Foton Leisa L9 360 hp 6X4(10 wheels) 4.5 m³ concrete mixer truck
EXW
From $43,014
Export quote
Loxa Heavy Machinery Loxa L9 concrete mixer truck
Main model photos
3 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Foton Leisa L9 360 hp 6X4(10 wheels) 4.5 m³ concrete mixer truck | 6x4 / 360hp / China V | From $43,014 | |
| Foton Laisa L9 360hp 6X4(10 wheels) 4.03 cubic meter concrete mixer truck | 6x4 / 360hp / China V | From $43,014 |
Foton Laisa L9 360hp 6X4(10 wheels) 4.03 cubic meter concrete mixer truck
EXW
From $43,014
Export quote
Series Specs
Basic Info
Cab dimensions: 9.8×2.495×3.99 / 10.51×2.495×3.98m
Truck Type: concrete mixer truck
Drive type: 6X4
Wheelbase: 4100+1350 / 4300+1350mm
Vehicle origin: Beijing
Front/rear track width: Front: 2005,2021mm; Rear: 1865/1865,1880/1880 / Front: 2005,2028; Rear: 1865/1865,1880/1880
Curb Weight: 15 / 16ton
Rated payload: 9.87 / 8.87ton
Max. speed: 85km/h
Front/rear suspension: 1.532/2.818 / 1.532/2.82m
Body Parameters
Drum geometric volume: 12 / 14m³
Mixing drum capacity: 4.5 / 4.03m³
Feed rate: ≥3m³/min
Discharge speed: ≥1 / ≥2m³/min
Discharge residue rate: 0.8%
Vehicle certification code: BJ5253GJB-AB / BJ5253GJB-AC
Body Brand: Loxa Heavy Machinery
Engine parameters
Injection System: Common Rail (China V)
Engine Model: FotonISGe5-360
Number of cylinders: 6cylinder
fuel type: Diesel
Displacement: 11.8L
Emission standard: China V
Max output power: 265kW
Max hp: 360Horsepower
Engine Type: Electronic high-pressure common rail + SCR
Chassis Specs
Chassis Series: AumanETX
Front axle description: 7.5T drum / 9T drum
rear axle description: 13T Steyr axle / 16TMercedes-Benz
Steering gear: Domestic
Axle ratio: 4.76
Leaf spring count: 10/12 / 9/12
clutch: Φ430
Transmission Parameters
Number of gears: 9Gear
Transmission Model: Fast Gear9JSD180
Cab parameters
Cab: Flat roof
Tire
Tire Size: 12.00R20
Number of tires: 10pcs
FAQ
What kind of truck is Loxa Heavy Machinery Loxa Heavy Machinery Loxa L9 concrete mixer truck?
Loxa Heavy Machinery Loxa Heavy Machinery Loxa L9 is an export-oriented concrete mixer truck lineup with about 2 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Loxa Heavy Machinery Loxa L9 concrete mixer truck?
Loxa Heavy Machinery Loxa L9 concrete mixer truck export reference is about From $43,014. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Loxa Heavy Machinery Loxa L9 concrete mixer truck cover?
Loxa Heavy Machinery Loxa L9 concrete mixer truck mainly covers: Drive: 6x4; Horsepower: 360 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Loxa Heavy Machinery Loxa L9 concrete mixer truck?
For Loxa Heavy Machinery Loxa L9 concrete mixer truck: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is concrete mixer truck typically used for?
concrete mixer truck is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Loxa Heavy Machinery Loxa L9 concrete mixer truck include?
Loxa Heavy Machinery Loxa L9 concrete mixer truck currently lists about 2 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Loxa Heavy Machinery Loxa L9 concrete mixer truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
