JAC HV5 4.5T 4.18m Single Row Plug-in Hybrid Flatbed Light Truck 15.5kWh 4X2(6 wheels)
EXW
From $30,278
Export quote
JACHV5 electric cargo truck
Main model photos
55 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| JAC HV5 4.5T 4.18m Single Row Plug-in Hybrid Flatbed Light Truck 15.5kWh 4X2(6 wheels) | 4x2 / 150hp / China VI | From $30,278 | |
| JAC Jubao 4.5T 4.18m Single Row Plug-in Hybrid Stake Light Truck 15.5kWh 4X2(6 wheels) | 4x2 / 127hp / China VI | From $29,167 | |
| JAC Jubao 4.5T 4.22m Single Row Plug-in Hybrid Flatbed Light Truck 15.5kWh 4X2(6 wheels) | 4x2 / 127hp / China VI | From $33,028 | |
| JAC Treasure Basin 4.5T 4.18m single-row plug-in hybrid cage light truck 4X2(6 wheels) | 4x2 / 127hp / China VI | From $33,306 | |
| JAC Treasure Basin 4.5T 4.18m single-row plug-in hybrid cage light truck 4X2(6 wheels) | 4x2 / 150hp / China VI | From $36,111 |
JAC Jubao 4.5T 4.18m Single Row Plug-in Hybrid Stake Light Truck 15.5kWh 4X2(6 wheels)
EXW
From $29,167
Export quote
JAC Jubao 4.5T 4.22m Single Row Plug-in Hybrid Flatbed Light Truck 15.5kWh 4X2(6 wheels)
EXW
From $33,028
Export quote
JAC Treasure Basin 4.5T 4.18m single-row plug-in hybrid cage light truck 4X2(6 wheels)
EXW
From $33,306
Export quote
JAC Treasure Basin 4.5T 4.18m single-row plug-in hybrid cage light truck 4X2(6 wheels)
EXW
From $36,111
Export quote
Series Specs
Basic Info
Model code (announced): HFC1042PHEV5 / HFC5041CCYPHEV2 / HFC1041PHEV2 / HFC5041CCYPHEV2-1 / HFC5041XXYPHEV2 / HFC5041XXYPHEV1
Type: Cargo Trucks / stake truck / enclosed cargo truck
Drive type: 4X2
Wheelbase: 3300 / 3365mm
Box length class: 4.2m
Cab length: 5.995m
Cab width: 2.2 / 2.26 / 2.21 / 2.16 / 1900m
Cab height: 2.2 / 3.15 / 2.45 / 3.25 / 2.42 / 3.24 / 2.94m
CLTC range: 1000km
Curb Weight: 3.305 / 3.555 / 3.075 / 3.15 / 3.25ton
Rated payload: 0.995 / 0.745 / 1.225 / 1.15 / 1.05ton
GVWR: 4.495ton
Max. speed: 100 / 105km/h
Origin: Hefei, Anhui
tonnage class: Light Truck
Remarks: Engine: Kunming Yunnei D20TCIF11
electric motor
Motor 1 Brand: Wuxi Mingheng / Yunnei Mingheng
Motor 1 Model: TZ220XY01 / MH15HB1
Max torque: 120N·m
Motor Type: Permanent magnet synchronous motor
Energy Type: Hybrid
total rated power: 65 / 44kW
Peak power: 125 / 70kW
total peak torque: 120N·m
total rated torque: 65N·m
Battery/Charging
Charging method: Fast Charge
Battery Brand: Wuxi Mingheng / Shaanxi Coal Industry / Mingheng / Guoxuan High-Tech
Battery type: Lithium Iron Phosphate Battery / NMC lithium battery pack
Battery capacity: 15.5 / 17.5kWh
Battery rated voltage: 345 / 345.6V
Engine parameters
Engine Model: Yunnei PowerD25TCIF1 / Yunnei PowerD20TCIF11
Number of cylinders: 4cylinder
Displacement: 2.5 / 2 / 1.999L
Emission standard: China VI
Max output power: 110 / 93kW
Max hp: 150 / 127Horsepower
Cargo box parameters
Cargo box volume: 19.173m³
Cargo box type: stake body / Stake type / Van body
Cargo box length: 4.18 / 4.22 / 4.15m
Cargo box width: 2.1m
FAQ
What kind of truck is JAC JACHV5 electric cargo truck?
JAC JACHV5 is an export-oriented electric cargo truck lineup with about 9 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for JACHV5 electric cargo truck?
JACHV5 electric cargo truck export reference is about $29,167 – $36,111. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does JACHV5 electric cargo truck cover?
JACHV5 electric cargo truck mainly covers: Drive: 4x2; Horsepower: 127 hp / 150 hp; Emission: China VI. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in JACHV5 electric cargo truck?
For JACHV5 electric cargo truck: confirm local charging and registration first, then filter by range/power and payload, and quote with your operating route.
What is electric cargo truck typically used for?
electric cargo truck focuses on lower-emission work where charging is available. Confirm local charging and registration before purchase.
How many models does JACHV5 electric cargo truck include?
JACHV5 electric cargo truck currently lists about 9 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for JACHV5 electric cargo truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
