XCMG Hanfeng G5 350 hp 8X4(12 wheels) 8.4m Truck Mounted Crane (XCMG Brand)
EXW
From $42,583
Export quote
XCMG XCMG Truck Chassis truck-mounted crane
Main model photos
41 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| XCMG Hanfeng G5 350 hp 8X4(12 wheels) 8.4m Truck Mounted Crane (XCMG Brand) | 8x4 / 350hp / China V | From $42,583 | |
| XCMG Hanfeng G5 310 hp 8X4(12 wheels) 8.4m Truck Mounted Crane (XCMG Brand) | 8x4 / 310hp / China V | From $41,833 | |
| XCMG Hanfeng G5 260 hp 6X4(10 wheels) 8.2m truck-mounted crane (XCMG brand) | 6x4 / 260hp / China V | From $35,722 | |
| XCMG Hanfeng G5 245 hp 6X4(10 wheels) 8.2m truck-mounted crane (XCMG brand) | 6x4 / 245hp / China V | From $35,028 | |
| XCMG Hanfeng G5 270 hp 6X4(10 wheels) 8.2m truck-mounted crane (XCMG brand) | 6x4 / 270hp / China V | From $35,833 |
XCMG Hanfeng G5 310 hp 8X4(12 wheels) 8.4m Truck Mounted Crane (XCMG Brand)
EXW
From $41,833
Export quote
XCMG Hanfeng G5 260 hp 6X4(10 wheels) 8.2m truck-mounted crane (XCMG brand)
EXW
From $35,722
Export quote
XCMG Hanfeng G5 245 hp 6X4(10 wheels) 8.2m truck-mounted crane (XCMG brand)
EXW
From $35,028
Export quote
XCMG Hanfeng G5 270 hp 6X4(10 wheels) 8.2m truck-mounted crane (XCMG brand)
EXW
From $35,833
Export quote
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| XCMG Ruilong 270 hp 8X4(12 wheels) Truck-Mounted Crane (XCMG Brand) | 8x4 / 270hp / China III / Euro III | ||
| XCMG Ruilong 220 hp 6X2(8 wheels) Truck-mounted Crane (XCMG Brand) | 6x2 / 220hp / China III / Euro III | ||
| XCMG Ruilong 180 hp 4X2(6 wheels) Truck-Mounted Crane (XCMG brand) | 4x2 / 180hp / China III / Euro III |
Series Specs
Basic Info
Cab dimensions: 12×2.55×3.85 / 12×2.55×3.856 / 12×2.55×3.833 / 9×2.55×3.655 / 9×2.55×3.51 / 12×2.55×3.82 / 12×2.495×3.98 / 12×2.495×3.7 / 9×2.495×3.53m
Type: truck-mounted crane / Truck with crane
Drive type: 8X4 / 6X4 / 6X2 / 4X2
Wheelbase: 2200+4250+1350 / 5800+1350 / 2200+5300 / 2200+4700 / 5300 / 5800 / 2100+4100+1350 / 2100+5300 / 5000mm
Rated mass: 10.59 / 6.935 / 11.96 / 11.335 / 8.78 / 9.85 / 9.555 / 11.175 / 20.28 / 13.655 / 11.025 / 7.8ton
GVWR: 31 / 25 / 18 / 16ton
Remarks: Optional ratio 4.875
Front/rear suspension: 1.4/2.8 / 1.4/3.45 / 1.4/3.1 / 1.4/2.3 / 1.46/2.99 / 1.46/3.14 / 1.25/2.75m
Energy Type: Diesel
Body Parameters
Other special notes: 300L aluminum fuel tank / This chassis can be optionally equipped with various XCMG brand truck-mounted cranes. / This chassis can be fitted with multiple specifications of XCMG crane. / Optional crane type: knuckle boom.
