Sinotruk Sitrak G5 340 hp 8X4(12 wheels) 7.9 m³ concrete mixer truck (Zoomlion)
EXW
Export quote
ZOOMLION Sitrak Chassis concrete mixer truck
Main model photos
27 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Sinotruk Sitrak G5 340 hp 8X4(12 wheels) 7.9 m³ concrete mixer truck (Zoomlion) | 8x4 / 340hp / China V | ||
| Sinotruk Sitrak G5 350 hp 8X4(12 wheels) 7.9 m³ concrete mixer truck (Zoomlion) | 8x4 / 350hp / China V | ||
| Sinotruk Sitrak G5 310 hp 8X4(12 wheels) 7.9 m³ concrete mixer truck (Zoomlion) | 8x4 / 310hp / China V | ||
| Sinotruk Sitrak G5 340 hp 8X4(12 wheels) 7.9 m³ concrete mixer truck (Zoomlion) | 8x4 / 340hp / China V | ||
| Sinotruk SITRAK C5H 340 hp 8X4(12 wheels) 8 m³ concrete mixer truck (Zoomlion brand) | 8x4 / 340hp / China V |
Sinotruk Sitrak G5 350 hp 8X4(12 wheels) 7.9 m³ concrete mixer truck (Zoomlion)
EXW
Export quote
Sinotruk Sitrak G5 310 hp 8X4(12 wheels) 7.9 m³ concrete mixer truck (Zoomlion)
EXW
Export quote
Sinotruk Sitrak G5 340 hp 8X4(12 wheels) 7.9 m³ concrete mixer truck (Zoomlion)
EXW
Export quote
Sinotruk SITRAK C5H 340 hp 8X4(12 wheels) 8 m³ concrete mixer truck (Zoomlion brand)
EXW
Export quote
Series Specs
Basic Info
Cab dimensions: 9.8×2.5×3.96 / 9.68×2.525×3.96m
Drive type: 8X4
Truck Type: Concrete mixer truck
Vehicle origin: Yuanjiang, Hunan
Front/rear track width: Front: 2035/2035mm; Rear: 1850/1850
Wheelbase: 1800+3025+1400mm
Curb Weight: 13.63 / 13.4ton
Rated payload: 17.24 / 17.47ton
Max. speed: 82km/h
Front/rear suspension: 1.43/2.17 / 1.43/2.05m
Body Parameters
Mixing drum capacity: 7.9 / 8m³
Vehicle certification code: ZLJ5312GJBKE / ZLJ5318GJBKE
Body Brand: ZOOMLION
Engine parameters
Engine Model: WeichaiWP8.340E51 / SinotrukMC07.35-50 / SinotrukMC07.31-50 / SinotrukMC07.34-50
Number of cylinders: 6cylinder
fuel type: Diesel
Displacement: 7.8 / 6.87L
Emission standard: China V
Max output power: 250 / 254 / 228kW
Max hp: 340 / 350 / 310Horsepower
Rated speed: 2100 / 2300rpm
Engine Type: High-pressure common rail+EGR / Inline 6-cylinder, water-cooled, 4-stroke / Inline, water-cooled, 4-stroke, turbocharged with intercooler / Water-cooled, 4-stroke, turbocharged intercooled
Chassis Specs
Chassis Series: G5 / SITRAK C5H
Chassis Model: ZZ1316N306GE1
Leaf spring count: 11/11/10
Transmission Parameters
Number of gears: 10 / 9Gear
Transmission Model: SinotrukHW15710L / 9-Speed
Cab parameters
Cab: SitrakG5
Tire
Tire Size: 11.00R20
Number of tires: 12pcs
FAQ
What kind of truck is ZOOMLION ZOOMLION Sitrak Chassis concrete mixer truck?
ZOOMLION ZOOMLION Sitrak Chassis is an export-oriented concrete mixer truck lineup with about 6 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does ZOOMLION Sitrak Chassis concrete mixer truck cover?
ZOOMLION Sitrak Chassis concrete mixer truck mainly covers: Drive: 8x4; Horsepower: 310 hp / 340 hp / 350 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in ZOOMLION Sitrak Chassis concrete mixer truck?
For ZOOMLION Sitrak Chassis concrete mixer truck: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is concrete mixer truck typically used for?
concrete mixer truck is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does ZOOMLION Sitrak Chassis concrete mixer truck include?
ZOOMLION Sitrak Chassis concrete mixer truck currently lists about 6 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for ZOOMLION Sitrak Chassis concrete mixer truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
