels) 7.6m AMT Automatic Dump Truck | 8x4 / 490hp / China VI | ||
| Beijing Trucks Dream Chaser 490hp 8X4(12 wheels) 7.2m AMT Automatic Dump Truck | 8x4 / 490hp / China VI | ||
| Beijing Trucks Dream Chaser 490hp 8X4(12 wheels) 6.8m AMT Automatic Dump Truck | 8x4 / 490hp / China VI | ||
| Beijing Trucks Dream Chaser 490 hp 8X4(12 wheels) 6.2m AMT automatic dump truck | 8x4 / 490hp / China VI | ||
| Beijing Trucks Dream Chaser 490 hp 8X4(12 wheels) 5.8m AMT automatic dump truck | 8x4 / 490hp / China VI |
Beijing Trucks Dream Chaser 490hp 8X4(12 wheels) 7.2m AMT Automatic Dump Truck
EXW
Export quote
Beijing Trucks Dream Chaser 490hp 8X4(12 wheels) 6.8m AMT Automatic Dump Truck
EXW
Export quote
Beijing Trucks Dream Chaser 490 hp 8X4(12 wheels) 6.2m AMT automatic dump truck
EXW
Export quote
Beijing Trucks Dream Chaser 490 hp 8X4(12 wheels) 5.8m AMT automatic dump truck
EXW
Export quote
Series Specs
Basic Info
Model code (announced): BJ3310D6DP-04 / BJ3310D6DP-03 / BJ3310D6DP-02 / BJ3310D6DP-01
Drive type: 8X4
Wheelbase: 2100+3400+1400 / 2100+2800+1400 / 2100+2500+1400 / 2100+2300+1400 / 2100+4600+1400 / 2100+4200+1400 / 2100+3700+1400 / 2100+3000+1400mm
Engine Model: FotonX12NS6B490 / FotonX12NS6B470 / FotonX12NS6B440 / FotonX11NS6B400
Transmission Model: ZF12-speed
Rear Axle Ratio: 5.26
Cab length: 10.565 / 10.185 / 9.785 / 9.165 / 8.965 / 8.785 / 11.905 / 11.705 / 11.365 / 11.065 / 10.705 / 10.305 / 10.105 / 9.905 / 9.605 / 8.665m
Cab width: 2.55 / 2490m
Cab height: 3.2 / 3.85 / 3.55m
Front track width: 2100/2100 / 2020/2020mm
rear track: 1865/1865mm
Curb Weight: 15.5ton
Rated payload: 15.37ton
GVWR: 31ton
Origin: Changzhou / Changzhou, Jiangsu
tonnage class: Heavy truck
Approach angle: 17°
departure angle: 18 / 16°
Remarks: Optional ratios 4.76, 5.92; optional fuel tank 600L / Standard: 12.3-inch full LCD instrument cluster; Optional: long cab, flat roof, standard floor cab, 4.2/4.76/5.92 ratio, 600L fuel tank. / Standard: 12.3-inch full LCD instrument cluster; Optional: 4.2/4.76/5.92 ratio, 600L fuel tank.
Energy Type: Diesel
Engine parameters
Engine Brand: Foton
Number of cylinders: 6cylinder
Displacement: 11.8 / 10.5L
Emission standard: China VI
Max output power: 360 / 346 / 324 / 294kW
Max hp: 490 / 470 / 440 / 400Horsepower
Max torque: 2300 / 2200 / 2000N·m
Max torque speed: 1000-1400 / 900-1400rpm
Rated speed: 1900rpm
Transmission Parameters
Transmission Brand: ZF
shift method: AMT manual/auto
Forward gears: 12Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
Unloading Type: Dump type
Cargo box type: Dump type
Cargo box length: 7.6 / 7.2 / 6.8 / 6.2 / 5.8 / 6 / 5.6 / 8.8 / 8.6 / 8.4 / 7.8 / 7.4 / 7 / 6.5m
Cargo box width: 2.35m
Cargo box height: 1.5m
Body Parameters
Lifting type: Rear dump
Cab parameters
Cab: Long cab high roof standard floor / Medium-long extended body flat roof standard floor / Medium-long body flat roof standard floor
FAQ
What kind of truck is Beijing Trucks Beijing Trucks Dream Chaser Dump Trucks?
Beijing Trucks Beijing Trucks Dream Chaser is an export-oriented Dump Trucks lineup with about 48 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Beijing Trucks Dream Chaser Dump Trucks cover?
Beijing Trucks Dream Chaser Dump Trucks mainly covers: Drive: 8x4; Horsepower: 490 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Beijing Trucks Dream Chaser Dump Trucks?
For Beijing Trucks Dream Chaser Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Beijing Trucks Dream Chaser Dump Trucks include?
Beijing Trucks Dream Chaser Dump Trucks currently lists about 48 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Beijing Trucks Dream Chaser Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
