JAC Kangling H6 120hp 4X2(6 wheels) 4.03m Refrigerated Truck (China VI)
EXW
From $17,861
Export quote
JAC H6 light truck Refrigerated Truck
Main model photos
136 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| JAC Kangling H6 120hp 4X2(6 wheels) 4.03m Refrigerated Truck (China VI) | 4x2 / 120hp / China VI | From $17,861 | |
| JAC Kangling H6 152hp 4X2(6 wheels) 3.7m Extended Cab Refrigerated Truck (China VI) | 4x2 / 152hp / China VI | From $18,556 | |
| JAC Kangling H6 152 hp 4X2(6 wheels) 4.03m single-row refrigerated truck (China VI) | 4x2 / 152hp / China VI | From $18,292 |
JAC Kangling H6 152hp 4X2(6 wheels) 3.7m Extended Cab Refrigerated Truck (China VI)
EXW
From $18,556
Export quote
JAC Kangling H6 152 hp 4X2(6 wheels) 4.03m single-row refrigerated truck (China VI)
EXW
From $18,292
Export quote
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| JAC Kangling H6 120hp 4X2(6 wheels) 4.03m refrigerated truck | 4x2 / 120hp / China V | From $27,083 | |
| JAC Kangling H6 156 hp 4X2(6 wheels) 4m refrigerated truck | 4x2 / 156hp / China V | From $23,028 |
JAC Kangling H6 120hp 4X2(6 wheels) 4.03m refrigerated truck
EXW
From $27,083
Export quote
JAC Kangling H6 156 hp 4X2(6 wheels) 4m refrigerated truck
EXW
From $23,028
Export quote
Series Specs
Basic Info
Cab dimensions: 5.995×2.11×3.1 / 5.995×2.235×3.15 / 5.995×2.34×3.15 / 5.995×2.28×3.19 / 5.995×2.3×3.39m
Drive type: 4X2
Truck Type: Refrigerated Truck
Wheelbase: 3365 / 3308mm
Vehicle origin: Hefei, Anhui
Front track width: 1595 / 1690 / 1685mm
rear track: 1560 / 1620 / 1525mm
Curb Weight: 3.21 / 2.805 / 3.2ton
Rated payload: 1.09 / 1.495 / 1.1ton
GVWR: 4.495ton
Max. speed: 100 / 95km/h
Remarks: Standard: electric preheating, MP3, I-beam front axle, dual batteries; Optional: 6.50R16 tubeless tires, basic MP5 + reverse camera. / MP3 radio. / Optional 4/4+2
Front/rear suspension: 1.1/1.587 / 1.11/1.52 / 1.075/1.612m
Energy Type: Diesel
Engine parameters
Injection System: Common Rail
Engine Model: QuanchaiH20-120E60 / QuanchaiQ28-152E60 / JACHFC4DA1-2D / Yunnei PowerD30TCIE1
Number of cylinders: 4cylinder
Displacement: 2 / 2.8 / 2.771 / 2.977L
Emission standard: China VI / China V
Max output power: 90 / 112 / 88 / 115kW
Max hp: 120 / 152 / 156Horsepower
Max torque: 325 / 380 / 285 / 400N·m
Rated speed: 3200 / 3000rpm
Engine Type: Inline 4-cylinder, water-cooled, 4-stroke, turbocharged with intercooler, high-pressure common rail / Electronically controlled strong-cooling EGR / 4-cylinder inline, 16-valve, DOHC, turbocharged intercooled, high-pressure common rail fuel injection
Cargo box parameters
Cargo box dimensions: 4.03×2.01×2 / 3.7×2.075×2 / 4.03×2.3×2.3 / 4.03×2.08×2 / 4×2.3×2.3m
Cargo box width: 2.01 / 2.075 / 2.3 / 2.08m
Cargo box height: 2 / 2.3m
Body Parameters
Vehicle certification code: HFC5045XLCP22K1C7S / HFC5043XLCP21K1C7S-1 / HFC5043XLCP91K1C2V / HFC5043XLCV3Z
Body Brand: JAC
Others: Refrigeration to -18°C, eco-friendly insulation body, stainless steel door frame and accessories
Chassis Specs
Chassis Brand: JAC
Chassis Series: Kangling H6
Chassis Model: HFC1045P22K1C7S / HFC1043P21K1C7S / HFC1043P91K1C2V
Front axle description: 2T
Frame Dimensions: 180*65*4.5 / 170*70*5mm
rear axle description: 4T / 5T
Axle ratio: 4.875 / 5.571 / 4.33
Transmission Parameters
Number of gears: 5 / 6Gear
Transmission Model: JACML532C / Xingrui LC6T450B / Lu'an LC5T28B / Lu'an LC6T450M1
Cab parameters
Cab: H6 / Single Row
FAQ
What kind of truck is JAC JAC H6 light truck Refrigerated Truck?
JAC JAC H6 light truck is an export-oriented Refrigerated Truck lineup with about 5 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for JAC H6 light truck Refrigerated Truck?
JAC H6 light truck Refrigerated Truck export reference is about $17,861 – $27,083. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does JAC H6 light truck Refrigerated Truck cover?
JAC H6 light truck Refrigerated Truck mainly covers: Drive: 4x2; Horsepower: 120 hp / 152 hp / 156 hp; Emission: China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in JAC H6 light truck Refrigerated Truck?
For JAC H6 light truck Refrigerated Truck: 1) set emission; 2) match body/wheelbase to cargo type; 3) pick drive and horsepower; 4) compare prices, then open a model to quote.
What is Refrigerated Truck typically used for?
Refrigerated Truck covers box, stake or flatbed cargo work from city delivery to regional haul. Filter by body and payload needs.
How many models does JAC H6 light truck Refrigerated Truck include?
JAC H6 light truck Refrigerated Truck currently lists about 5 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for JAC H6 light truck Refrigerated Truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