Crane model: SQS400 / SQS350 / SQS200 / SQS157 / SQS300 / SQ16SK4Q / SQ10SK3Q,SQ10ZK3Q / SQ6.3SK3Q
Lifting capacity: 16 / 8.5 / 8 / 6 / 6.3 / 12 / 8 tons/10 / 10
crane self-weight: 6.02 / 6.5 / 3.475 / 3.4 / 2.57 / 3.8，3.477 / 2.074ton
Vehicle certification code: XZJ5310JSQX5 / XZJ5255JSQX5 / XZJ5251JSQX5 / XZJ5180JSQX5 / XZJ5181JSQX5 / XZJ5250JSQX5 / XZJ5311JSQX / XZJ5251JSQX / XZJ5160JSQX
Body Brand: XCMG brand
Engine parameters
Injection System: Common Rail
Engine Brand: Weichai / SDEC / Yuchai / Xichai
Engine Model: WeichaiWP10.350E53 / WeichaiWP10.310E53 / SDECSC7H260Q5 / SDECSC7H245Q5 / YuchaiYC6A270-50 / YuchaiYC6JA240-50 / YuchaiYC6JA200-50 / YuchaiYC6JA180-50 / YuchaiYC4EG160-50 / SC9DK270Q3 / Yuchai YC6J220-31 / Xichai CA6DF3-18E3
Displacement: 9.726 / 6.44 / 7.52 / 6.87 / 4.73 / 8.82 / 6.5 / 6.74L
Emission standard: China V / China III / Euro III
Max output power: 257 / 228 / 192 / 180 / 199 / 177 / 147 / 132 / 118 / 162 / 143kW
Max hp: 350 / 310 / 260 / 245 / 270 / 240 / 200 / 180 / 160 / 220Horsepower
Max torque: 1600 / 1500 / 1000 / 960 / 1100 / 950 / 800 / 700 / 600 / 680N·m
Max torque speed: 1200-1600 / 1200-1500 / 1400 / 1200-1800 / 1300-1800 / 1200-1700 / 1100-1400rpm
Rated speed: 1900 / 2300 / 2500rpm
Chassis Specs
Chassis Brand: XCMG Truck
Chassis Series: Hanfeng G5 / Ruilong
Chassis Model: NXG1310D5NEX / NXG1250D5NCX / NXG1251D5NBL1X / NXG1180D5NAX / NXG1310D3ZEX / NXG1252D3AZBL1X / NXG1160D3ZAL1X
Frame Dimensions: 300×80×(8+8+8 partial) / 300×80×(8+5+8 local) / 280×80×(8+4+6 local) / 250×75×(7+4+6 local) / 250×75×(7+4) / 280×80×(8+4)mm
rear axle description: 457;13T / 13T(457) / 435;10T / 9T / 457 / 6.5T dual/13T / 7.5/13 / 5T/10T
Axle ratio: 5.286 / 4.875 / 5.143
Leaf spring count: 9/9/10 / 10/10 / 9/9/12+10 / 9/9+7,9/10+8,3/4+3,10/10+8,3/10+8 / 9/9+7 / 10/10+8
Transmission Parameters
Number of gears: 12 / 10 / 9 / 8 / 6Gear
Transmission Model: Fast Gear12JSD160TA / Fast Gear 10JSD160A (Iron) / Fast Gear9JS119TB / Fast Gear8JS118 / Fast Gear8JS85E / Fast Gear6DS60T / Fast Gear9JS135A / Hachi CA6-85
Cab parameters
Cab: G5 Low Roof / G5SD / G5 Flat Roof / Hanfeng G5 Cab
Tire
Tire Size: 11.00R20 18PR / 11.00R20 18PR/11.00R20 16PR / 10.00R20 18PR / 12R22.5 18PR/12R22.5 16PR,11.00R20 18PR/11.00R20 16PR,12R22.5 18PR,11.00R20 18PR / 11.00R20 / 10.00R-20
FAQ
What kind of truck is XCMG XCMG XCMG Truck Chassis truck-mounted crane?
XCMG XCMG XCMG Truck Chassis is an export-oriented truck-mounted crane lineup with about 26 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for XCMG XCMG Truck Chassis truck-mounted crane?
XCMG XCMG Truck Chassis truck-mounted crane export reference is about $22,917 – $42,583. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does XCMG XCMG Truck Chassis truck-mounted crane cover?
XCMG XCMG Truck Chassis truck-mounted crane mainly covers: Drive: 4x2 / 6x2 / 6x4 / 8x4; Horsepower: 180 hp / 220 hp / 245 hp / 260 hp / 270 hp / 310 hp / 350 hp; Emission: China III / Euro III / China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in XCMG XCMG Truck Chassis truck-mounted crane?
For XCMG XCMG Truck Chassis truck-mounted crane: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is truck-mounted crane typically used for?
truck-mounted crane specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does XCMG XCMG Truck Chassis truck-mounted crane include?
XCMG XCMG Truck Chassis truck-mounted crane currently lists about 26 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for XCMG XCMG Truck Chassis truck-mounted crane?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
