Chengliwei Dongfeng Chassis water sprinkler truck

Main model photos

141 photos

Models

On sale

Model	Drive / HP / Emission	EXW
Dongfeng F5 150hp 4X2(6 wheels) green sprinkler truck (Chengliwei brand)	4x2 / 150hp / China VI
Dongfeng T3 160 hp 4X2(6 wheels) water sprinkler truck (Chengliwei brand)	4x2 / 160hp / China V	From $19,167
Dongfeng T5 190hp 4X2(6 wheels) Water Sprinkler Truck (Chengliwei)	4x2 / 190hp / China V	From $23,056
Dongfeng T3 160 hp 4X2(6 wheels) green sprinkler truck (Chengliwei Brand)	4x2 / 160hp / China V	From $19,167
Dongfeng T5 190 hp 4X2(6 wheels) green sprinkler truck (Chengliwei Brand)	4x2 / 190hp / China V	From $23,056

Dongfeng F5 150hp 4X2(6 wheels) green sprinkler truck (Chengliwei brand)

4x2 150hp China VI

EXW

Export quote

Model details

Dongfeng T3 160 hp 4X2(6 wheels) water sprinkler truck (Chengliwei brand)

4x2 160hp China V

EXW From $19,167

Export quote

Model details

Dongfeng T5 190hp 4X2(6 wheels) Water Sprinkler Truck (Chengliwei)

4x2 190hp China V

EXW From $23,056

Export quote

Model details

Dongfeng T3 160 hp 4X2(6 wheels) green sprinkler truck (Chengliwei Brand)

4x2 160hp China V

EXW From $19,167

Export quote

Model details

Dongfeng T5 190 hp 4X2(6 wheels) green sprinkler truck (Chengliwei Brand)

4x2 190hp China V

EXW From $23,056

Export quote

Model details

Series Specs

Basic Info

Cab dimensions: 8.3×2.5×3.35 / 7.6×2.48×3.2 / 8.15×2.48×3.2 / 7.8×2.48×3.2 / 8.4×2.48×3.05 / 8.2×2.48×3.05 / 7.65×2.48×3.05 / 10.3×2.5×2.97 / 9.66×2.5×3.2 / 8.6×2.48×3.05 / 8.2×2.48×3.2 / 7.65×2.48×3.2 / 8.35×2.48×3.1 / 7.8×2.48×3.1m

Truck Type: landscaping sprinkler truck / Water Sprinkler Truck

Drive type: 4X2 / 6X4

Wheelbase: 3950 / 4500 / 5100 / 4350+1300mm

Vehicle origin: Suizhou, Hubei

Front track width: 1820 / 1910 / 1960mm

rear track: 1800 / 1860 / 1860/1860mm

Curb Weight: 5.87 / 7.3 / 6.105 / 6.85 / 10.85 / 10.4 / 6.34 / 5.97 / 6.84 / 6.4ton

Rated payload: 10 / 10.505 / 11.7 / 9.02 / 13.955 / 14.105 / 9.53 / 9.9 / 9.03 / 9.405ton

Max. speed: 88 / 90km/h

Front/rear suspension: 1.25/2.55 / 1.25/2.4 / 1.25/2.05 / 1.25/2.45 / 1.45/3.2 / 1.25/2.76 / 1.45/2.45 / 1.45/2.4m

Energy Type: Diesel

Body Parameters

Tank Dimensions (L×W×H): 4.1×2.35×1.5 / 4.5×2.3×1.56 / 5×2.2×1.46 / 4.5×2.4×1.65 / 5×2.36×1.6 / 4.5×2.2×1.39 / 4×2.27×1.52 / 6.8×2.2×1.44 / 6.5×2.3×1.45 / 4.8×2.15×1.4 / 4.3×2.15×1.55 / 4.3×2.2×1.45 / 4.8×2×1.3 / 4.6×2.3×1.45m

