Hongyan New Dakang Heavy Truck 310 hp 6X4(10 wheels) 8m Dump Truck
EXW
From $27,778
Export quote
SAIC Hongyan New Dakang Heavy Truck Dump Trucks
Main model photos
30 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Hongyan New Dakang Heavy Truck 310 hp 6X4(10 wheels) 8m Dump Truck | 6x4 / 310hp / China III / Euro III | From $27,778 | |
| Hongyan New Dakang Heavy Truck 380 hp 8X4(12 wheels) 8m Dump Truck | 8x4 / 380hp / China III / Euro III | From $46,528 | |
| Hongyan New Dakang Heavy Truck 336 hp 8X4(12 wheels) 9.5m Dump Truck | 8x4 / 336hp / China III / Euro III | From $41,917 | |
| Hongyan New Dakang Heavy Truck 310 hp 8X4(12 wheels) Dump Truck | 8x4 / 310hp / China III / Euro III | From $28,194 | |
| Hongyan New Dakang Heavy Truck 340 hp 6X4(10 wheels) 7.3m Dump Truck | 6x4 / 340hp / China III / Euro III | From $48,611 |
Hongyan New Dakang Heavy Truck 380 hp 8X4(12 wheels) 8m Dump Truck
EXW
From $46,528
Export quote
Hongyan New Dakang Heavy Truck 336 hp 8X4(12 wheels) 9.5m Dump Truck
EXW
From $41,917
Export quote
Hongyan New Dakang Heavy Truck 310 hp 8X4(12 wheels) Dump Truck
EXW
From $28,194
Export quote
Hongyan New Dakang Heavy Truck 340 hp 6X4(10 wheels) 7.3m Dump Truck
EXW
From $48,611
Export quote
Series Specs
Basic Info
Model code (announced): CQ3254TRG324 / CQ3314TTG426 / CQ3314TTG466 / CQ3304TMG366 / CQ3254TRG494 / CQ3254TPG384 / CQ3254TMG384
Drive type: 6X4 / 8X4
Wheelbase: 1800+4200+1350 / 1800+4600+1350 / 1800+3600+1350 / 4975+1350 / 3825+1350mm
Engine Model: WeichaiWP10.310E32 / WeichaiWP10.380E32 / WeichaiWP10.336 / WeichaiWP10.340E32 / WeichaiWP10.290
Transmission Model: Fast Gear9JS135 / Fast Gear12JS160T / Fast Gear9JS119
Rear Axle Ratio: 4.8 / 5.73
Cab length: 10.854 / 11.96 / 10.19 / 10.085 / 10.23 / 8.4 / 10.83 / 8.3m
Cab width: 2.5m
Cab height: 3.342 / 3.735 / 3.64 / 3.51 / 2 / 3.5m
Front track width: 2006/2006 / 2006mm
rear track: 1850/1850 / 1800mm
Curb Weight: 15.25 / 15 / 12.5 / 12.2 / 12.3 / 12.4 / 12.37ton
Rated payload: 15.62 / 15.87 / 14.87 / 12.37 / 12.6 / 12.5ton
GVWR: 31 / 30 / 25ton
Origin: Chongqing
tonnage class: Heavy truck
Approach angle: 25 / 18 / 23 / 26°
departure angle: 17 / 13 / 15 / 24 / 21°
Remarks: Optional T-type cab; 2 Optional mining bucket body; 3 Optional eco-friendly covered body, cover weight 300 kg, body length also 8.45 m, cargo box length also 5.8 m / 1. Optional T-shaped cab; 2. Optional mining dump body; 3. Cargo body can have side doors, top cover optional, cover weight 400 kg; 4. WP10.290 and SC9DK290Q3 engines have max net power 211 kW; 5. This model is equipped with a tachograph. Dump body unloads by rear tipping; 6. Without top cover, when body length is 5800mm or 5850mm, max body height is 1100mm. When body length is 6200mm, body height is 1000mm. With top cover, when body length is 5400mm or 5800mm, max body height is 1100mm. When body length is 6200mm or 5850mm, body height is 1000mm. / .Optional T-cab; 2. Optional mining dump body; 3. Cargo box can have side doors, top can be covered, cover mass 400 kg; 4. WP10.290, SC9DK290Q3 engine net power 211 kW; 5. This model is equipped with a tachograph. Dump method is rear dump; 6. Without cover, when cargo box length is 5800mm or 5850mm, max box height 1100mm. When cargo box length is 6200mm, box height 1000mm. With cover, when cargo box length is 5400 or 5800mm, max box height 1100mm. When cargo box length is 6200 or 5850mm, box height 1000mm.
Energy Type: Diesel
Engine parameters
Engine Brand: Weichai
Number of cylinders: 6cylinder
Displacement: 9.726L
Emission standard: China III / Euro III
Max output power: 228 / 280 / 247 / 250 / 213kW
Max hp: 310 / 380 / 336 / 340 / 290Horsepower
Max torque: 1250 / 1600 / 1160N·m
Max torque speed: 1200-1600 / 1500-1800 / 1400-1600rpm
Rated speed: 2200rpm
Engine Type: Water-cooled, 4-stroke, with exhaust brake, direct injection, turbocharged intercooled / Water-cooled, four-stroke, with exhaust brake, direct injection, turbocharged intercooled
Transmission Parameters
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 9 / 12Gear
Number of Reverse Gears: 1 / 2pcs
Cargo box parameters
Unloading Type: Rear-dump body / Dump type
Cargo box length: 8 / 9.5 / 7.3 / 5.6 / 8.5 / 5.4 / 5.8 / 7.6 / 6.2m
Cargo box width: 2.3 / 2.5 / 2.36m
Cargo box height: 1 / 0.9 / 1.8 / 1.15 / 1.1 / 1.5m
fuel tank
Fuel tank capacity: 280 / 350 / 360L
Chassis Specs
rear axle description: two-stage cast steel / Tandem axle / Full-floating, dual reduction with inter-axle differential, Steyr steel axle
FAQ
What kind of truck is SAIC Hongyan SAIC Hongyan New Dakang Heavy Truck Dump Trucks?
SAIC Hongyan SAIC Hongyan New Dakang Heavy Truck is an export-oriented Dump Trucks lineup with about 12 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for SAIC Hongyan New Dakang Heavy Truck Dump Trucks?
SAIC Hongyan New Dakang Heavy Truck Dump Trucks export reference is about $27,778 – $51,667. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does SAIC Hongyan New Dakang Heavy Truck Dump Trucks cover?
SAIC Hongyan New Dakang Heavy Truck Dump Trucks mainly covers: Drive: 6x4 / 8x4; Horsepower: 310 hp / 336 hp / 340 hp / 380 hp; Emission: China III / Euro III; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in SAIC Hongyan New Dakang Heavy Truck Dump Trucks?
For SAIC Hongyan New Dakang Heavy Truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does SAIC Hongyan New Dakang Heavy Truck Dump Trucks include?
SAIC Hongyan New Dakang Heavy Truck Dump Trucks currently lists about 12 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for SAIC Hongyan New Dakang Heavy Truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