Vehicle certification code: CLW5162GPSHDL / CLW5182GSSE5 / CLW5182GPSE5 / CLW5162GSST5 / CLW5250GSSE5 / CLW5252GSSE5 / CLW5163GSST5 / CLW5161GSST5 / CLW5164GPST5

Body Brand: Chengliwei

Engine parameters

Engine Model: Yunnei PowerD25TCIF1 / YuchaiYC4E160-56 / DongfengISB190 50 / YuchaiYC6JA180-50 / DongfengISB170 50 / YuchaiYCD4D4S-140 / YuchaiYC6JA240-50 / DongfengISB210 50 / YuchaiYC6A240-50 / YuchaiYC6A270-50 / DongfengISD245 50

Number of cylinders: 4 / 6cylinder

Displacement: 2.5 / 4.26 / 5.9 / 6.87 / 7.52 / 6.7L

Emission standard: China VI / China V

Max output power: 110 / 118 / 140 / 132 / 125 / 105 / 177 / 155 / 199 / 180kW

Max hp: 150 / 160 / 190 / 180 / 170 / 140 / 240 / 210 / 270 / 245Horsepower

Rated speed: 3000 / 2600 / 2500 / 2300 / 2800rpm

Engine Type: Electronic control common rail system HEGR + DOC + DPF + SCR + ASC / Vertical, inline, water-cooled, four-stroke / SCR / Water-cooled, electronic high-pressure common rail, turbocharged intercooled, SCR

Cargo box parameters

Box volume: 10.5 / 11.02 / 12.92 / 9.39 / 14.65 / 14.8 / 9.93 / 9.4 / 10.39m³

Chassis Specs

Chassis Brand: Dongfeng

Chassis Series: Huashen F5 / Huashen T3 / Huashen T5 / Yuhu / Yulong

Chassis Model: EQ1160GL6DJ / EQ5180GLVJ / EQ1168GLJ4 / EQ1250GLJ / EQ1258VFJ2

Front axle description: 3.6T / 5T

rear axle description: 8T / 10T

Axle ratio: 6.83

Leaf spring count: 9/11+8 / 9/10+8,9/11+8,8/10+8,8/11+8,3/4+3 / 9/11+8,8/10+8,8/11+8,9/10+8,3/4+3 / 9/10,9/13

Transmission Parameters

Number of gears: 6 / 8 / 5 / 9Gear

Transmission Model: WLY 6-speed / Dongfeng 8-speed / Fast Gear small 8-speed / Dongfeng 6-speed / Dongfeng 5-speed / Fast Gear 8-speed / Fast Gear 9-speed

Tire

Tire Size: 9.00R20 / 10.00-20 18PR / 10.00R20 16PR / 9.00R20 16PR / 11.00R20 18PR / 10.00-20,11.00-20,11.00R20

Number of tires: 6 / 10pcs

FAQ

What kind of truck is Chengliwei Chengliwei Dongfeng Chassis water sprinkler truck?

Chengliwei Chengliwei Dongfeng Chassis is an export-oriented water sprinkler truck lineup with about 70 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.

What is the export price range for Chengliwei Dongfeng Chassis water sprinkler truck?

Chengliwei Dongfeng Chassis water sprinkler truck export reference is about $17,500 – $35,556. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).

What spec range does Chengliwei Dongfeng Chassis water sprinkler truck cover?

Chengliwei Dongfeng Chassis water sprinkler truck mainly covers: Drive: 4x2; Horsepower: 150 hp / 160 hp / 190 hp; Emission: China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.

How do I choose a variant in Chengliwei Dongfeng Chassis water sprinkler truck?

For Chengliwei Dongfeng Chassis water sprinkler truck: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.

What is water sprinkler truck typically used for?

water sprinkler truck specs vary widely by job. Define the application first, then compare specs here and request a quote.

How many models does Chengliwei Dongfeng Chassis water sprinkler truck include?

Chengliwei Dongfeng Chassis water sprinkler truck currently lists about 70 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.

How do I request a quote for Chengliwei Dongfeng Chassis water sprinkler truck?

Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
